2004 TOYOTA TACOMA Owners Manual (in English)

’04 Tacoma U (L/O 0309)
97
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Front outside position
Front center position
Rear outside position
Follow the procedure below for a child
restraint system that requires the use
of a top strap.
Routing
device
Upper
anchor bracket
Lower anchor
bracket Symbol mark
Use the routing device and the anchor
bracket to attach the top strap.
Upper anchor bracket is installed for
right
−front passenger ’s seating position,
lower anchor bracket is installed for front
center seating position (with split bench
seat) or right −rear seating position.
This symbol indicates the locations of
user ready anchor bracket.
— U sin g a to p st rap
(xtracab models)

’04 Tacoma U (L/O 0309)
98
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Symbol mark
TO USE THE ANCHOR BRACKET:
Front outside position—1. Remove the passenger head re- straint.
Lightly push down on the top sur-
face of the anchor bracket cover
with the symbol mark shown in the
illustration, then pull it forward to
remove.2. Fix the child restraint system withthe seat belt.
Latch the hook onto the anchor
bracket on the back panel and tight-
en the top strap.
For instructions on installing the child re-
straint system, see “Child restraint” in this
Section.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
Follow all the installation instructions
provided by its manufacturer.

’04 Tacoma U (L/O 0309)
99
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
3. Replace the head restraint.
Store the removed cover in a safe place
such as the glove box.
Be sure to replace the cover when the
anchor bracket is not in use.Front center position—
Fix the child restraint system with the
seat belt.
Latch the hook onto the rear lower an-
chor bracket and tighten the top strap.
For instructions on installing the child re-
straint system, see “Child restraint” in this
Section.
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
Follow all the installation instructions
provided by its manufacturer.

’04 Tacoma U (L/O 0309)
100
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Symbol mark
Rear outside position—1. Lightly push down on the top sur- face of the anchor bracket cover
with the symbol mark shown in the
illustration, then pull it forward to
remove.
Routing
device
2. Fix the child restraint system withthe seat belt.
Route the top strap through the
routing device as shown in the il-
lustration.
For instructions on installing the child re-
straint system, see “Child restraint” in this
Section.
CAUTION
Make sure the top strap is not
twisted.
3. Latch the hook onto the rear lower anchor bracket and tighten the top
strap.
Store the removed cover in a safe place
such as the glove box.
Be sure to replace the cover when the
anchor bracket is not in use.

’04 Tacoma U (L/O 0309)
101
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
CAUTION
Make sure the top strap is securely
latched, and check that the child re-
straint system is secure by pushing
and pulling it in different directions.
Follow all the installation instructions
provided by its manufacturer.
Separate seats
Split bench seats
Nonsplit bench seat
Lower anchorages for the child restraint
systems complying with the FMVSS225
or CMVSS210.2 specifications are
installed in the right passenger ’s seat-
ing position.
Child restraint systems complying with the
FMVSS225 or CMVSS210.2 specification
can be fixed to these anchorages. In this
case, it is not necessary to fix the child
restraint system with a seat belt on the
vehicle.
—Installation with child
restraint lower anchorages
(regular cab and xtracab models)

’04 Tacoma U (L/O 0309)
102
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Canada only
Ty p e ACanada only
Ty p e B
For owners in Canada
The symbol on a child restraint system
indicates the presence of a lower connec-
tor system.
CHILD RESTRAINT SYSTEM
INSTALLATION
Ty p e A — 1. Widen the clearance between the seat cushion and seatback a little
and confirm the position of the low-
er anchorages near the tag on the
seatback.
2. Latch the hooks of lower straps onto the anchorages and tighten the lower
straps.
Ty p e B — 1. Widen the clearance between the seat cushion and seatback a little
and confirm the position of the low-
er anchorages near the tag on the
seatback.
2. Latch the buckles onto the anchor- ages.
If your child restraint system has a top
strap, it should be anchored. (For the
installation of the top strap, see “—Using
a top strap” in this Section.)

’04 Tacoma U (L/O 0309)
103
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
For the installation details, refer to the
instruction manual equipped with each
product.
CAUTION
When using the lower anchorages
for the child restraint system, be
sure that there are no irregular ob-
jects around the anchorages or that
the seat belt is not caught.
Push and pull the child restraint
system in different directions to be
sure it is secure. Follow all the
installation instructions provided by
its manufacturer.
After securing the child restraint
system, never slide or recline the
seat.
Vehicles with passenger airbag
manual onoff switch—
Child restraint system should never
be installed on the front passenger
seat with the passenger airbag
manual onoff switch in the “ON”
position, because the force of the
deploying airbag could cause death
or serious injury to the child in for-
ward seating position.
Lower anchorages for the child restraint
systems complying with the FMVSS225
or CMVSS210.2 specifications are
installed in the outside positions of the
rear seat.
Child restraint systems complying with the
FMVSS225 or CMVSS210.2 specification
can be fixed with these anchorages. In
this case, it is not necessary to fix the
child restraint system with a seat belt on
the vehicle.
Canada only
Ty p e A
—Installation with child
restraint lower anchorages
(double cab models)

’04 Tacoma U (L/O 0309)
104
2004 TACOMA from Sep. ’03 Prod. (OM35814U)
Canada only
Ty p e B
For owners in Canada
The symbol on a child restraint system
indicates the presence of a lower connec-
tor system.
CHILD RESTRAINT SYSTEM
INSTALLATION
Ty p e A — 1. Widen the clearance between the seat cushion and seatback a little
and confirm the position of the low-
er anchorages near the tag on the
seatback.
2. Latch the hooks of lower straps onto the anchorages and tighten the lower
straps.
Ty p e B — 1. Widen the clearance between the seat cushion and seatback a little
and confirm the position of the low-
er anchorages near the tag on the
seatback.
2. Latch the buckles onto the anchor- ages.
If your child restraint system has a top
strap, it should be anchored. (For the
installation of the top strap, see “—Using
a top strap” in this Section.) For the installation details, refer to the
instruction manual equipped with each
product.
CAUTION
When using the lower anchorages
for the child restraint system, be
sure that there are no irregular ob-
jects around the anchorages or that
the seat belt is not caught.
Push and pull the child restraint
system in different directions to be
sure it is secure. Follow all the
installation instructions provided by
its manufacturer.
After securing the child restraint
system, never recline the seat.
Do not install a child restraint sys-
tem on the rear seat if it interferes
with the lock mechanism of the
front seats. Otherwise, the child or
front seat occupant(s) may be killed
or seriously injured in case of sud-
den braking or a collision.
