2005 Hyundai Accent Owner's Manual

1
FEATURES OF YOUR HYUNDAI
53
DRINK HOLDER
!
The front drink holder is located on the center
facia panel for holding cups or cans in its holes.
The drink holder can be used by pushing it.B450A04A-AATFront Drink Holder
HLC2116
CAUTION:
Place the drink holder in its closed position
when not in use.
WARNING:
Do not place anything except drinks in the
drink holder. Such objects can be thrown
out, possibly injuring persons in the ve-
hicle during sudden braking or in the event
of an accident.
!
B440A01E-AATRear Ashtray (If Installed)The rear ashtray may be opened by pulling it
out by its top edge. To remove the ashtray to
empty or clean it, press down on the spring-
loaded tab inside the ashtray and lift the ash-
tray upward and pull it all the way out.
HLC2108

1FEATURES OF YOUR HYUNDAI54
INTERIOR LIGHT
The interior courtesy light switch has three
positions. The three positions are:o "DR" or "
"
In the "DR" or "

" position, the interior
courtesy light comes on when any door is
opened regardless of the ignition key posi-
tion. The light goes out when the door is
closed.
NOTE:If your vehicle is equipped with the delay-out
interior light, the light goes out gradually
within 6 seconds after the door is closed.B490A03A-AATInterior light
HLC2080
Type A (If Installed) Type B
B480A01E-AATMap Light (If Installed)The two map light switches are located on
both sides of the front overhead console.
Push in the map light switch to turn the light on
or off. This light produces a spot beam for
convenient use as a map light at night or as
a personal light for the driver and the passen-
ger.
HLC2081
!
B450B02A-AATRear Drink HolderThe rear drink holder is located on the rear
main console and may be used for holding
cups or cans.
HLC2117
WARNING:
o Use caution when using the drink hold-
ers. A spilled beverage that is very hot
can injure you or your passengers.
Spilled liquids can damage interior trim
and electrical components.
o Do not place anything except drinks in
the drink holder. Such objects can be
thrown out, possibly injuring persons
in the vehicle during sudden braking or
in the event of an accident.

1
FEATURES OF YOUR HYUNDAI
55
SEAT POCKET
GLOVE BOXo To open the glove box, pull on the glove box
release lever.
o To close glove box, push up on glove box.
B540B01TB-AAT(If Installed)A seat side pocket is located on the front
passenger seat to hold papers.
There are seatback pockets on the backside
of the front seats.
HLC2119
!
oONIn the "ON" position, the light stays on at all
times. Do not leave the switch in this position
for an extended period of time when the ve-
hicle is not running.oOFFIn the "OFF" position, the light stays off at all
times even though a door is open.
HLC2110 B500A01A-AAT
WARNING:
To avoid the possibility of injury in case of
an accident or a sudden stop, the glove box
door should be kept closed when the car is
in motion.

1FEATURES OF YOUR HYUNDAI56
OUTSIDE REARVIEW MIRRORB510A01A-AATManual Type (If Installed)The outside rearview mirrors are equipped
with a remote control for your convenience. It
is operated by the control lever in the bottom
front corner of the window.
Before driving away, always check that your
mirrors are positioned so you can see behind
you, both to the left and right sides, as well as
directly behind your vehicle. When using the
mirror, always exercise caution when attempt-
ing to judge the distance of vehicles behind or
along side of you.
HLC2113
CAUTION:
If the mirror control is jammed with ice, do not
attempt to break it free using the control
handle or by manipulating the face of the
mirror. Use an approved spray de-icer (not
radiator antifreeze) to release the frozen
mechanism or move the vehicle to a warm
place and allow the ice to melt.
!
B510B01Y-AATElectric Type (If Installed)
HLC2114
The outside rearview mirrors can be adjusted
to your preferred rear vision, both directly
behind the vehicle, and to the rear of the left
and right sides.
The remote control outside rearview mirror
switch controls the adjustments for both right
and left outside mirrors.To adjust the position of either mirror:1. Move the selecting switch to the right or left
to activate the adjustable mechanism for the
corresponding door mirror.
2. Adjust mirror angle by depressing the ap-
propriate directional switch as illustrated.

1
FEATURES OF YOUR HYUNDAI
57
!
B510D01HP-GATOutside Rearview Mirror Heater
(If Installed)The outside rearview mirror heater is actuated
in connection with the rear window defroster.
To heat the outside rearview mirror glass,
push in the switch for the rear window de-
froster. The rearview mirror glass will be
heated for defrosting or defogging and will give
you improved rear vision in inclement weather
conditions. Push the switch again to turn the
heater off. The outside rearview mirror heater
automatically turns itself off after 20 minutes.
B370A01AB510C01A-AAT
Folding the Outside Rearview MirrorsTo fold the outside rearview mirrors, push
them towards the rear. To unfold the outside
rear view mirrors, push them toward the front.
The outside rearview mirrors can be folded
rearward for parking in restricted areas.
HLC2115
WARNING:
Do not adjust or fold the outside rearview
mirrors while the vehicle is moving. This
could result in loss of control, and an acci-
dent causing death, serious injury or prop-
erty damage.
!
B510B01A
CAUTION:
o Do not operate the switch continuously
for an unnecessary length of time.
o Scraping ice from the mirror face could
cause permanent damage. To remove any
ice, use a sponge, soft cloth or ap-
proved de-icer.
WARNING:
Be careful when judging the size or distance
of any object seen in the passenger side
rearview mirror. It is a convex mirror with a
curved surface. Any objects seen in this
mirror are closer than they appear.
!

