When to Add Engine Oil
If the oil is below the cross-hatched area at the tip of the
dipstick, you will need to add at least one quart/liter of oil.
But you must use the right kind. This section explains
what kind of oil to use. For engine oil crankcase capacity,
seeCapacities and Speci cations on page 5-133.Notice:Do not add too much oil. If the engine
has so much oil that the oil level gets above the
cross-hatched area that shows the proper operating
range, the engine could be damaged.
SeeEngine Compartment
Overview on page 5-14
for the location of the
engine oil ll cap.
Be sure to add enough oil to put the level somewhere in
the proper operating range. Push the dipstick all the
way back in when you are through. All Except 8.1L Engine
8.1L Engine
5-21
Normal Maintenance Replacement Parts (Gasoline Engine)
Replacement parts identi ed below by name, part number, or speci cation can be obtained from your GM dealer.
If your vehicle has a diesel engine see the maintenance schedule section in the DURAMAX®Diesel Engine
Supplement.
Part GM Part Number ACDelco®Part Number
Engine Air Cleaner/Filter
High Capacity 25313349 A1518C
Standard 25313348* A1519C*
Oil Filter
4300 V6 25010792 PF47
4800 V8; 5300 V8; 6000 V8 88984215 PF46
8100 V8 25324052 PF454
Spark Plugs
4300 V6 25162556 41–932
4800 V8; 5300 V8; 6000 V8 12571164 41–985
8100 V8 12578277 41–983
Wiper Blades (ITTA Type)
22 inches (56.0 cm)15153642 —
*A1518C high-capacity air cleaner lter may be substituted.
6-17
