FEATURES OF YOUR HYUNDAI
27
CAUTION:
In the following conditions, the I.M.S will not activate.
1. When the key is in the "OFF" posi- tion.
2. When the vehicle is running above 3 km/h.
3. When the seat is being adjusted.
4. When the shift lever is positioned in other than "P" position.
! CAUTION:
In the following conditions, the I.M.S will not memorize.
1. When the "1" or "2" button is not pushed within five seconds.
2. When the seat is being adjusted.
3. When the key is not in the "ON"
position.
4. When the shift lever is positioned in other than "P" position. To activate the memorized posi- tion
1. Place the shift lever into "P" while
the ignition switch is ON.
2. When you push button "1" or "2", the driving position will be automatically adjusted to the position recorded forthat button.
!
To memorize driving position
1. Place the shift lever into "P" while
the ignition switch is ON.
2. Adjust the driver's seat and steering wheel column (with electric tilt and telescopic type) to the desired posi-tion.
3. Push the "SET" button on the I.M.S
until the signal beeps.
4. Within five seconds, push button "1" or "2" until the signal beeps twice.The beep sounds mean that the po-sitions are memorized in the I.M.S. Reverse Parking Aid Function While the vehicle is moving backward, the outside rearview mirror(s) will movedownward to aid reverse parking safely. According to the position of the outside rearview mirror switch knob, the out-side rearview mirror(s) will operate as follows.B090E02TG

1FEATURES OF YOUR HYUNDAI
28
!
NOTE:
o The seat warmer may not operate
if ambient temperature is warm enough.
o If the seat warmer doesn't work when the ambient temperature islower than 24°C, it must bechecked at an authorized dealer.
WARNING:
Be very careful not to injure by lowtemperature burn or an attack offever as following occupants; infants, children, old man, drunken man, people who is taken sleeping drug orcold remedy.B100A01TG-GAT SEAT WARMER (If Installed) The front seats can be electrically heated individually when the ignition switch is ON. When the switch is ON, anumber ranging from 1 to 5 is displayed on the switch (5 = warmest setting). To turn off the seat warmer, set theswitch to 0. B100A01TG
L
: When the remote control outside
rearview mirror switch knob is se-lected to the "L" position, both ofthe outside rearview mirrors will move downward.
R : When the remote control outside
rearview mirror switch knob is se-lected to the "R" position, only thepassenger's outside rearview mir- ror will move downward.
Neutral :When the remote control out-
side rearview mirror switchknob is placed in the middle position, the outside rearviewmirrors will not operate while the vehicle is moving back- ward.
NOTE: When the ignition key is in the "LOCK" position, the shift lever is moved to any position except "R"position, or the remote control out- side rearview mirror switch knob is placed in the middle position, theoutside rearview mirrors will auto- matically revert to original position.

1FEATURES OF YOUR HYUNDAI
94
oON In the "ON" position, the light stays on at all times.
CAUTION:
Do not leave this button pressed foran extended period of time when the vehicle is not running.
!
!
SPECTACLE CASE
B491A03O-GAT (If Installed) The spectacle case is located on the front overhead console. Push the end of the cover to open thespectacle case. WARNING:
o Do not keep objects such as sharp or unsuitable things inside thespectacle case. Such objects can be thrown out in the event of a sudden stop or an accident, pos-sibly injuring the passengers in the vehicle.
o Do not open the spectacle case while the vehicle is moving. Therear view mirror of the vehicle can be blocked by an open spectaclecase.
HTG2182

1FEATURES OF YOUR HYUNDAI
96
B505A01NF-GAT CENTER CONSOLE BOX
HTG2179
The center console box is used for storing cassette tape or small articles. To use the center console box, pull up the button and lift the lid to open it. HTG2179-1
!WARNING:
To avoid the possibility of injury in case of an accident or a sudden stop, the center console box lidshould be kept closed when the car is in motion.
The outside rearview mirrors can be adjusted to your preferred rear vision, both directly behind the vehicle, and tothe rear of the left and right sides. The remote control outside rearview mirror switch controls the adjustmentsfor both right and left outside mirrors. NOTE: Before driving away, always check that your mirrors are positioned so you can see behind you, both to the left and right sides, as well as di-rectly behind your vehicle. B510B01TG
OUTSIDE REARVIEW MIRROR
B510B01TG-AAT

