Four transmitting antennae are distributed in the
vehicle and are used by the vehicle for radio
communication with the vehicle key. The antennae
transmit on a frequency of 24.5 kHz. The vehicle key
evaluates all four signals and determines the
position in or on the vehicle based on the field
strength of the individual antennae.
The antennae are located:
–in the rear doors
–in the centre console
–in the rear bumper
The start/stop button works in the same way as the
button module, which was first used in the A8 ‘03.
For safety reasons, the button positions are
evaluated both by the control unit for access and
start authorisation and by the switch for access and
start authorisation signal.
Antennae for access and start authorisation E134 - R138
Button for access and start authorisation E408
326_086 326_098
