2005 HONDA ODYSSEY Owners Manual

´
If it takes several pushes on the
button to lock or unlock the doors
and the tailgate, replace the battery
as soon as possible.
Battery type: CR2025 To replace the battery, separate the
half s by caref ully prying on the edge
with a coin. Remove the old battery,
and insert a new battery with the
side f acing up. Snap the two halves
of the transmitter case back together.
As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.Replacing the Transmitter
Battery
Remote Transmitter
136

To lock the doors and the tailgate,
press the f ront of the master door
lock switch on either f ront door,
pressthelocktabonthedriver’s
door, or use the outside lock on the
driver’s door.
Pressing the rear of the master door
lock switch will unlock all doors and
the tailgate.The lock tab on any door locks and
unlocks that door.
All doors and the tailgate can be
locked f rom the outside by using the
key in the driver’s door. To unlock
only the driver’s door, insert the key,
turn the key, and release it. The
remaining doors and the tailgate
unlock when you turn the key a
second time within a f ew seconds.With the driver’s door open and the
key in the ignition, both master door
lock switches are disabled. They are
not disabled if the driver’s door is
closed. Pushing the f ront of the
master door lock switch on the open
passenger’s door will lock all doors
and the tailgate.
Power Door L ocks
L ockout Prevent ion
Door L ocks
Inst rument s and Cont rols
137
MASTER DOOR
LOCK SWITCH
Lock

The childproof door locks are
designed to prevent children seated
in the rear f rom accidentally opening
the rear sliding doors. Each door has
a lock lever near the edge. With the
lever in the LOCK position, the door
cannot be opened f rom the outside
regardless of the position of the lock
tab. To open the door, pull the lock
tab up and use the outside door
handle.With the childproof door locks on,
automatic operation with the inside
door handle is disabled.
To open the tailgate, pull the handle,
then lif t up. To close the tailgate, use
the inner handle to pull it down, then
press down on the back edge.
Keep the tailgate closed at all times
while driving to avoid damaging the
tailgate and to prevent exhaust gas
f rom getting into the interior. Seeon page
.
56
On EX and Touring models
LX and EX modelsChildproof Door L ocks T ailgate
Carbon Monoxide Hazard
Door L ocks
138

The tailgate can be opened and
closed with the remote transmitter
or the switch on the dashboard when
both f ront doors are unlocked.The tailgate can also be closed by
pressing the button on the tailgate. If
you press the button again while the
tailgate is closing, you will hear three
beeps, and the tailgate will stop
moving, reverse direction, and stop
at the f ully opened position.
Press and hold the tailgate button on
the remote transmitter or the
dashboard switch f or about 1 second
to open or close the tailgate. Each
time you press the button on the
remote transmitter or the dashboard
switch, you will hear a beep.
If you push the same button or
switch again while the tailgate is
opening or closing, you will hear
three beeps, and the tailgate will stop
moving, reverse direction, and stop
at the f ully opened or closed position.
To open or close the tailgate
manually, see page .138
CONT INUED
On Touring model only
Power Tailgate
Door L ocks
Inst rument s and Cont rols
139
DASHBOARD SWITCH
TAILGATE
BUTTON TAILGATE SWITCH

The power tailgate has an auto-
reverse f eature. If it meets
resistance while opening or closing,
it will beep three times and reverse
direction. However, the tailgate may
not reverse immediately. Always
make sure passengers and objects
are clear of the tailgate before
opening or closing it.Also check that passengers,
especially children, do not have their
hands on the edge of the tailgate or
on the tailgate still. The auto reverse
featurestopsworkingwhenthe
tailgate is about to latch so the motor
can pull the tailgate shut.
If your vehicle’s battery is
disconnected, goes dead, or the f use
is removed while the tailgate is f ully
open, the power tailgate needs to be
reset. After connecting the battery
or installing the f use, close the
tailgate f ully by hand.
The power tailgate may not open or
close under the these conditions: Whenthetailgateortheroof is
covered with snow or ice.
Do not install any accessories on the
tailgate. It may cause the tailgate not
to f unction properly. If there is snow
or ice on the tailgate, make sure to
remove it bef ore you operate the
tailgate.
If you pull the tailgate release handle
while the tailgate is opening or
closing, it will stop moving. You need
to open or close it the rest of the way
manually.
The tailgate has sensors on both
sides. Be caref ul not to damage them.
If the sensors are damaged, the
power tailgate does not f unction
properly.
When the vehicle is swayed in a
strong wind. The vehicle is parked on a steep
hill.
A ut o-Reverse
Door L ocks
140
Closing a power tailgate while
anyone is in the path of the
tailgate can cause serious
injury.
Make sure everyone is clear
before closing the power
tailgate.