1
FEATURES OF YOUR HYUNDAI
97
!
CAUTION:
o Do not operate the switch continu- ously for an unnecessary length of time.
o Scraping ice from the mirror face
could cause permanent damage.To remove any ice, use a sponge, soft cloth or approved de-icer.!
WARNING:
Be careful when judging the size or distance of any object seen in the passenger side rearview mirror. It is a convex mirror with a curvedsurface. Any objects seen in this mirror are closer than they appear.
To adjust the position of either mirror:
1. Move the selecting switch to the
right or left to activate the adjustable mechanism for the correspondingdoor mirror.
2. Adjust mirror angle by depressing
the appropriate perimeter switch asillustrated.
B510B02TG
! CAUTION:
If the mirror is jammed with ice, do not adjust the mirror by force. Use an approved spray de-icer (not radiatorantifreeze) to release the frozen mechanism or move the vehicle to a warm place and allow the ice to melt.

1FEATURES OF YOUR HYUNDAI
98
The outside rearview mirror heater is actuated in connection with the front/ rear window defroster. To heat the outside rearview mirror glass, push inthe switch for the front/rear window defroster. The rearview mirror glass will be heated for defrosting or defog-ging and will give you improved rear vision in inclement weather conditions.
B510D02HP-AAT OUTSIDE REARVIEW MIRROR HEATER (If Installed)
B380A01TG
With Manual A/C With Automatic A/C
Push the switch again to turn the heater off. The outside rearview mirror heaterautomatically turns itself off after 20 minutes.
B510C01TG-AAT FOLDING THE OUTSIDE REAR- VIEW MIRRORS (Manual Type) (If Installed) To fold the outside rearview mirrors, push them towards the rear. The outside rearview mirrors can be folded rearward for parking in narrowareas.
B510C01TG
!WARNING:
Do not adjust or fold the outside rearview mirrors while the vehicle is moving. This could result in loss of control, and an accident causingdeath, serious injury or property damage. CAUTION:
If the mirror is jammed with ice, do not adjust the mirror by force. Use anapproved spray de-icer (not radiator antifreeze) to release the frozen mechanism or move the vehicle to awarm place and allow the ice to melt.
!

1
FEATURES OF YOUR HYUNDAI
99DAY/NIGHT INSIDE REAR- VIEW MIRROR
B520A01A-AAT Manual type Your Hyundai is equipped with a day/ night inside rearview mirror. The "night" position is selected by flipping the tab at the bottom of the mirror toward you.In the "night" position, the glare of headlights of cars behind you is re- duced. HTG2079
!
B510E01TG-AAT FOLDING THE OUTSIDE REAR- VIEW MIRRORS (Electric Type)
Both left and right outside rearview mirrors can be folded by pressing theoutside rearview mirror folding switch. The outside rearview mirrors can be folded rearward for parking in narrowareas. B510E01TGCAUTION:
o If the mirror is jammed with ice, do not adjust the mirror by force.Use an approved spray de-icer (not radiator antifreeze) to release the frozen mechanism or move thevehicle to a warm place and allow the ice to melt.
o Do not attempt to fold the outside
rearview mirrors manually.If the mirrors are not completely folded out, the mirrors may bevibrate.
!
WARNING:
Do not adjust or fold the outside rearview mirrors while the vehicle ismoving. This could result in loss of control, and an accident which could cause death, serious injury or prop-erty damage.

1FEATURES OF YOUR HYUNDAI
100
B520B02O-GAT Electric type (If Installed) The electric type day/night inside rear- view mirror automatically controls the glare of headlights of the car behindyou.
1. Pressing the button turns the
auto-dimming function OFF which is indicated by the green status indi- cator LED turning off.
2. Pressing the button again turns the auto-dimming function ON whichis indicated by the green status indi- cator LED turning on.
NOTE: The mirror defaults to the "ON" posi- tion each time the vehicle is started. HTG2080B530A01TG-GAT
B530A01TG
PARKING BRAKE
Always engage the parking brake be- fore leaving the car. This also turns onthe parking brake indicator light when the key is in the "ON" or "START" position. Before driving away, be surethat the parking brake is fully released and the indicator light is off.
o To engage the parking brake, de- press the parking brake pedal.
o To release the parking brake, de- press the parking brake pedal a sec- ond time.
NOTE: The parking brake pedal should be checked periodically for proper stroke.
TRUNK LID
B540A01S-GAT Remote Trunk Lid Release To open the trunk lid without using the key, pull up the lid release lever. HTG2014
HTG2017
To close, lower the trunk lid, then press down on it until it locks.
