Page 459 of 491
11 - 7 4
Maintenance and service
!
Rear combination lights
! Sedan
1. Remove the clip from the rear trunk trim with a reg-
ular screwdriver. 1) Backup light
2) Rear turn signal light
3) Brake light
4) Tail light
5) Brake/tail light
2. Open the rear portion of the side trunk trim panel.
3. Remove the bulb holder from the rear combination
light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it and
turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Secure the rear trunk trim panel with the clips.
UGB538BA
554
2
3
1
UGB539BB
Page 461 of 491
11 - 7 6
Maintenance and service
1) Tail/brake light
2) Rear turn signal light
3) Backup light
3. Remove the bulb holder from the rear combination
light assembly by turning it counterclockwise.
4. Remove the bulb from the socket by pushing it and
turning counterclockwise. Install a new bulb.
5. Set the bulb holder into the rear combination light
assembly and turn it clockwise until it locks.
6. Close the cover and latch the lock.
7. Reinstall the rear combination light assembly and
its side cover. !
License plate light
1. Remove the mounting screws using a phillips
screwdriver.
2. Remove the cover and lens.
3. Pull the bulb out of the socket. Install a new bulb.
4. Reinstall the lens and cover.
5. Tighten the mounting screws.
2
1
3
UGB542BB
UGB543BA
Page 464 of 491
11 -7 9
Maintenance and service
– CONTINUED –
!Wagon
1. Remove the mounting screw covers by prying the
edge with a screwdriver.
2. Remove the mounting screws using a phillips
screwdriver and then remove the high mount stop light cover.
3. Remove the bulbs from the socket by pushing it
and turning counterclockwise. Install a new bulb.
4. Reinstall the cover.
5. Tighten the mounting screws then reinstall the cov- ers.
NOTE
Other bulbs may be difficult to replace. Have your SUBARU dealer replace these bulbs if necessary.
HSB091BA
Page 473 of 491
12-8
Specifications
!
Fuse panel located in the engine com-
partment
A) FWD socket (AT models except Turbo)
B) Main fuse
A 12
3 B
4
5 6
78
91011
12
HSC002BB
Fuse panelFuse ratingCircuit
120A"
Radiator cooling fan
(Main)
220A"Radiator cooling fan
(Sub)
330A"ABS motor
420A"Rear window defogger
515A"Hazard warning flasher
" Horn
615A"Turn signal lights
710A"Automatic transmis- sion control unit
810A"Alternator
915A"Headlight (right side)
1015A"Headlight (left side)
1120A"Lighting switch
1215A"Clock
" Interior light
Page 482 of 491

14-3
Index
Cargo
Area cover ................................................................ 6-15
Area light ......................................................... 6-2, 11-77
Tie-down hooks ...................................................... 6-17
Catalytic converter ...................................................... 8-4
Center Console ..................................................................... 6-6
Ventilators ................................................................. 4-3
Visor ............................................................................ 6-4
Changing
Flat tire ....................................................................... 9-5
Oil and oil filter ........................................................ 11-12
Charge warning light .................................................. 3-21
CHECK ENGINE warning light/ Malfunction indicator lamp ..................................3-20
Checking
Brake pedal free play ........................................... 11-40
Brake pedal reserve distance ...........................11-41
Clutch function ........................................................ 11-41
Clutch pedal free play .......................................... 11-42
Engine oil level ....................................................... 11-11
Fluid level ....................... 11-31, 11-36, 11-37, 11-38
Gear oil level ................................ 11-28, 11-33, 11-34
Child restraint systems ............................................... 1-31
Installation with seatbelt .....................................1-35
Lower and tether anchorages ..........................1-42
Child safety .................................................................... 6Locks
.......................................................................... 2-21
Chime
Key .............................................................................. 3-4
Seatbelt ........................................................... 1-15, 3-19
Cigarette lighter socket ............................................. 6-10
Cleaning Aluminum wheels .................................................. 10-3
Interior ........................................................................ 10-6
Ventilator grille ........................................................ 4-19
Climate control system
Manual ....................................................................... 4-4
Semi-automatic ...................................................... 4-11
Clock ................................................................................. 3-28
Clutch fluid ...................................................................... 11-38
Clutch pedal ................................................................... 11-41
Coat hook ....................................................................... 6-14
Coin tray .......................................................................... 6-7
Cooling system ............................................................. 11-18
Corrosion protection ......................................... 8-14, 10-4
Cruise control ................................................................ 7-37
Indicator light ........................................................... 3-26
Set indicator light ................................................... 3-26
Cup holder ...................................................................... 6-7
D
Daytime running light system .................................3-31
Differential gear oil
