Page 100 of 297

1
FEATURES OF YOUR HYUNDAI
83
Left-Hand Drive type
HAZARD WARNING SYS- TEM
B370A01A-AAT
B370A01TG
B370A01TG-R
Right-Hand Drive type
Switch position
0 0 1 2 3
Loading condition Driver onlyDriver + front passenger Full passengers (including driver)Full passengers (includ- ing driver) + full trunk loading (or light trailerloading)
Driver + full trunk load- ing (or maximum trailer
loading)
The higher the number of the switch position, the lower the headlight beamlevel. Always keep the headlight beam at the proper leveling position, or head- lights may dazzle other road users.Listed below are the examples of proper switch settings. For loading conditions other than those listed below, adjust theswitch position so that the beam level may be the nearest as the condition obtained according to the list.
!
B340G01LZ-GAT (Automatic Type) (If Installed) It is automatically adjusted the head- light beam level according to the num-ber of the passengers and the loading weight in the luggage area. And it offers the proper headlight beamunder the various conditions.
WARNING:
If it is not working properly even though your car is inclined back- ward according to passenger's pos-ture, or the headlight beam is irradi- ated to the high or low position, have your vehicle inspected by yourHyundai dealer. Don't attempt to inspect or replace the wiring yourself to prevent mal-function.
Page 101 of 297

1FEATURES OF YOUR HYUNDAI
84FRONT/REAR WINDOW DE- FROSTER SWITCH
B380A01TG
With Automatic A/C
With Manual A/C
B380A02HP-AAT (If Installed)
The front/rear window defroster is turned on by pushing in on the switch. At thesame time, the front/rear window de- froster indicator light on the switch is turned on. To turn the defroster off,push in on the switch a second time. The front/rear window defroster auto- matically turns itself off after about 20minutes. To restart the defroster cycle, push in on the switch again after it has turned itself off. CAUTION:
Do not clean the inner side of thefront/rear window glass with an abrasive type of glass cleaner or use a scraper to remove the foreigndeposits from the inner surface of the glass as this may cause dam- age to the defroster elements. NOTE: The ignition must be in the "ON" position for the front/rear window defroster to operate.
!
The hazard warning system should be used whenever you find it necessaryto stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road asfar as possible. The hazard warning lights are turned on by pushing in on the hazard switch.This causes all turn signal lights to blink. The hazard warning lights will operate even though the key is not inthe ignition. To turn the hazard warning lights off, push in on the switch a second time.
Page 102 of 297