1FEATURES OF YOUR HYUNDAI58
PARKING BRAKE
DAY/NIGHT INSIDE REARVIEW
MIRRORB520A01A-AATYour Hyundai is equipped with a day/night
inside rearview mirror. The "night" position is
selected by flipping the tab at the bottom of the
mirror toward you. In the "night" position, the
glare of headlights of cars behind you is re-
duced.
HLC2112
B530A01A-AATAlways engage the parking brake before leav-
ing the car. This also turns on the parking
brake indicator light when the key is in the
"ON" or "START" position. Before driving away,
be sure that the parking brake is fully released
and the indicator light is off.
o To engage the parking brake, pull the lever
up as far as possible.
o To release the parking brake, pull up the
lever and press the thumb button. Then,
while holding the button in, lower the brake
lever.
HLC3024
HIGH-MOUNTED REAR STOP LIGHTB550A01S-GAT(If Installed)In addition to the lower-mounted rear stop
lights on either side of the car, the high mounted
rear stop light in the center of the rear window
or inserted in the rear spoiler also lights when
the brakes are applied.
HLC2124

1
FEATURES OF YOUR HYUNDAI
59
FLOOR MAT ANCHOR
HOOD RELEASE
!
!
CAUTION:
Make sure that the support rod has been
released prior to closing the hood.
!
WARNING:
o Always double check to be sure that the
hood is firmly latched before driving
away. If it is not latched, the hood could
open while the vehicle is being driven,
causing a total loss of visibility, which
might result in an accident.
o The support rod must be inserted com-
pletely into the hole provided in the hood
whenever you inspect the engine com-
partment. This will prevent the hood
from falling and possibly injuring you.
o Do not move the vehicle with the hood in
the raised position, as vision is obstructed
and the hood could fall or be damaged.
B571A03Y-AATWhen using a floor mat on the front floor
carpet, make sure it attaches to the floor mat
anchor in your vehicle. This keeps the floor
mat from sliding forward.
HXGS263
WARNING:
o Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the move-
ment of the pedals during driving, it
may cause an accident.
o Don't put a additional floor mat on the
top of the fixed mat, otherwise the ad-
ditional mat may slide forward and inter-
fere with the movement of the pedals. 2. Push the safety catch lever to the left and
lift the hood.
3. Hold the hood open with the support rod.
Before closing the hood, return the support rod
to its clip to prevent it from rattling. Lower the
hood until it is about 1 ft. (30 cm) above the
closed position and let it drop. Make sure that
it locks into place.
B570A01A-1 B570A03A-GAT
1. Pull the release knob to unlatch the hood.
B570A01A

1FEATURES OF YOUR HYUNDAI60
B560A02S-AAT
B560A01A-1The fuel-filler lid may be opened from inside the
vehicle by pulling up on the fuel-filler lid opener
located on the front floor area on the left side
of the car.NOTE:If the fuel-filler lid will not open because ice
has formed around it, tap lightly or push on
the lid to break the ice and release the lid. Do
not pry on the lid. If necessary, spray around
the lid with an approved de-icer fluid (do not
use radiator anti-freeze) or move the vehicle
to a warm place and allow the ice to melt.REMOTE FUEL-FILLER LID RELEASE
!
WARNING:
o The fuel cap must be tightened at least
3 clicks, otherwise " " light will
illuminate.
o Gasoline vapors are dangerous. Before
refueling, always stop the engine and
never allow sparks or open flames near
the filler area. If you need to replace the
filler cap, use a genuine Hyundai re-
placement part.
o If you open the fuel filler cap during
high ambient temperatures, a slight
"pressure sound" may be heard. This is
normal and not a cause for concern.
Whenever you open the fuel filler cap,
turn it slowly.
HLC2016-2
!
o Make sure the fuel filler cap is replaced
and securely seated after fueling. Fail-
ure to replace or fully seat the fuel filler
cap will result in fuel vapors escaping
into the atmosphere and the check
engine "MIL" indicator illuminating.
o Do not "TOP-OFF" after the first nozzle
shut off when refueling.
o Automotive fuels are flammable/explo-
sive materials. When refueling, please
note the following guidelines carefully.
o Before touching the fuel nozzle or fuel
filler cap, have one's hands in contact
with metal parts away from the filler
neck to discharge static electricity.
o Do not get back in the vehicle while
refueling. Do not operate anything that
can produce static electricity. Static
electricity discharge can ignite fuel va-
pors resulting in explosion.
o When using a portable fuel container
be sure to place the container on the
ground while refueling. Static electric-
ity discharge from the container can
ignite fuel vapors causing a fire. While
starting refueling contact should be
maintained until the filling is complete.
WARNING:
