2005 JEEP GRAND CHEROKEE Owners Manual

when attaching clamps. If acid splashes in eyes or on
skin, flush the area immediately with large amounts of
water.
•Do not use a booster battery or any other booster
source that has a greater than 12–volt system, i.e., do
not use a 24–volt power source.
•Never attempt to jump start a discharged battery that
is frozen, because it could rupture or explode during
jump starting.
•Be sure your vehicle is not touching the jump start
vehicle.
•Observe all Battery Warnings in Section 7 of this
manual, while jump starting your vehicle.
WARNING!
Do not attempt to push or tow your vehicle to get it
started. Unburned fuel could enter the catalytic
converter and, once the engine has started, ignite and
damage the converter and vehicle.
EMERGENCY TOW HOOKS — IF EQUIPPED
If your vehicle is equipped with tow hooks, there will be
one in the rear and two mounted on the front of the
vehicle. The rear hook will be located on the driver’s side
of the vehicle.
NOTE:For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of
damage to the vehicle.
WHAT TO DO IN EMERGENCIES 305
6

CAUTION!
Tow hooks are for emergency use only, to rescue a
vehicle stranded off road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle.
WARNING!
Stand clear of vehicles when pulling with tow
hooks. Tow straps and chains may break, causing
serious injury.
TOWING A DISABLED VEHICLE
2WD Models Only
Provided the transmission is operable, tow only in N
(Neutral) at speeds not exceeding 30 mph (48 km/h), for
distances of not more than 15 miles (24 km). Towing at
more than 30 mph (48 km/h) or for more than 15 miles
(24 km) can cause severe transmission damage. If the
transmission is not operable, or the vehicle must be
towed faster than 30 mph (48 km/h) or farther than 15
miles (24 km), remove the driveshaft or tow with all four
wheelsOFFthe ground. Acceptable methods are to tow
the vehicle on a flatbed or with one end of the vehicle
raised and the other end on a towing dolly.
4WD Models Only
The manufacturer recommends towing with all four
wheelsOFFthe ground. Acceptable methods are to tow
the vehicle on a flatbed or with one end of the vehicle
raised and the other end on a towing dolly.
306 WHAT TO DO IN EMERGENCIES

MAINTAINING YOUR VEHICLE
CONTENTS

3.7L Engine...........................310

4.7L Engine...........................311

5.7L Engine...........................312

Onboard Diagnostic System — OBD II........313
▫Loose Fuel Filler Cap Message............313

Emissions Inspection And Maintenance
Programs............................314

Replacement Parts......................315

Dealer Service.........................316
Maintenance Procedures..................316
▫Engine Oil..........................316
▫Drive Belts - Check Condition And Tension . . . 320
▫Spark Plugs.........................321
▫Catalytic Converter....................321
▫Ignition Cables.......................323
▫Crankcase Emission Control System........323
▫Fuel Filter..........................323
▫Air Cleaner Filter.....................323
7

▫Maintenance-Free Battery................324
▫Air Conditioner Maintenance.............325
▫Power Steering Fluid Check..............326
▫Body Lubrication.....................327
▫Windshield Wiper Blades................327
▫Windshield Washers — Front And Rear.....328
▫Exhaust System......................328
▫Cooling System.......................329
▫Hoses And Vacuum/Vapor Harnesses.......334
▫Brake System........................334
▫Automatic Transmission................336
▫Transfer Case........................339
▫Front/Rear Axle Fluid..................340▫Appearance Care And Protection From
Corrosion...........................340

Fuse Panel...........................345
▫Interior Fuses........................345
▫Underhood Fuses
(Power Distribution Center)..............346
▫Underhood Fuses
(Integrated Power Module)..............348

Vehicle Storage........................350

Replacement Bulbs......................350

Bulb Replacement......................351
▫Head Light..........................351
▫Front Turn Signal.....................353
▫Front Fog Light......................354
308 MAINTAINING YOUR VEHICLE

▫Rear Tail, Stop, Turn Signal, And Back-Up
Lights.............................355
▫Center High Mounted Stop Light (CHMSL) . . . 356

Fluid Capacities........................357
Recommended Fluids, Lubricants And Genuine
Parts................................358
▫Engine.............................358
▫Chassis............................359
MAINTAINING YOUR VEHICLE 309
7

3.7L ENGINE
310 MAINTAINING YOUR VEHICLE

4.7L ENGINE
MAINTAINING YOUR VEHICLE 311
7

5.7L ENGINE
312 MAINTAINING YOUR VEHICLE
