Cleaning Headlights
Your vehicle has plastic headlights that are lighter and
less susceptible to stone breakage than glass headlights.
Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with any commercial household-type glass cleaner.
Never use an abrasive type cleaner. Use caution whencleaning inside rear windows equipped with electric
defrosters. Do not use scrapers or other sharp instru-
ments which may scratch the elements.
Instrument Panel Cover
The instrument panel cover has a low glare surface which
minimizes reflections in the windshield. Do not use
protectants or other products which may cause undesir-
able reflections. Use soap and warm water to restore the
low glare surface.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in the vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft rag. A mild soap solution may be
used, but do not use high alcohol content of abrasive
cleaners. If soap is used, wipe clean with a clean damp
rag.
MAINTAINING YOUR VEHICLE 289
7

2. Dry with a soft tissue.
Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the
vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
CONVERTIBLE TOP CARE
Immediate removal of any contaminant is recommended.
Regular washing of the top will enhance its life and
appearance, and make successive cleanings easier. Do not
subject the top to excessive heat. Frequently vacuum the
top and storage compartment.
Washing
Hand washing is highly recommended. Automatic car
washing equipment can damage the top material. If you
must use an automatic car wash, soft cloth systems are
preferred.
CAUTION!
Avoid high pressure car washes, as they can damage
the top material. Also, increased water pressure may
force water past the weather strips.
General Cleaning
Careful vacuuming of the top before washing is helpful
in removing dust and other foreign particles. Wash in
partial shade instead of direct sun. Wet the entire vehicle
before washing the top. The top should be washed with
290 MAINTAINING YOUR VEHICLE

a soft, natural bristle scrub brush, and a mild soap
solution such as liquid dish washing soap. Do not use
detergent.
CAUTION!
Never use an abrasive type cleaner or bleaches.
Cleaners should not contain silicones, organic sol-
vents, petroleum distillates or plasticizers. always
wait until the top is thoroughly dry before lowering
it into the storage area.
Scrub in all directions, covering an area of about two
square feet at a time. Avoid heavy scrubbing. Rinse the
entire vehicle with water to remove all soap and dirt from
the top fabric and to prevent streaking on painted and
chrome surfaces. Allow the top to dry before lowering.
Vacuuming the top with a wet/dry shop vacuum will
decrease the top’s drying time, ensure removal of all dirt,and delete streaks in the material. Multiple cleanings
may be necessary to remove stubborn stains. If stains
persist, contact your local dealership for further sugges-
tions.
Cloth Top Additional Cleaning Procedure
For additional cleaning assistance in removing stubborn
stains, apply Mopar Convertible Cloth Top Cleaner #
4883061 to the complete stain, extending 2 inches (50
mm) beyond the stain. With a soft bristle brush, scrub in
all directions over the stain. Avoid heavy scrubbing.
Rinse the area with warm water. If the stain is still
apparent, repeat the cleaning procedure. When the stain
is no longer showing, rinse the complete top with warm
water. Let the top dry before lowering it.
MAINTAINING YOUR VEHICLE 291
7

Cloth Top Protection
For appearance purposes, you may wish to protect your
Twillfast™(cloth) top periodically. A fabric protectant
such as Scotchguardis suggested. The top should be
clean and dry before application of the protectant.
CAUTION!
Avoid getting Scotchguardon the surrounding
weather strips, moldings, paint, or glass. Damage to
these items might occur.
Weather Strip Care
Lubricate all top and door glass weather strips periodi-
cally with Mopar Weather Strip Lubricant (part number
4773427), to keep them soft and pliable.
FUSES
Underhood Fuses (Power Distribution Center)
A Power Distribution Center is located in the engine
compartment; next to the air cleaner filter. A label iden-
tifying the components and circuits is located on the
underside of the cover.
Power Distribution Center Location
292 MAINTAINING YOUR VEHICLE

Power Distribution Center
MAINTAINING YOUR VEHICLE 293
7

FUSE Amp/Color Items Fused
1 30 Amp/Pink Ignition Start
2 40 Amp/
GreenAnti-Lock Brake (ABS)
Pump
3 40 Amp/
GreenIgnition Run
4 30 Amp/Blue Heated Seats
5 40 Amp/
GreenRadiator Fan (Low Speed
Turbo only)
6 50 Amp/Red High Speed Radiator Fan
(Turbo Only)
7 30 Amp/Blue Anti-Lock Brake (ABS)
Solenoid
8 40 Amp/
GreenElectric Back Light (EBL)
9 40 Amp/
GreenPower Top10 40 Amp/
GreenIP Fuse Block
11 10 Amp/Red Air Conditioning (A/C)
12 15 Amp/Lt.
BlueStop Lights
13 20 Amp/
YellowFuel Pump/Auto Shut
Down (ASD)
14 15 Amp/Lt.
BlueHorn
15 20 Amp/
YellowElectronic Automatic
Transaxle (ETAX)
16
17 15 Amp/Lt.
BlueHi Beam
18 30 Amp/Blue Ignition Off Draw (IOD)
19 15 Amp/Lt.
BlueHazard Flasher
294 MAINTAINING YOUR VEHICLE

20 20 Amp/
YellowPower Outlets
21 Spare
22 20 Amp/
YellowFog Lamps (Export Only)
Interior Fuses
The fuse access panel is on the left side of the instrument
panel next to the steering column. To remove the panel,
pull it out, as shown. A label identifying the components
and circuits is located on the inside of the cover.
Interior Fuse Panel
MAINTAINING YOUR VEHICLE 295
7

FUSE Amp/Color Items Fused
1 25 Amp/
NaturalHeadlamp Switch
2 15 Amp/Lt.
BluePark Lamps
3 20 Amp/
YellowRKE/Door Locks
4 20 Amp/
YellowPower Height Adjust
5 10 Amp/Red Airbag Run Only
6 10 Amp/Red B/U Electric Back Light
(EBL) NEU SAF
7 25 Amp/
NaturalHVAC Blower
8 15 Amp/Lt.
BlueFog Lamp (Non BUX)
9 10 Amp/Red Airbag Run-ST10 10 Amp/Red Cluster/RKE/SKIM
11 10 Amp/Red Engine Module/ABS-
TRAC
12 10 Amp/Red PDC Relays/LDP
13 10 Amp/Red Interior Lighting
14 20 Amp/
YellowOverhead Console/Radio
15 20 Amp/
YellowWipers/Comb. FLS
16 10 Amp/Red Auto Stick/Ignition
17 15 Amp/Lt.
BlueHeated Seats
18 10 Amp/Red Heated Mirrors
19 10 Amp/Red Rt Headlamp
20 10 Amp/Red Lt Headlamp
296 MAINTAINING YOUR VEHICLE
