2005 JEEP GRAND CHEROKEE Owners Manual

Miles 36,000 42,000 48,000 54, 000
(Kilometers) (58 000) (67 000) (77 000) (86 000)
[Months] [36] [42] [48] [54]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the brake linings. X X
Lubricate the upper knuckle ball stud at steering & sus-
pension ball joints.XX
SCHEDULE “A” 377
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 60,000 66,000 72,000 78,000
(Kilometers) (96 000) (106 000) (115 000) (125 000)
[Months] [60] [66] [72] [78]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary. X
Replace the spark plugs.X
Inspect the ignition cables, replace if necessary (5.7L
Only).X
Inspect the drive belt, replace if necessary. X
Lubricate the upper knuckle ball stud at steering & sus-
pension ball joints.XX
Flush and replace the engine coolant/anti-freeze, at 60
months if not done at 102,000 miles (163 000 km).X
Inspect the brake linings. X
Drain the transfer case and refill. X
378 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 84,000 90,000 96,000 102, 000
(Kilometers) (134 000) (144 000) (154 000) (163 000)
[Months] [84] [90] [96] [102]
Change the engine oil and engine oil filter. X X X X
Rotate the tires. X X X X
Inspect the engine air cleaner filter, and replace if nec-
essary.X
Inspect the PCV Valve, replace if necessary. X
Replace the spark plugs.X
Inspect the drive belt, replace if necessary. X
Lubricate the upper knuckle ball stud at steering & sus-
pension ball joints.XX
Inspect the brake linings. X
Flush and replace the engine coolant/anti-freeze if not
replaced at 60 months.X
Drain the transfer case and refill. X
SCHEDULE “A” 379
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (173 000) (182 000) (192 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Rotate the tires. X X X
Inspect the engine air cleaner filter, and replace if necessary.X
Inspect the PCV Valve, replace if necessary. X
Replace the spark plugs.X
Inspect the ignition cables, replace if necessary (5.7L Only).X
Inspect the drive belt, replace if necessary. X
Lubricate the upper knuckle ball stud at steering & suspension
ball joints.XX
Inspect the brake linings. X
Flush and replace the engine coolant/anti-freeze if not done at
102,000 miles (163 000 km).X
Drain the transfer case and refill.X
380 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
This maintenance is recommended by the manufac-
turer to the owner, but is not required to maintain
emissions warranty.WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the proper equipment. If you have any
doubt about your ability to perform a service job,
take your vehicle to a competent mechanic.
SCHEDULE “A” 381
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS

Suggestions For Obtaining Service For Your
Vehicle..............................384
▫Prepare For The Appointment............384
▫Prepare A List........................384
▫Be Reasonable With Requests.............384

If You Need Assistance...................384
Warranty Information....................386

MoparParts.........................388

Reporting Safety Defects..................388
▫In Canada..........................388

Publication Order Forms..................389
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with the
service advisor and list the items in order of priority. At
many dealers you may obtain a rental vehicle at a minimal
daily charge. If you need a rental, it is advisable to make
these arrangements when you call for an appointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Warranty service must be done by an authorized Chrysler,
Dodge, or Jeep dealer. We strongly recommend that you
take your vehicle to you selling dealer. They know you
and your vehicle best, and are most concerned that you
get prompt and high quality service. The manufacturer’s
dealers have the facilities, factory-trained technicians,
special tools, and the latest information to assure your
vehicle is fixed correctly and in a timely manner.
384 IF YOU NEED CONSUMER ASSISTANCE
