2005 BUICK CENTURY Owner's Manual

Instrument Panel Cluster
The instrument panel cluster is designed to let the driver know at a glance how the vehicle is running. It shows how
fast the vehicle is going, about how much fuel is in the fuel tank and many other things needed to drive safely
and economically.
United States version with Enhanced Traction System and ABS shown; Canada Base Level similar
3-29

Speedometer and Odometer
The speedometer shows the vehicle’s speed in both
miles per hour (mph) and kilometers per hour (km/h).
The odometer shows how far the vehicle has been
driven in either miles (used in the United States) or in
kilometers (used in Canada).
The vehicle has a tamper-resistant odometer. If ERROR
is displayed, this indicates someone has probably
tampered with it and the numbers may not be accurate.
You may wonder what happens if the vehicle needs
a new odometer installed. If the new one can be set to
the mileage total of the old odometer, then that will
be done. But if it cannot, then it will be set at zero and a
label must be put on the driver’s door to show the old
mileage reading when the new odometer was installed.
Trip Odometer
The trip odometer tells how far the vehicle has been
driven since it was last reset. To set the trip odometer to
zero, press the button on the right side of the instrument
panel cluster.
The trip/select reset button will go back and forth
between the odometer and the trip odometer if the
button is pressed and released within 1.5 seconds.If the button is pressed and held for longer than
1.5 seconds while in the trip odometer mode, it will be
reset to zero. If the button is pressed and held for longer
than 1.5 seconds while in the odometer mode, it will
have no effect.
Safety Belt Reminder Light
When the ignition key is turned to RUN or START,
a chime will come on for several seconds to remind
occupants to fasten their safety belts.
The safety belt light will
also come on and stay on
for several seconds, then it
will ash for several more.
If the driver’s belt is already buckled, neither the chime
nor the light will come on.
3-30

Airbag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows the air bag symbol. The system
checks the air bag’s electrical system for malfunctions.
The system check includes the air bag modules, the
wiring and the crash sensing and diagnostic module.
For more information on the air bag system, seeAirbag
System on page 1-49.
This light will come on
when the vehicle is
started, and it will ash for
a few seconds. Then
the light should go out.
This means the system is
functioning properly.
If the air bag readiness light stays on after the vehicle is
started, or comes on as the vehicle is being driven,
there may be an electrical problem and the air
bag system may not work properly. Have the vehicle
serviced right away.{CAUTION:
If the airbag readiness light stays on after you
start your vehicle, it means the airbag system
may not be working properly. The airbags in
your vehicle may not inate in a crash, or they
could even inate without a crash. To help
avoid injury to yourself or others, have your
vehicle serviced right away if the airbag
readiness light stays on after you start
your vehicle.
The air bag readiness light should ash for a few
seconds when you turn the ignition key to RUN. If the
light does not come on then, have it xed so it will
be ready to warn you if there is a problem.
3-31

Charging System Light
The charging system light
will come on briey when
the ignition is turned on,
as a check to show that it
is working. Then it should
go out.
If it stays on, or comes on while the vehicle is being
driven, there may be a problem with the charging
system. It could indicate that the vehicle has a loose
accessory belt or another electrical problem. Have
it checked right away. Driving while this light is on could
drain the battery.
If the vehicle must be driven a short distance with the
light on, be certain to turn off all the accessories,
such as the radio and air conditioner.
Brake System Warning Light
The vehicle’s hydraulic brake system is divided into two
parts. If one part is not working, the other part can
still work and stop the vehicle. For good braking, though,
you need both parts working well.
If the warning light comes on, there is a brake problem.
Have the brake system inspected right away.
This light should come on briey when the ignition
key is turned to RUN. If it does not come on then,
have it xed so it will be ready to warn you if there
is a problem.
United StatesCanada
3-32

