2005 CHRYSLER SEBRING SEDAN Owners Manual

Sunshade Operation
The sunshade can be opened manually. However, the
sunshade will open automatically as the sunroof opens.
NOTE:The sunshade cannot be closed if the sunroof is
open.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if so equipped) in certain
open or partially open positions. This is a normal occur-
rence and can be minimized. If the buffeting occurs with
the rear windows open, open the front and rear windows
together to minimize the buffeting. If the buffeting occurs
with the sunroof open, adjust the sunroof opening to
minimize the buffeting.
Sunroof Maintenance
Use only a non abrasive cleaner and a soft cloth to clean
the glass panel.
Sunroof Fully Closed
Press and hold the switch forward until the sunroof stops
completely to ensure that the sunroof is fully closed.
ELECTRICAL POWER OUTLET
The power outlet is located in the lower center of your
instrument panel. If your vehicle is equipped with heated
seats, a second power outlet is located inside the center
console. All accessories connected to any outlet should be
removed or turned off when the vehicle is not in use.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81
3

CAUTION!
Electrical Outlet Use With Engine Off
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not
in use (i.e., cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life
and/or prevent engine starting.
•Accessories that draw higher power (i.e., coolers,
vacuum cleaners, lights, etc.) will degrade the
battery even more quickly. Only use these inter-
mittently and with greater caution.
•After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
alternator to recharge the vehicle’s battery.
•Power outlets are designed for accessory plugs
only. Do not hang any type of accessory or acces-
sory bracket from the plug. Improper use of the
power outlet can cause damage.
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instruments And Controls.................87

Instrument Cluster Standard...............88

Instrument Cluster Premium...............89

Instrument Cluster Description.............90

Compass, Temperature, And Trip Computer
Display—If Equipped
...................95
▫Control Buttons.......................96
▫Trip Conditions........................96
▫Compass Temperature Display.............97

Cigar Lighter/Ashtray...................99

Electronic Digital Clock..................99
▫To Set The Clock......................100

Radio General Information...............100
▫Radio Broadcast Signals.................100
▫Two Types Of Signals..................100
▫Electrical Disturbances..................100
▫AM Reception.......................100
▫FM Reception........................100

Sales Code RAZ—AM/ FM Stereo Radio With
Cassette Tape Player, CD Player And CD
Changer Controls
......................101
▫Operating Instructions—Radio...........101
▫Power Switch, Volume Control............101
▫Seek Button (Radio Mode)...............101
4

▫Tuning.............................101
▫Radio Data System (RDS)...............101
▫PTY (Program Type) Button..............102
▫Balance............................103
▫Fade..............................103
▫Tone Control........................103
▫AM/FM Selection.....................103
▫Scan Button.........................103
▫To Set The Radio Push-Button Memory......104
▫To Change From Clock To Radio Mode......104
▫Operating Instructions—Tape Player.......104
▫Seek Button.........................104
▫Fast Forward (FF).....................105
▫Rewind (RW)........................105
▫Tape Eject...........................105
▫Scan Button.........................105▫Changing Tape Direction................105
▫Metal Tape Selection...................105
▫Pinch Roller Release...................105
▫Noise Reduction......................105
▫Operating Instructions—CD Player........106
▫Inserting The Compact Disc..............106
▫Seek Button.........................107
▫EJT CD (Eject) Button..................107
▫FF/Tune/RW........................107
▫Program Button 4 (Random Play)..........107
▫Mode..............................107
▫Tape CD Button......................108
▫Time Button.........................108
▫Scan Button.........................108
▫CD Changer Control Capability—
If Equipped.........................108
84 UNDERSTANDING YOUR INSTRUMENT PANEL

Sales Code RBB—AM/FM Stereo Radio With
Cassette Tape Player And CD Changer
Capability
...........................109
▫Radio Operation......................109
▫Mode Button........................111
▫Scan Button (Radio Mode)...............111
▫Cassette Player Features................112
▫CD Changer Control Capability—
If Equipped.........................113

Sales Code RBK—AM/ FM Stereo Radio
With CD Player And CD Changer Controls
...114
▫Radio Operation......................114
▫CD Player Operation...................116
▫CD Changer Control Capability—
If Equipped.........................118

Sales Code RB1—AM/FM Stereo Radio With
DVD/GPS Navigation System
............119

6 Disc CD Changer—If Equipped.........120
▫Loading The CD Changer...............120
▫Playing Discs........................121
▫Seek Button.........................121
▫FF/Tune/RW........................121
▫Mode Button........................121
▫Program Button 1.....................121
▫Program Button 4 (Random Play)..........121
▫Program Button 5.....................121
▫Time Button.........................122
▫Changing Modes......................122
▫Removing Discs From The CD Changer.....122
▫CD Changer Operation With The Changer
Off ...............................122
UNDERSTANDING YOUR INSTRUMENT PANEL 85
4

Remote Sound System Controls—
If Equipped
..........................122
▫Radio Operation......................123
▫Tape Player.........................123
▫CD Player—Single Disc In Radio.........124
▫CD Player—6 Disc CD Changer..........124

Cassette Tape And Player Maintenance......124

Compact Disc Maintenance...............125

Radio Operation And Cellular Phones.......126

Climate Controls......................126
▫Automatic Temperature Control (ATC)—If
Equipped...........................126
▫Manual Air Conditioning/Heater Control—If
Equipped...........................133
86 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENTS AND CONTROLS
UNDERSTANDING YOUR INSTRUMENT PANEL 87
4

INSTRUMENT CLUSTER STANDARD
88 UNDERSTANDING YOUR INSTRUMENT PANEL
