2005 CHRYSLER TOWN AND COUNTRY Owners Manual

STORAGE
Front Seat Storage Bin—If Equipped
The storage bin is located under the front passenger’s
seat. If equipped with a lock, it can be locked with the
ignition key.
Second Row Seat Storage bins—If Equipped
The Seat Storage Bins are located on the floor in front of
the second row seats, the area below the covers can be
used for storage when the second row seat is in the
upright position.
Pull up on the storage bin latch to open cover.
Front Seat Storage BinFold-in-Floor Stroage Bin
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177
3

WARNING!
In an accident, serious injury could result if the seat
storage bin covers are not properly latched. Do not
drive the vehicle with the storage bin cover open.
Keep the storage bin cover closed and latched while
the vehicle is in motion. Do not operate the storage
bin cover while the vehicle is in motion.
Overhead Rail System—If Equipped
The overhead rail system contains provisions for three
overhead storage bins.
CAUTION!
Do not load objects over 1.5 lbs (0.68 kg) in the
storage bins. Failure to follow this could cause
damage to the Overhead Rail System.
WARNING!
In a collision, you or others in your vehicle could be
injured if the storage bins are not properly latched to
the Overhead Rail System. Always be sure the
storage bins are fully latched.
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Removable Floor Console With Fold-in-Floor
Seating—If Equipped
The removable floor console has a two power outlets,
storage tray, light, removable cell phone holder, tissue
holder, pen holder and a map holder. It can be removed
from the vehicle by pulling the release handle inside the
floor console.
To remove the console use the following procedure:
1. Open the console lid and remove the storage tray.
2. Pull up on the release handle located inside the floor
console, and slide the console rearward to disengage
from the floor.
3. Remove the floor console.
Release Handle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179
3

To reinstall the console, open the console lid and remove
the storage tray. Pull up on the release handle and slide
the console forward to engage the front of the console
into the floor tray. Pivot the floor console down until it is
seated on the floor tray and release the handle. Pull up on
the console to be sure it is firmly attached.
WARNING!
In an accident, serious injury could result if the
removable floor console is not properly installed.
Always be sure the removable floor console is fully
latched.
Cell Phone Holder Removal
1. Open the floor console lid and lift the cell phone
holder upward.2. Squeeze the legs together to disengage the holder from
the floor console and remove the cell phone holder.
To reinstall the cell phone holder, align the pivot legs into
the guides and push forward to snap the legs into place.
Removable Floor Console Without Fold-in-Floor
Seating—If Equipped
The removable floor console has a power outlet, storage
tray, light, cell phone holder, tissue holder, and a map
holder. It can be placed between either the front seats or
middle seats.
NOTE:When the console is located between the front
seats the outlet is protected by an automatic circuit
breaker and is powered directly from the battery, items
plugged into this outlet may discharge the battery
and/or prevent engine starting.
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To remove the console use the following procedure:
1. Open the rear lid and remove the storage tray.
2. Pull up on the release handle located inside the floor
console to disengage the floor console, reinstall the
storage tray and close the rear lid.3. Using the front and rear grab handles, slide the
console rearward to disengage the front of the console
and lift up to remove the console from the floor.
4. Place the rubber mat on the floor tray.
Removable Floor ConsoleRelease Handle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181
3

To reinstall the console, remove the rubber mat and
relocate to the alternate floor tray, slide the console
forward to engage the front of the console into the floor
tray. Rapidly push down on the rear of the console with
enough force to engage the latch, you should hear the
latch“snap”into place. Pull up on the console to be sure
it is firmly attached.
WARNING!
In an accident, serious injury could result if the
removable floor console is not properly installed.
Always be sure the removable floor console is fully
latched.
NOTE:When the removable floor console is located
between the middle seats, the power outlet only has
power supplied to it when the ignition switch is ON.
Cell Phone Holder
1. Open the front lid and remove the cell phone holder
by pulling rearward and up on the lower edge of the
holder.
Cell Phone Holder
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

2. Plug in the power cord for the cellular phone into the
outlet located in the bottom of the forward console bin
and reinstall the cell phone holder.
3. Place the cell phone into the holder.CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not
in use (i.e. cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
•Accessories that draw higher power (i.e. coolers,
vacuum cleaners, lights, etc.), will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183
3

Rear Compartment Storage Bins
Your vehicle may be equipped with open storage bins
located in each rear trim panel or your vehicle may be
equipped with storage bins located under the armrest in
each rear trim panel.
Cargo/Tub Nets
Two cargo/tub nets are available on vehicles equipped
with Fold-in-Floor Seating. The cargo nets fit in the
second row storage bin and the third row tub. The nets
are supported by hooks located in these areas. Refer to
instructions provided in the net kit.
Cargo Area Storage
The seats in your vehicle are in-line which enables you to
stow long objects, such as lumber or skis, on the floor
without moving the seats.
NOTE:With all rear seat backs folded, a 4x8 foot sheet
of building material may be stored in the long-wheelbase
body style on top of the folded seats with the liftgate
closed. The front seats must be moved slightly forward of
the rearmost position. If the rear seats are removed no
front seat adjustment is needed and more than one 4x8
sheet of building material may be stored.
The liftgate sill plate has a raised line with the statement
“Load To This Line”. This line indicates how far rearward
cargo can be placed without interfering with liftgate
closing.
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