1
FEATURES OF YOUR HYUNDAI
85CIGARETTE LIGHTER
B420A02A-AAT For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position.To use the cigarette lighter, push it all the way into its socket. When the element has heated, the lighter willpop out to the "ready" position. Do not hold the cigarette lighter pressed in. This can damage the heating ele-ment and create a fire hazard. If it is necessary to replace the ciga- rette lighter, use only a genuine Hyundaireplacement or its approved equiva- lent. B420A01TGINSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT)
B410A01A-AAT The instrument panel lights can be made brighter or dimmer by turning the instrument panel light control knob. B410A01TG
B410A01TG-R
Left-Hand Drive type
Right-Hand Drive type
DIGITAL CLOCK
B400A01TG-GAT There are three control buttons for the digital clock. Their functions are: H - Push "H" to advance the hour indi-
cated. M - Push "M" to advance the minute
indicated. R - Push "R" to reset minutes to ":00"
to facilitate resetting the clock to the correct time. When this is done: Pressing "R" between 11 : 01 and 11 :29 changes the readout to 11 : 00. Pressing "R" between 11 : 30 and 11 : 59 changes the readout to 12 : 00.Push the "R" button for 4 seconds to display a 12 or 24-hour clock. B400A01TG
Page 104 of 297
1
FEATURES OF YOUR HYUNDAI
87DRINK HOLDER
HTG2183
The drink holder is located on the main console for holding cups or cans. The drink holder can be opened by pushingat its top edge.
B450A01LZ-GAT Front Drink Holder
ASHTRAY
B430A02NF-GAT Front Ashtray The front ashtray may be opened by pushing and releasing the ashtray lid.To clean the ashtray, the plastic recep- tacle should be removed by lifting the plastic ash receptacle upward and pull-ing it out. The ashtray light will only illuminate when the external lights are on. B430A01TG
B440A01TG-AAT Rear Ashtray The rear ashtray may be opened by pulling the ashtray lid out. To clean the ashtray, the plastic receptacle shouldbe removed by lifting the plastic ash receptacle upward and pulling it out.
HTG2177
Page 106 of 297
1
FEATURES OF YOUR HYUNDAI
89
B460B01TG-GAT Opening the Sunroof System If your vehicle is equipped with this feature, you can slide or tilt your sunroof with the sunroof control buttons lo-cated on the overhead console. The sunroof can only be opened, closed, or tilted when the ignition switchis in the "ON" position. B460B01TG
!
SEATBACK POCKET
B540B01E-GAT
HTG2042
The seatback pockets are located on the backside of the front seats for holding papers.SUNROOF
B460A02Y-AAT (If Installed) Sun Shade
B460A01TG
Your HYUNDAI is equipped with a slid- ing sunshade which you can manuallyadjust to let in light with the sunroof closed, or to block sunlight.
WARNING:
Never adjust the sunshade while driving. This could result in loss ofcontrol and an accident that may cause death, serious injury, or prop- erty damage.
Page 110 of 297
1
FEATURES OF YOUR HYUNDAI
93
B490A02NF-GAT Interior Light The interior courtesy light has two but- tons. The two buttons are:
o DOOR In the "DOOR" position, the interior courtesy light comes on when any door is opened regardless of the igni- tion key position. The light goes outgradually 30 seconds after the door is closed.
B490A01TG
B485A01TG-GAT Rear Map Light Push in the map light switch to turn the light on or off. This light produces a spot beam for convenient use as a map light at night or as a personal light for rearpassengers. B485A01TGB480B01TG-AAT Front Map Light Push in the map light switch to turn the light on or off. This light produces a spot beam for convenient use as a map light at night or as a personal lightfor the driver and the passenger. HTG2113
INTERIOR LIGHT
Without sunroof
With sunroof
Page 111 of 297
1FEATURES OF YOUR HYUNDAI
94
oON In the "ON" position, the light stays on at all times.
CAUTION:
Do not leave this button pressed foran extended period of time when the vehicle is not running.
!
!
SPECTACLE CASE
B491A03O-GAT (If Installed) The spectacle case is located on the front overhead console. Push the end of the cover to open thespectacle case. WARNING:
o Do not keep objects such as sharp or unsuitable things inside thespectacle case. Such objects can be thrown out in the event of a sudden stop or an accident, pos-sibly injuring the passengers in the vehicle.
o Do not open the spectacle case while the vehicle is moving. Therear view mirror of the vehicle can be blocked by an open spectaclecase.
HTG2182
Page 112 of 297
1
FEATURES OF YOUR HYUNDAI
95
B500A01TG-GAT ACCESSORY BOX
The accessory box may be opened by pushing at its top edge (Type A) or pushing the knob downward (Type B). It is used for storing small articles. B500A01TG
B500B01NF-GAT Illuminated Glove Box Opening the glove box will automati- cally turn on the light when the multi- function switch is turned to the firstposition.
NOTE: Information about use of the trunk lid control button located in the glove box is beginning on the trunk lidsection.
B541A01TG
Type A
B500A02TG
Type B
!
STORAGE BOX
B500A01TG-AAT GLOVE BOX
WARNING:
To avoid the possibility of injury in case of an accident or a suddenstop, the glove box door should be kept closed when the car is in mo- tion.
o To open the glove box, pull on the glove box release lever.
o The glove box door can be locked
(and unlocked) with the key.
HTG2178
