Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure indicator and the
appropriate tire on the tire pressure
monitor to come on.Each tire, including the spare, should
be checked monthly when cold and
set to the recommended inf lation
pressure as specif ied in the vehicle
placard and this owner’s manual (see
page ).
Although your tire pressure is
monitored, you must manually check
thetirepressuresmonthly.
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
When the tire pressure monitoring
system warning indicator is on, one
or more of your tires is signif icantly
under-inf lated. You should stop and
check your tires as soon as possible,
and inflate them to the proper
pressureasindicatedonthevehicle’s
tire inf ormation placard.
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire. 247
Tire Pressure Monitoring System (TPMS)
Low Tire Pressure
Indicator
Driving
165

Trailer lights and equipment must
comply with f ederal, state, province,
and local regulations. Check trailer
light requirements f or the areas
where you plan to tow.
To get to your vehicle’s trailer
lighting connector, open the tailgate,
remove the cargo cover, then
remove the rear panel trim. The
connector is on the lef t side.We recommend that you have your
dealer install a Honda wiring harness
and converter. This harness has
been designed f or your vehicle.
If you use a non-Honda trailer
lighting harness and converter, you
cangetthematingconnectorand
pins that mate with the connector in
your vehicle f rom your dealer.
Since lighting and wiring vary with
trailer type and brand, you should
also have a qualif ied mechanic install
a suitable connector between the
vehicleandthetrailer.
T railer L ights
Towing a Trailer
Driving
179
GROUND
(BLACK)
BACK-UP LIGHT
(GREEN/BLACK) LEFT TURN SIGNAL
(GREEN/WHITE)
RIGHT TURN SIGNAL
(GREEN/YELLOW) BRAKE LIGHT
(WHITE/BLACK)
TAILLIGHT
(RED/BLACK)

Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
To remove the f ront turn signal
bulb, push it in slightly and turn it
counterclockwise.
Install the new bulb into the
socket and reinstall it.Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
1. 4.
5.
3. 2.
Lights
Replacing a Front T urn Signal/
Parking L ight Bulb
Maint enance
209

µµ
Î Î
Î Î
Î
No. No.
Amps. Amps.
Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
15 A
10 A
7.5 A
7.5 A
7.5 A 15 A
7.5 A
7.5 A 10 A
7.5 A
7.5 A 30 A 20 A
20 A
20 A
20 A
10 A
20 A
20 A
15 A
15 A
10 A
20 A
7.5 A
7.5 A 20 A
20 A
Fuel Pump
SRS
Heater Control, A/C Clutch
Relay, Cooling Fan Relay
Power Mirror, VTM-4
Daytime Running Light
ECU(PCM),CruiseControl
OPDS, Rear Wiper
ACC Relay
Back-up Lights, Instrument
Lights
Turn Signals
VTM-4
Front Wiper
Not used
Driver’s Power Window
Driver’s Power Seat Reclining
Heated Seat
Driver’s Power Seat Sliding
Not used
Daytime Running Light
Driver’s side Rear Power
Window
Front Passenger’s Power
Window
Front Accessory Socket, Radio
Small Light
Interior Light, Navi
Power Door Lock
Back Up
Moonroof
Moonroof
Passenger’s Side Rear Power
Window
Canadian models
:
Canadian models
Fuse Locations
242
Driver’s Side INTERIOR FUSE BOX
Passenger’s Side
Front Front
:

