Minor Repairs
325
Battery chargingAutomotive batteries loose their efficiency when
not in use. The charge available in your battery can
be measured with a battery hydrometer. We
recommend that the battery voltage be tested by
your Porsche dealer who has the appropriate
equipment.
If the car is not driven for prolonged periods, the
battery must be charged at least every 6 weeks.
A discharged battery allows rapid formation of sul-
fates, leading to premature deterioration of the
plates.
Danger!
Hydrogen gas generated by the battery
could cause an explosion, resulting in
serious personal injury or death.
fCharge battery in a well ventilated area.
fNever charge a frozen battery. It may explode
because of gas trapped in the ice. Allow a fro-
zen battery to thaw out first.
fIf you get electrolyte, which is an acid, in your
eyes or on your skin, immediately rinse with
cold water for several minutes and call a doc-tor.Note
Your authorized Porsche dealer will be pleased to
advise you about a suitable charger.
fAlways observe the instructions of the charger
manufacturer.
fWhen charging the battery, ensure adequate
ventilation.
1. Check the acid level of a low-maintenance
battery.
2. Connect charger to the jump starting points.
Only plug into the mains and switch the
charger on when it has been correctly
connected up.
3. Switch on the charger.
4. After charging, switch off and disconnect the
charger.
5. Check the acid level of a low-maintenance
battery.
After charging the battery After the battery is connected or the completely
discharged battery is charged, the PSM warning
light lights up on the instrument panel and a
message appears on the multi-purpose display of
the instrument panel to indicate a fault.
This fault can be remedied with a few simple
steps:
1. Start the engine.
To do this, turn the ignition key or the control
unit (on vehicles that have Porsche Entry &
Drive) to ignition lock position 2 twice.
2. Perform a few steering movements to the left
and to the right when vehicle is standing and
drive a short distance in a straight line until the
PSM warning light goes out and the message
is erased from the memory of the multi-
purpose display of the instrument panel.
3. If the warnings does not go out, then:
Drive carefully to the nearest authorized
Porsche dealer.
Have the fault remedied by an authorized
Porsche dealer.
10_Cayenne_21_KW17.book Seite 325 Donnerstag, 9. April 2009 3:33 15

Tire Pressure and Technical Data
359
CapacitiesUse only fluids and fuels authorized by Porsche. Your authorized Porsche dealer will be pleased to advise you.
Your Porsche has been designed so that it is not necessary to mix any additives with oils or fuels.
CayenneCayenne S,
Cayenne GTS,
Cayenne S TranssyberiaEngine oil change quantity without oil filter
approx. 6.34 quarts (6.0 liters)
approx. 9.0 quarts (8.5 liters)
Engine oil change quantity with oil filter approx. 7.29 quarts (6.9 liters) approx. 9.51 quarts (9.0 liters)
Reference indication is the level on the oil dipstick.
Please see the chapter “CHECKING ENGINE OIL LEVEL” on Page 252.
Coolant, depending on equipment level
approx. 3.4 – 4.8 U.S. gallons (13 – 18 liters)
approx. 4.8 – 5.5 U.S. gallons (18 – 21 liters)
Manual transmission with compensation approx.1.9quarts (1.8 litres) approx.1.9 quarts (1.8 litres)
Automatic transmission with torque converter
approx. 10.04 quarts (9.5 liters)
approx. 9.51 quarts (9.0 liters)
Transfer box approx. 0.9 quarts (0.85 liter) approx. 0.9 quarts (0.85 liter)
Front-axle differential
approx. 1.1 quarts (1.0 liter)
approx. 1.1 quarts (1.0 liter)
Rear-axle differential approx. 1.3 quarts (1.25 liters) approx. 1.5 quarts (1.4 liters)
Locking rear differential
approx. 1.7 quarts (1.6 liters)
approx. 1.7 quarts (1.6 liters)
Fuel tankapprox. 26.4 U.S. gallons (100 liters),
including approx. 3 U.S. gallons (12 liters) reserveapprox. 26.4 U.S. gallons (100 liters),
including approx. 3 U.S. gallons (12 liters) reserve
Fuel quality
The engine is designed to provide optimum performance and fuel consumption if unleaded premium fuel with
98 RON/88 MON is used.
If unleaded premium fuels with octane numbers of at least 95 RON/85 MON are used, the engine's “Electronic
Oktane™ knock control“ automatically adapts the ignition timing.
