2005 CHRYSLER TOWN AND COUNTRY buttons

Auto Unlock On Exit—If Equipped
The doors will unlock automatically on vehicles with
power door locks if:
1. The Auto Door Locks feature is enabled and the Auto
Unlock On Exit feature is enabled,
2. the transmission was in gear and the vehicle speed
returned to 0 mph (0 km/h),
3. the transmission is in NEUTRAL or PARK,
4. any door is opened (excluding liftgate) and
5. the vehicle speed is 0 mph (0 km/h).
The Auto Unlock On Exit feature can be enabled or
disabled by performing the procedure in the Electronic
Vehicle Information Center (EVIC), Customer Program-
mable Features section on vehicles so equipped.
NOTE:Use the Auto Door Locks and Auto Unlock
features in accordance with local laws.
REMOTE KEYLESS ENTRY—IF EQUIPPED
This system allows you to lock or unlock the doors and
liftgate, and activate the panic alarm, optional power
liftgate, left power sliding door, and right power sliding
door from distances up to about 23 feet (7 meters) using
a hand held radio transmitter. The transmitter need not
be pointed at the vehicle to activate the system.
NOTE:If the key is in the ignition switch, then all
buttons on that transmitter will be disabled. The buttons
on the remaining transmitters will work. If the vehicle is
shifted out of PARK, all the transmitter buttons are
disabled for all keys.
Two (2) transmitters may be supplied with the vehicle.
Vehicles built without the powered options will be
equipped from the factory with three button transmitters
and those built with power options will be equipped
with six button transmitters.
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To unlock the doors and liftgate:
Press and release the UNLOCK button on the transmitter
once to unlock the driver’s door side of the vehicle, or
twice to unlock all doors and liftgate. The illuminated
entry system also turns on.
The Remote Unlock Driver’s Door 1st feature can be
enabled or disabled by performing the following proce-
dure:
1. Press the UNLOCK button for 5 to 10 seconds.
2. While the UNLOCK button is pressed, (after 5 sec-
onds) press the LOCK button. Release both buttons.
The“Remote Unlock Driver’s Door 1st”feature can be
reactivated by repeating the above mentioned procedure
or by performing the procedure in the Electronic Vehicle
Information Center (EVIC), Customer Programmable
Features section on vehicles so equipped.
To lock the doors and liftgate:
Press and release the LOCK button on the transmitter to
lock all doors and liftgate. The horn will chirp once to
acknowledge the signal.
If desired, the“Sound Horn On Lock”feature can be
turned on and off by performing the following proce-
dure:
1. Press the LOCK button for 5 to 10 seconds.
2. While the LOCK button is pressed (after 5 seconds),
press the PANIC button. Release both buttons.
The“Sound Horn On Lock”feature can be reactivated by
repeating this procedure or by performing the procedure
in the Electronic Vehicle Information Center (EVIC),
Customer Programmable Features section on vehicles so
equipped.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

To Turn Off“Flash Lights On Lock/Unlock”—If
Equipped
If desired, the“Flash Lights On Lock/Unlock”feature
can be turned on and off by performing the following
procedure:
1. Press the LOCK button for 5 to 10 seconds.
2. While the LOCK button is pressed, (after 5 seconds)
press the UNLOCK button. Release both buttons.
The“Flash Lights On Lock/Unlock”feature can be
reactivated by repeating this procedure or by performing
the procedure in the Electronic Vehicle Information Cen-
ter (EVIC), Customer Programmable Features section on
vehicles so equipped. The table below explains the Lamp
Flash options.
Function Which Turn Signal
LampsNumber of
Flashes
Lock All 1
Unlock 1st
PressLeft Side 2
Unlock All
DoorsAll 2
Left Side Left Side 2
Right Side Right Side 2
Liftgate All 2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

General Information
This device complies with part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:
•This device may not cause harmful interference.
•This device must accept any interference received,
including interference that may cause undesired op-
eration.
If your Remote Keyless Entry transmitter fails to operate
from a normal distance, check for these two conditions.
1. A weak battery in the transmitter. The expected life of
the battery is a minimum of three years.
2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, and some mobile or CB radios.
Transmitter Battery Service
The recommended replacement battery is one CR2032
battery.
NOTE:Do not touch the battery terminals that are on
the back housing or the printed circuit board.
1. With the transmitter buttons facing down, use a thin
coin to pry the two halves of the transmitter apart. Make
sure not to damage the rubber gasket during removal.
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