µ µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
Specif ications
T echnical Inf ormation
247
Battery
Fuses
Engine
Alignment
Tires
Lights
60 W/55 W
12 V
60 psi (420 kPa , 4.2 kgf/cm
)
32 psi (220 kPa , 2.2 kgf/cm)
T155/90D16 110M P235/70R16 104S 1°88’
0°50’ 0°50’
0.00 in (0.0 mm)
0.00 in (0.0 mm) 10.0 : 1
211.8 cu-in (3,471 cm
)
3.50 x 3.66 in (89.0 x 93.0 mm)
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V
12 V 12 V
12 V
12 V
5W
27 W/8 W
5W
21 W/5 W
21 W/5 W
21 CP (18 W)
5W
18 W
6.2 W
5W
1.1 W
3.8 W
12 V 65 AH/20 HR 14 V 12 V 12.4 W 1.4 W
Capacity Interior
Under-hood
Type
BorexStroke
Displacement
Compression ratio
Spark plugs
Water cooled 4-stroke SOHC,
V6 gasoline engine
Toe-in
Camber
Caster
Size
Pressure IZFR5K-11
SKJ16DR-M11
Headlights
Front side marker lights
Front turn signal lights/
Parking lights
Rear side marker lights
Rear turn signal/hazard lights
Stop/Taillights
Backup lights
License plate lights
High-mount brake light
Individual map lights
Tailgate light
Vanity mirror light
Door (Courtesy) light
Grab rail lights
Console lights See page
242or the fuse label
attached to the dashboard.
See page 242or the fuse label
attached to the inside of the fuse
box door under the dashboard.
See page 241or the fuse box
cover.
Front/Rear
Spare
Front/Rear
Spare Front
Rear
Front
Rear
Front
Driver’s side
Passenger’s side
(1157 NA)
(168)
(7443)
(7443) (921)
(168)
(921)
(204)
(HB2)
(168)
Front
Rear
Front
Rear
Front NGK:
DENSO:

CONT INUED
............................
Capacities Chart .246
.............
Carbon Monoxide Hazard . 53
.............................
Carrying Cargo .153
..............
CAUTION, Explanation of . ii
..........................
CD Changer .113, 114
.......................................
CD Player .111
........................
Certif ication Label .244
............................................
Chains .220
....................
Changing a Flat Tire .225
...
Accessories and Modif ications . 151
ACCESSORY (Ignition Key .......................................
Position) .77
..............
Accessory Power Sockets . 95
....................
Additives, Engine Oil . 199
.............................
Airbag (SRS) .11, 23
..........
Airbag System Components . 23
..............
Air Conditioning System . 100
.....................
Rear A/C Control .105
.......................
Air Pressure, Tires .217
......................................
Antif reeze .202
Anti-lock Brakes (ABS) ...............................
Indicator .59, 169
...................................
Operation .169
..............
Anti-thef t, Audio System . 123
.
Anti-thef t Steering Column Lock . 77
................
Audio System . 106,109,119
...
Automatic Seat Belt Tensioners . 21
.............
Automatic Speed Control . 138
..............
Automatic Transmission . 160
..........................
Capacity, Fluid .204
...............
Checking Fluid Level . 204
.......................................
Shif ting .160
.
Shif t Lever Position Indicator . 160................
Shif t Lever Positions . 161
....................
Shif t Lock Release . 163
Battery Charging System ...........................
Indicator .58, 234
............................
Jump Starting .230
..............................
Maintenance .221
............................
Specif ications .247
..............................
Bef ore Driving .145
..................................
Belts, Seat .10, 20
...........................
Beverage Holders .95
..................................
Booster Seats .50
Brakes ...........
Anti-lock System (ABS) . 169
.............
Break-in, New Linings . 146
...........................................
Fluid .206
....................
Bulb Replacement .210
.........................................
Parking .93
.................
System Indicator . 59,236
........................
Wear Indicators .168
.............................
Braking System .168
.................
Break-in, New Vehicle . 146
..
Brightness Control, Instruments . 72........................
Brights, Headlights .71
Bulb Replacement .....................
Brake Lights .210, 211
..........................
Back-up Lights .210
................
Front Parking Lights . 209
........
Front Side Marker Lights . 212
.................................
Headlights .208
........
High-mount Brake Lights . 211
.................................
Rear Bulbs .210
............................
Specif ications .247
.............
Turn Signal Light . 209,210
..............................
Bulbs, Halogen .208
