2005 Acura RL display

µYour vehicle has a door monitor
indicator on the multi-inf ormation
display to indicate when a specif ic
door or the trunk is not tightly closed.
You will see the appropriate light/
lights and the message f or each
condition.
The f ollowing pages provide
instructions on how to properly
protect the driver, adult
passengers, and teenage children
who are large enough and mature
enough to drive or ride in the f ront.
See pages f or important
guidelines on how to properly
protect inf ants, small children, and
larger children who ride in your
vehicle.
Af ter everyone has entered the
vehicle, be sure the doors are
closed and locked.
When one or more doors are not
tightly closed, the ‘‘DOOR OPEN’’
indicator will stay on.When the trunk is not tightly closed,
the ‘‘TRUNK OPEN’’ indicator will
stay on.
36 40
CONT INUED
Introduction
Close and L ock the Doors
1.
Protecting A dults and Teens
Driver and Passenger Saf ety
13

Your seat belt system includes lap/
shoulder belts in all f ive seating
positions. The f ront seat belts are
also equipped with automatic seat
belt tensioners.The seat belt system
includes an indicator on the
instrument panel and a beeper to
remind you to f asten your seat belt.
If you turn the ignition to ON (II)
bef ore f astening your seat belt, the
beeper will sound and the indicator
will f lash. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator will stop f lashing but
remain on. To unlock the belt, press the red
PRESSbuttononthebuckle.Guide
the belt across your body so that it
retracts completely. Af ter exiting the
vehicle, be sure the belt is out of the
way and will not get closed in the
door.
All seat belts have an emergency
locking retractor. In normal driving,
the retractor lets you move f reely in
your seat while it keeps some
tension on the belt. During a collision
or sudden stop, the retractor
automatically locks the belt to help
restrain your body.
If you continue driving without
f astening your seat belt, the beeper
will sound and the indicator will f lash
again at regular intervals. You will
also see a ‘‘FASTEN SEAT BELT’’
message on the multi-inf ormation
display (see page ).
To fasten the belt, insert the latch
plate into the buckle, then tug on the
belt to make sure the buckle is
latched (see page f or how to
properly position the belt). The lap/shoulder belt goes over
your shoulder, across your chest,
and across your hips.
17
77
CONT INUED
Seat Belt System Components
L ap/Shoulder Belt
Additional Inf ormation About Your Seat Belts
Driver and Passenger Saf ety
21

CONT INUED
This indicator alerts you that the
passenger’s f ront airbag has been
shut of f because weight sensors
detect an inf ant or small child may
be in the f ront passenger’s seat. It
does there is a problem
with the airbag.
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-inf ormation display (see page
). This indicator alerts
you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
If you see any of these indications,
the airbags and seat belt tensioners
may not work properly when you
need them.
When you turn the ignition to ON
(II), the indicator should come on
brief ly and go out (see page ). If it
does not come on, stays on, or comes
on while driving without a passenger
in the f ront seat, you will also see a
‘‘PASSENGER SIDE AIRBAG OFF
SYSTEM’’ message on the multi-
information display. Have the system
checked (see page ).
76
61
77
Additional Inf ormation About Your Airbags
How the Passenger Airbag Of f
Indicator Works
How the Side Airbag Of f
Indicator Works
not mean
not
Driver and Passenger Saf ety
33
PASSENGER AIRBAG OFF INDICATOR
Canada
U.S.
Canada
U.S.
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.

This section gives inf ormation about
the controls and displays that
contribute to the daily operation of
your vehicle. All the essential
controls are within easy reach............................
Control Locations .58
............................
Instrument Panel .59
..........
Instrument Panel Indicators . 60
.............................................
Gauges .68
...................
Temperature Gauge . 68
..................................
Fuel Gauge .68
.............
Multi-Inf ormation Display . 69
Controls Near the Steering .........................................
Wheel .101
Windshield Wipers and .....................................
Washers .102
...................................
Turn Signal .104
....................................
Headlights .104
....................................
Fog Lights .106
Adaptive Front Lighting System .........................................
(AFS) .107
...............
Hazard Warning Button . 109
......
Instrument Panel Brightness . 109
...............
Rear Window Def ogger . 110
......
Steering Wheel Adjustments . 111
.............................
Keys and Locks .113
......................
Immobilizer System .114
..............................
Ignition Switch .115
....................................
Door Locks .116
..............................................
Trunk .117
......
Emergency Trunk Opener . 118................
Childproof Door Locks . 118
...............................................
Seats .119
...........................................
Mirrors .122
Driving Position Memory ........................................
System .124
................
Keyless Access System . 127
..................................
Seat Heaters .142
Seat Heaters and Seat .................................
Ventilation .143
............................
Power Windows .145
.......................................
Moonroof .147
...............................
Parking Brake .151
.........
Interior Convenience Items . 152
..................................
Glove Box .153
.....................
Beverage Holders .154
.............
Console Compartment . 155
..................................
Sun Visors .156
........
Accessory Power Sockets . 156
...........................
Rear Ashtrays .157
..................
Front Door Pockets . 157
..............
Power Rear Sunshade . 158
..............
Integrated Sunshades . 159
...............................
Interior Lights .160
Instruments and Controls
Inst rument s and Cont rols
57