NOTE:The driver’s side sliding door cannot be opened
while the fuel door is open. This feature operates only
when the sliding door is fully closed prior to opening the
fuel door.
Sliding Door Open Flash
When the sliding door(s) are opened, the left and right
exterior hazard lights will flash for 12 seconds to alert
other drivers in the area that passenger(s) could be
entering or exiting the vehicle.
The Sliding Door Open Flash can be enabled or disabled
by performing the following procedure:
1. Place the key in the ignition switch.
2. Cycle the ignition switch ON/OFF four times ending
in the OFF position. (do not start the engine)
3. Within 10 seconds of the final cycle, press the hazard
switch.4. A single chime will sound to signify that you have
successfully completed the programming.
You can turn the feature back on by repeating the above
mentioned procedure or by performing the procedure in
the Electronic Vehicle Information Center (EVIC), Cus-
tomer Programmable Features section on vehicles so
equipped.
Power Sliding Door—If Equipped
NOTE:The power sliding door must be unlocked before
the switches located on the trim panel, just in front of the
power sliding door will operate.
The power sliding door may be opened manually or by
using the buttons on the remote keyless entry transmitter.
Press the buttons on the remote keyless entry transmitter
twice within five seconds, to open a power sliding door.
Once the door is fully open, pressing the button twice
within five seconds a second time will close the door.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31
2

•The power liftgate must be in the full open or close
positions for any of the buttons to operate. If the
liftgate is not in the full open or close positions it must
be opened or closed manually.
•If the liftgate release button is activated while the
power liftgate is closing, the liftgate will reverse to the
full open position.
•The power liftgate buttons will not operate if the
vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).
•The power liftgate will not operate in temperatures
below
12°F(
24°C) or temperatures above 143°F
(62°C). Be sure to remove any build-up of snow or ice
from the liftgate before pressing any of the power
liftgate buttons.
•If the power liftgate encounters multiple obstructions
within the same cycle, the system will automatically
stop and must be opened or closed manually.
WARNING!
•Driving with the liftgate open can allow poison-
ous exhaust gases into your vehicle. You and your
passengers could be injured by these fumes. Keep
the liftgate closed when you are operating the
vehicle.
•If you are required to drive with the liftgate open,
make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode.
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

▫To Accelerate For Passing...............153

Overhead Console—If Equipped...........154
▫Courtesy/Reading Lights................154
▫Sunglass Storage......................155
▫Compass/Temperature Display...........155
▫Mini-Trip Computer...................158
▫Electronic Vehicle Information Center (EVIC)—
If Equipped.........................159
▫Customer Programmable Features—
If Equipped.........................160

Garage Door Opener—If Equipped.........163
▫Programming Homelink................164
▫Canadian Programming/Gate Programming . . 167
▫Using Homelink......................168▫Erasing Homelink Buttons...............168
▫Reprogramming a Single Homelink Button . . . 168
▫Security............................169

Power Sunroof—If Equipped.............169
▫Express Open Feature..................170
▫Wind Buffeting.......................171
▫Sunroof Maintenance...................171

Electrical Power Outlets—If Equipped.......172
▫Electrical Outlet Use With Engine Off.......173

Convenience Tray Drawer And Cup Holders . . . 174
▫Instrument Panel Cup Holders............174
▫Convenience Tray And Optional Smoker’s
Package Kit.........................175
▫Rear Cupholders......................175
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

The rearview mirror contains the microphone for the
system and the control buttons that will enable you to
access the system. The diagram below shows the mirror
with the appropriate buttons. Individual button behavior
is discussed in the“Operation”Section.
The UConnect™system can be used with any Hands
Free Profile certified Bluetooth™cellular phone. If yourcellular phone has a different profile (i.e. headset profile),
you will not be able to use any UConnect™features.
The UConnect™system is fully integrated into your
vehicle, including your vehicle’s stereo system. All voice
prompts as well as the other party’s voice in a conversa-
tion will be played over your vehicle’s stereo system. The
volume of the UConnect™system can be controlled
through your normal stereo controls.
The radio display will be used for visual prompts from
the UConnect™system such as caller ID.
Operation
Voice commands can be used in the operation of the
UConnect™system and to navigate through the UCon-
nect™menu structure. Voice commands should be given
after each UConnect™system prompt. You will be
prompted for a specific command and then guided
through the available options. There are two ways to give
commands to the UConnect™system:
UConnect™Switches
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97
