2005 CHRYSLER PT CRUISER Owners Manual

A new engine may consume some oil during its first few
thousand miles (kilometers) of operation. This should be
considered as a normal part of the break-in and not
interpreted as an indication of difficulty.
SAFETY TIPS
Exhaust Gas
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow the safety tips below.
Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in or
out of the area.If it is necessary to sit in a parked vehicle with the engine
running, adjust your heating or cooling controls to force
outside air into the vehicle. Set the blower at high speed.
WARNING!
If you are required to drive with the deck lid/liftgate
open, make sure that all windows are closed, and the
climate control blower switch is set at high speed.
DO NOT use the recirculation mode.
Safety Checks You Should Make Inside The
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57
2

Front seat belt assemblies must be replaced after a
collision. Rear seat belt assemblies must be replaced after
a collision if they have been damaged (bent retractor, torn
webbing, etc. If there is any question regarding belt or
retractor condition, replace the belt.
Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the LED is not lit during starting, have it
checked. If the light stays on or comes on while driving,
have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect tread and sidewall for cuts or
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil or other fluid leaks. Also, if gasoline
fumes are detected or fuel, power steering fluid or brake
fluid leaks are suspected, the cause should be located and
corrected immediately.
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS

Convertible Top Operation.................62
▫To Lower The Top......................62
▫To Raise The Top......................66
▫Convertible Top Boot Cover Installation–If
Equipped............................68
▫Convertible Top Boot Cover Removal And
Storage.............................72
▫Convertible Top Manual Override..........73

Mirrors...............................75
▫Inside Compass/Temperature Mirror........75▫Outside Mirror—Driver’s Side.............78
▫Outside Mirror—Passenger’s Side...........78
▫Electric Remote-Control Mirrors............79
▫Illuminated Vanity Mirrors................80

Seats.................................80
▫Front Seat Adjustment...................80
▫Driver’s Power Seat Height Adjuster—If
Equipped............................81
▫Reclining Bucket Seats...................82
3

▫Driver’s Seat Back Tilt...................82
▫Passenger Seat Back Tilt (Easy Entry System) . . .83
▫Adjustable Head Restraints...............85
▫Heated Seats—If Equipped..............86
▫Folding Rear Seat......................87
▫Tumbling Rear Seat.....................88

To Open And Close The Hood..............93

Lights................................94
▫Interior Lights........................94
▫Multi-Function Control Lever..............95
▫Headlights, Parking Lights, Instrument Panel
Lights..............................96
▫Daytime Running Lights (Canada Only)......96▫Lights-On Reminder....................96
▫Fog Lights...........................97
▫Turn Signals..........................97
▫Highbeam/Lowbeam Select Switch..........97
▫Passing Light.........................97

Windshield Wipers And Washers............98
▫Windshield Washers....................98
▫Mist Feature..........................98
▫Windshield Wiper Operation..............99
▫Intermittent Wiper System................99
▫Adding Washer Fluid..................100

Tilt Steering Column....................101

Traction Control Switch—If Equipped.......102
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Electronic Speed Control..................103
▫To Activate..........................103
▫To Set At A Desired Speed...............104
▫To Deactivate........................104
▫To Resume Speed.....................104
▫To Vary The Speed Setting...............104
▫Manual Transaxle.....................105
▫To Accelerate For Passing...............105

Garage Door Opener—If Equipped.........106
▫Programming The Universal Transceiver.....107
▫“Rolling Code”Programming............109▫Canadian Programming/Gate Programming . . 110
▫Operation...........................111
▫Reprogramming A Single Button..........111
▫Security............................111

Electrical Power Outlets..................112
▫Electrical Outlet Use With Engine Off.......114

Console Features.......................115

Storage..............................116
▫Front Seat Storage Bin..................116
▫Storage Pockets.......................117
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 61
3

CONVERTIBLE TOP OPERATION
WARNING!
The convertible top does not provide the structural
protection that a reinforced metal roof does, and the
fabric top cannot be expected to prevent the ejection
of the occupants of a vehicle in a collision. Therefore
it is important that all occupants wear their seat belts
at all times when riding in a convertible. Studies
have shown that it is generally safer to remain inside
a vehicle during a collision, than to be ejected from
the vehicle.
To Lower The Top:
NOTE:Thoroughly dry the convertible top and top
storage area, prior to leaving the top lowered for an
extended period of time. This will help prevent possible
mildew build-up.
CAUTION!
To avoid damage to the convertible top or its com-
ponents, your vehicle is equipped with a feature that
prevents convertible top operation at speeds over 10
mph (16 km/h).
62 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To fully insure that no damage occurs, be sure that
the vehicle is at a complete stop with the gear
selector in the Park position (automatic transaxle) or
in the Neutral position (manual transaxle) before
lowering or raising the top.
CAUTION!
Do not operate the convertible top with ice or snow
build-up on the top. Damage to the top may occur.
CAUTION!
To avoid damage to either the top or the rear win-
dow, check the top storage area at the rear of the
vehicle interior to be sure that it is clear of debris or
other items. Be sure that child seat flip up bars are
lowered. Do not use the top storage area for other
storage purposes.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 63
3

1. Turn the ignition key to the ON position.
2. Release the top from the windshield header by pulling
down on the latch handle and turning the latch handle
clockwise until it stops.3. Press the Power Top Switch to disengage the top pins
from the header, turn the handle counterclockwise and
raise the handle to the stowed position.
NOTE:The Power Top Switch has two detent positions
for lowering the convertible top. Pressing and holding
the Power Top Switch lightly in the first detent position
will lower the windows slightly and the convertible top
to the full down position. Pressing and holding the
switch in the second detent position will lower all four
windows completely and the top to the full down posi-
tion.
Releasing Convertible Top Latches
64 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