Î
Î
Î
The U.S. instrument panel is shown. Dif f erences f or the Canadian models are noted in the text.
:
Instrument Panel
Inst rument s and Cont rols
59
CHARGING SYSTEM
INDICATOR
LOW OIL
PRESSURE
INDICATOR VEHICLE STABILITY ASSIST (VSA)
SYSTEM INDICATOR
LIGHTS ON INDICATOR FOG LIGHT
INDICATOR
LOW TIRE PRESSURE
INDICATORANTI-LOCK BRAKE
SYSTEM INDICATOR
VSA
ACTIVATION
INDICATOR
KEYLESS ACCESS
SYSTEM INDICATOR
SIDE AIRBAG OFF
INDICATOR
SECURITY
SYSTEM
INDICATOR
PARKING BRAKE AND
BRAKE SYSTEM
INDICATOR
SEAT BELT REMINDER
INDICATOR
CRUISE MAIN INDICATOR
ADAPTIVE FRONT LIGHTING
(AFS) SYSTEM INDICATOR
(P.66)
(P.60, 348)
(P.64)
(P.60, 348)
(P.60,349)
(P.65,272)
(P.69)(P.64)
(P.65, 277)
(P.62)(P.21,
60)(P.61,
350)
(P.62,
275)(P.67,
107)
(P.
64)
(P.63,
281)
(P.66)
(P.67) (P.63,
281)
(P.64)
(P.62)
(P.33,61)
(P. 66)
MESSAGE INDICATOR
MALFUNCTION INDICATOR
LAMP SH-AWD INDICATOR
MULTI-INFORMATION
DISPLAY HIGH BEAM INDICATOR
LOW FUEL INDICATOR
IMMOBILIZER SYSTEM
INDICATORSUPPLEMENTAL RESTRAINT SYSTEM
INDICATOR
(P.32,
61)
ELECTRONICALLY
CONTROLLED
POWER STEERING
SYSTEM (ECPS)
INDICATOR

The instrument panel has many
indicators to give you important
inf ormation about your vehicle. This indicator comes on when youturn the ignition switch to ON (II). It
reminds you and your passengers to
f asten your seat belts. A beeper also
sounds if you have not f astened your
seat belt.
If you turn the ignition switch to ON
(II) bef ore f astening your belt, the
beeper sounds and the indicator
f lashes. If you do not f asten your
seat belt bef ore the beeper stops, the
indicator stops f lashing but remains
on.
You will also see a ‘‘CHECK
EMISSION SYSTEM’’ message on
the multi-information display. For
more information, see page . The engine can be severely damaged
if this indicator f lashes or stays on
when the engine is running, or if a
‘‘CHECK ENGINE OIL LEVEL’’
message is on the multi-inf ormation
display. For more inf ormation, see
page .
If this indicator comes on when the
engine is running, the battery is not
being charged, and you will also see
a ‘‘CHECK CHARGING SYSTEM’’
message on the multi-information
display. For more inf ormation, see
page .
If you continue driving without
f astening your seat belt, the beeper
sounds and the indicator f lashes
again at regular intervals, and you
will also see a ‘‘FASTEN SEAT
BELT’’ message on the multi-
inf ormation display (see page ). 348
348 349
77
Instrument Panel Indicators
Seat Belt Reminder
Indicator
L ow Oil Pressure
Indicator
Charging System
Indicator
Malf unction Indicator
Lamp
60

This indicator has two f unctions:Itcomesonwhenyouturnthe
ignition switch to ON (II). It is a
reminder to check the parking
brake. Driving with the parking
brake not f ully released can
damage the rear brakes, axles, and
tires.
If you drive without releasing the
parking brake, a chime will sound,
and you will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ).
If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, it can
indicate a problem in the brake system. You will also see a
‘‘BRAKE FLUID LOW’’ or
‘‘CHECK BRAKE SYSTEM’’
message on the multi-inf ormation
display (see page ). For more
inf ormation, see page .
This indicator comes on brief ly when
you turn the ignition switch to ON
(II). If it comes on at any other time,
it indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
automatic seat belt tensioners, or
side curtain airbags. You will also see
a ‘‘CHECK AIRBAG SYSTEM’’
message on the multi-inf ormation
display (see page ). For more
inf ormation, see page . This indicator comes on when you
turn the ignition switch to ON (II). If
it comes on at any other time, it
indicates that the passenger’s side
airbag has automatically shut off.
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-inf ormation display (see page
). For more inf ormation, see
page .
1.
2. 76
350
76 7632 33
77
Instrument Panel Indicators
Parking Brake and Brake System
Indicator Side Airbag Of f Indicator
Supplemental Restraint
System Indicator
Inst rument s and Cont rols
61
U.S. Canada U.S. Canada

This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either theor position. This indicator
will also come on when the light
switch is in AUTO and the lights
turn on automatically. If you turn the
ignition switch to ACCESSORY (I)
or LOCK (0) without turning of f the
light switch, this indicator will
remain on. A reminder chime will
also sound when you open the driver’s
door. This indicator comes on f or a f ew
seconds when you turn the ignition
switch to ON (II). It will then go of f
if you have a properly-coded remote.
If it is not a properly-coded remote,
the indicator will blink and the
engine will not start (see page ).
If you use the remote, this indicator
blinks several times when you turn
the ignition switch from
ACCESSORY (I) to LOCK (0).
If you use the built-in key, this
indicator blinks several times when
you turn the ignition switch f rom ON
(II) to ACCESSORY (I).This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to ON (II), and when
the ignition switch is turned to
START (III). If this indicator comes
on at any other time, there is a
problem in the ABS. If this happens,
take the vehicle to your dealer to
have it checked. With this indicator
on, your vehicle still has normal
braking ability but no anti-lock
f unction. You will also see a
‘‘CHECK ABS SYSTEM’’ message
on the multi-information display (see
page ). For more inf ormation, see
page .
275
114
76
Instrument Panel Indicators
Lights On Indicator Immobilizer System
IndicatorAnti-lock Brake System
(A BS) Indicator
62