Push the release lever to the right as
shown.
If you need to unlock the tailgate
manually, it means there is a
problem with the tailgate. Have the
vehicle checked by your dealer.
Use a small flat-tipped screwdriver to
remove the cover on the back of the
tailgate. If the power door lock system cannot
unlock the tailgate, unlock it
manually.
If you try to drive off with the
tailgate not closed completely, a
beeper sounds and a ‘‘DOOR &
TAILGATE OPEN’’ message is
shown on the multi-inf ormation
display.
Keep the tailgate closed at all times
while driving to avoid damaging the
tailgate and to prevent exhaust gas
f rom getting into the interior. See
on page
.
If there is a problem in the power
tailgate system, you will see a
‘‘CHECK POWER TAILGATE’’
message on the multi-inf ormation
display. Have the system checked by
your dealer.
With this message shown in the
multi-inf ormation display, you can
still open or close the tailgate
manually. 56
CONT INUED
On Touring model only
Unlocking the T ailgate
Carbon Monoxide Hazard
Door L ocks
Inst rument s and Cont rols
141

To open, pull the inside or outside
door handle, and slide the door back.
It will latch in the f ully open position.
When opening f rom the inside, the
childproof door lock must be
unlocked.
To close, pull either handle, and slide
the door closed. Make sure the door
is closed and latched securely bef ore
driving, and all passengers are clear
of the sliding doors bef ore closing
them.
If youcannotopenthetailgate,
remove the cover on the back of the
tailgate(seepage ).Usethekey
to unlock the tailgate as shown, then
pull the outer handle to open the
tailgate. The doors are electrically powered
and can be operated with the remote
transmitter, the door handles, or the
dashboard switches. To operate the
doors:
When opening a sliding door, it stops
about halfway if the window is open
morethan3in(8cm).If thevehicle
is f acing downhill, the sliding door
will slam shut when you release the
door handle. Always close the
window f ully bef ore opening the
sliding door. The shift lever must be in Park or
Neutral. To operate the doors with
the shift lever in Neutral, the
ignition switch must be in the ON
(II) position with the brake pedal
pressed or the parking brake
applied.
TheMAINswitchmustbeinthe
ON position.
The doors must be unlocked.
141
LX model
On EX and Touring models
On LX and EX models
Power Sliding Doors
Opening and Closing Manual
Sliding Doors
Door L ocks, Sliding Doors
142

CONT INUED
When the shift lever is in Park:When the shift lever is in Neutral andthe ignition switch is in the ON position:
If you shif t out of Park while a door
is closing, you will hear a beep until
the door closes.
If you shif t out of Park while a door
is opening, you will hear a
continuous tone and the door will
stop moving. Stop the vehicle and
close the door.
If you shif t out of Neutral or release
the brake pedal or the parking brake
while a door is closing, you will hear
a beep until the door closes.
If you shif t out of Neutral or release
the brake pedal or the parking brake
while a door is opening, you will hear
a continuous tone and the door will
stop moving. Stop the vehicle and
close the door. To open the door with the inside
door handle, pull the handle
backward. Push it f orward to close
the door. If you pull backward or
push f orward on the door handle
while a door is opening or closing,
the door stops moving. Pull
backward or push f orward to open or
close the door f ully.
To open or close the door with the
outside door handle, pull the door
handle. If you pull the door handle
while a door is opening or closing,
the door stops moving. If you pull the
door handle again, the door will open
f ully.
The dashboard switches to the lef t
of the steering column allow you to
open or close the power sliding doors.
The MAIN switch on the dashboard
controls power to the sliding doors.
Sliding Doors
Door Handles
Dashboard Switches
Inst rument s and Cont rols
143
POWER SLIDING DOOR MAIN SWITCH
POWER SLIDING
DOOR SWITCHES
