2004 TOYOTA TACOMA Owners Manual (in English)

’04 Tacoma U (L/O 0309)
89
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
3. While pressing the convertible seatfirmly against the seat cushion and
seatback, let the shoulder belt retract
as far as it will go to hold the convert-
ible seat securely.CAUTION
Push and pull the child restraint sys-
tem in different directions to be sure
it is secure. Follow all the installation
instructions provided by its manufac-
turer.
4. To remove the convertible seat, pressthe buckle release button and allow the
belt to retract completely. The belt will
move freely again and be ready to
work for an adult or older child passen-
ger.

’04 Tacoma U (L/O 0309)
90
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
(C) BOOSTER SEAT INSTALLATION
A booster seat must be used in for-
wardfacing position only.
Move seat
fully back
CAUTION
A forwardfacing child restraint sys-
tem should be allowed to be installed
on the front passenger seat only
when it is unavoidable. Always move
the seat as far back as possible, be-
cause the front passenger airbag
could inflate with considerable speed
and force. Otherwise, the child may
be killed or seriously injured.
1. Sit the child on a booster seat. Runthe lap and shoulder belt through or
around the booster seat and across the
child following the instructions provided
by its manufacturer and insert the tab
into the buckle taking care not to twist
the belt.
Make sure the shoulder belt is correctly
across the child’s shoulder and that the
lap belt is positioned as low as possible
on child’s hips. See “Seat belts” in this
Section for details.

’04 Tacoma U (L/O 0309)
91
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
CAUTION
Always make sure the shoulder belt
is positioned across the center of
child’s shoulder. The belt should be
kept away from child’s neck, but
not falling off child’s shoulder.
Otherwise, the child may be killed
or seriously injured in case of sud-
den braking or a collision.
Both highpositioned lap belts and
loosefitting belts could cause
death or serious injuries due to
sliding under the lap belt during a
collision or other unintended event.
Keep the lap belt positioned as low
on a child’s hips as possible.
For child’s safety, do not place the
shoulder belt under child’s arm.
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent your
child from properly latching the tab
and buckle.
If the seat belt does not function
normally, it cannot protect your
child from death or serious injury.
Contact your Toyota dealer immedi-
ately. Do not install the child
restraint system on the seat until
the seat belt is fixed.
2. To remove the child restraint system, press the buckle release button and
allow the belt to retract.

’04 Tacoma U (L/O 0309)
92
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Regular cab with bench seat
Regular cab with separate seats
Double cab with rear seats
Follow the procedure below for a child
restraint system that requires the use
of a top strap.
Anchor
brackets
Regular cab with bench seat
Anchor
bracket
Regular cab with separate seats
— U sin g a to p st rap
(regular
and double cab
models)

’04 Tacoma U (L/O 0309)
93
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Anchor
brackets
Double cab with rear seats
Use the anchor bracket on the back panel
to attach the top strap.
Regular cab models— Anchor brackets are installed for (each)
passenger seating position.
Double cab models— Anchor brackets are installed for each
rear seating position.
TO USE THE ANCHOR BRACKET:
Regular cab with bench seat—
1. Pull the seatback release lever and swing the seatback forward slightly,
then latch the hook onto the anchor
bracket.
Return the seatback to its original
position.2. Fix the child restraint system withthe seat belt and tighten the top
strap.
For instructions on installing the child re-
straint system, see “Child restraint” in this
Section.

’04 Tacoma U (L/O 0309)
94
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
CAUTION
When returning the seatback to its
original position, make sure the
seatback is securely locked by
pushing forward and rearward on
the top of the seatback.
Make sure the top strap is securely
latched, and check that the child
restraint system is secure by push-
ing and pulling it in different direc-
tions. Follow all the installation in-
structions provided by its manufac-
turer.
Regular cab with separate seats—1. Remove the passenger head re- straint.2. Pull the seatback release lever andswing the seatback forward slightly,
then latch the hook onto the anchor
bracket.
Return the seatback to upright posi-
tion.

’04 Tacoma U (L/O 0309)
95
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
3. Fix the child restraint system withthe seat belt and tighten the top
strap.
Replace the passenger head re-
straint.
For instructions on installing the child re-
straint system, see “Child restraint” in this
Section.
CAUTION
When returning the seatback to its
original position, make sure the
seatback is securely locked by
pushing forward and rearward on
the top of the seatback.
Make sure the top strap is securely
latched, and check that the child
restraint system is secure by push-
ing and pulling it in different direc-
tions. Follow all the installation in-
structions provided by its manufac-
turer.
Double cab with rear seats— 1. Remove the head restraint (outside position only).

’04 Tacoma U (L/O 0309)
96
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
2. Pull the seatback release lever andswing the seatback forward slightly,
then latch the hook onto the anchor
bracket.
Return the seatback to upright posi-
tion.3. Fix the child restraint system withthe seat belt and tighten the top
strap.
Replace the head restraint (outside
position only).
For instructions on installing the child re-
straint system, see “Child restraint” in this
Section.
CAUTION
When returning the seatback to its
original position, make sure the
seatback is securely locked by
pushing forward and rearward on
the top of the seatback. Failure to
do so will prevent the seat belt
from operating properly.
Make sure the top strap is securely
latched, and check that the child
restraint system is secure by push-
ing and pulling it in different direc-
tions. Follow all the installation in-
structions provided by its manufac-
turer.