When the ignition is on, the brake system warning light
will also come on when the parking brake is set.
The light will stay on if the parking brake does not
release fully. If it stays on after the parking brake is
fully released, it means there is a brake problem.
If the light comes on while the vehicle is being driven,
pull off the road and stop carefully. The pedal may
be harder to push, or it may go closer to the oor. It may
take longer to stop. If the light is still on, have the
vehicle towed for service. SeeTowing Your Vehicle on
page 4-36.
{CAUTION:
Your brake system may not be working
properly if the brake system warning light is
on. Driving with the brake system warning light
on can lead to an accident. If the light is still
on after you have pulled off the road and
stopped carefully, have the vehicle towed
for service.
Anti-Lock Brake System
Warning Light
If the vehicle has anti-lock brakes, this warning light will
come on for a few seconds when the ignition key is
turned to RUN. If the anti-lock brake system warning light
stays on longer than normal after the engine has been
started, turn the ignition off. Or, if the light comes on and
stays on while the vehicle is being driven, stop as soon as
possible and turn the ignition off. Then start the engine
again to reset the system. If the light still stays on, or
comes on again while driving, the anti-lock brake system
needs service. If the light is on and the regular brake
system warning light is not on, the vehicle still has brakes,
but it does not have anti-lock brakes.
The anti-lock brake system warning light will come on
briey when the ignition key is turned to RUN. This is
normal. If the light does not come on then, have it xed
so it will be ready to warn you if there is a problem.United States
Canada
3-33

Enhanced Traction System
Warning Light
If the vehicle has the
Enhanced Traction
System, (ETS) the warning
light may come on for
the following reasons:
When the vehicle is shifted to SECOND (2) or
FIRST (1). To turn the system back on, shift
to THIRD (3) or AUTOMATIC OVERDRIVE (
X).
SeeEnhanced Traction System (ETS) on page 4-9.
If the vehicle needs service. Adjust your
driving accordingly.
When the parking brake is set with the engine
running, and the parking brake does not release fully.
After the parking brake is fully released and the
transaxle shift lever is in any position other than
FIRST (1) or SECOND (2). This means there is a
problem with the system.
If an engine-related problem affects the ETS and
turns the system off.
When the ETS warning light is on, the system will not
limit wheel spin. Adjust your driving accordingly.
Low Traction Light
If the vehicle has the
Enhanced Traction System
(ETS), this light will
come on when the system
is limiting wheel spin.
You may feel or hear the system working, but this is
normal. Slippery road conditions may exist if the
low traction light comes on, so adjust your driving
accordingly. The light will stay on for a few seconds after
the ETS stops limiting wheel spin. SeeEnhanced
Traction System (ETS) on page 4-9.
The low traction light also comes on briey when the
ignition key is turned to RUN. If the light does not come
on then, have it xed so it will function properly to
indicate when the Enhanced Traction System is active.
3-34

Engine Coolant Temperature
Warning Light
This light indicates that
the engine coolant has
overheated or the radiator
cooling fan is not working.
The light will come on briey when the ignition is turned
on to show that it is working.
If the vehicle has been operating under normal driving
conditions, pull off the road, stop the vehicle and turn off
the engine as soon as possible. SeeEngine Overheating
on page 5-25.
Engine Coolant Temperature Gage
The vehicle has a gage
that shows the engine
coolant temperature. If the
gage pointer moves into
the red area, the engine
is too hot.
This reading indicates the same thing as the warning
light. It means that the engine coolant has overheated.
If the vehicle has been operating under normal
driving conditions, pull off the road, stop the vehicle and
turn off the engine as soon as possible. SeeEngine
Overheating on page 5-25.
3-35

Tire Pressure Light
The vehicle may have a
tire pressure monitor that
indicates a large change
in the pressure in one tire.
The system stores the tire pressures of the vehicle’s
properly inated tires. The LOW TIRE light will come on
if the pressure in one tire becomes 12 psi (83 kPa)
lower than the other three tires. The LOW TIRE light will
not come on if the pressure in more than one tire is
low, if the system is not yet calibrated, or if the vehicle
is moving faster than 70 mph (110 km/h).
When the LOW TIRE light comes on, stop as soon as
possible and check all the tires for damage. If a tire
is at, seeIf a Tire Goes Flat on page 5-69. Also check
the tire pressure in all four tires as soon as possible.
SeeInation - Tire Pressure on page 5-60.
The light will stay on, while the ignition is on, until the
system is reset. SeeTire Pressure Monitor System
on page 5-61.
Malfunction Indicator Lamp
Service Engine Soon Light
Your vehicle is equipped
with a computer which
monitors operation of the
fuel, ignition, and emission
control systems.
This system is called OBD II (On-Board Diagnostics
Second Generation) and is intended to assure that
emissions are at acceptable levels for the life of
the vehicle, helping to produce a cleaner environment.
The SERVICE ENGINE SOON light comes on and
a chime will sound to indicate that there is a problem
and service is required. Malfunctions often will be
indicated by the system before any problem is apparent.
This may prevent more serious damage to your
vehicle. This system is also designed to assist
your service technician in correctly diagnosing
any malfunction.
3-36