Power steering
approx. 1.6 quarts (1.5 liters) Pentosin CHF 202 S
®approx. 1.6 quarts (1.5 liters) Pentosin CHF 202 S
®
Brake fluid
approx. 1.0 quart (0.95 liter)
Use only Original Porsche brake fluid.
approx. 1.0 quart (0.95 liter)
Use only Original Porsche brake fluid.
Window/headlight washer system approx. 7.9 quarts (7.5 liters) approx. 7.9 quarts (7.5 liters)
10_Cayenne_21_KW17.book Seite 359 Donnerstag, 9. April 2009 3:33 15

364
Index
Belt tensioner
Functional description
....................................... 42
Belts
...................................................................... 42Adjusting belt height
......................................... 44
Belt tensioner functional description
.................... 42
Care instructions
........................................... 278
Fastening
....................................................... 43
Opening
......................................................... 44
Warning light
................................................... 53
Warning light on the tachometer
......................... 43
Bi-xenon
................................................................ 330Changing bulb for additional high beam
............. 331
Changing bulb for cornering light
...................... 332
Changing gas-discharge headlight
.................... 330
Installing headlights
........................................ 328
Removing headlights
...................................... 327
Brake booster
........................................................ 165
Brake booster faulty warning message
....................... 154
Brake fluid
Change quantity
............................................ 359
Changing
..................................................... 258
Checking level
............................................... 257
Warning light on speedometer
......................... 258
Warning message on multi-purpose display
........ 153
Brake light
Changing bulb
............................................... 338
Installing tail light
........................................... 337
Removing tail light
......................................... 336
Brake pads
Breaking in new brake pads
................................. 6
Warning message on the multi-purpose display
... 153
Warning message, brakes
............................... 165
Brake pedal
........................................................... 164
Brake wear
Warning light
................................................. 165
Brake wear warning message
................................... 165
Brakes
.................................................................. 163Applying/releasing parking brake
..................... 162
Brake pad warning message
........................... 165
Brake pedal
.................................................. 164
Break in new brake pads
..................................... 6
Discs
........................................................... 165
Pads
.................................................. 165
, 166
Parking brake test
......................................... 189
Test stand
.................................................... 189
Warning light
........................................ 163
, 164
Warning message on the multi-purpose display
... 153
Break in hints
............................................................. 6
Breaking in
Engine
............................................................. 6
Engine oil and fuel consumption
during break-in period
......................................... 6
Hints
............................................................... 6
New brake pads and brake discs
.......................... 6
New tires
......................................................... 6
Brief overview
2-zone air-conditioning
...................................... 69
4-zone air-conditioning (front control panel)
.......... 73
4-zone air-conditioning (rear control panel)
........... 74
Manual air-conditioning
..................................... 66
Opening and locking from outside
....................... 18
Panorama roof system
..................................... 96
Sliding/lifting roof
............................................ 91
Windshield wipers
.......................................... 110
Bulbs
Changing bulb for additional high beam
(Bi-Xenon headlights)
...................................... 331
Changing bulb for additional high beam
(halogen headlights)
....................................... 330
Changing bulb for front turn signal (Cayenne GTS)
335
Changing bulb for front turn signal
(Cayenne, Cayenne S, Cayenne S Transsyberia)
.. 333
Changing bulb for high beam
........................... 331
Changing bulb for high beam (halogen headlights)
330
Changing bulb for license plate light
.................. 338
Changing bulb for low beam
................... 329
, 330
Changing bulb for low beam (halogen headlights)
329
Changing bulb for side light (Cayenne GTS)
........ 335
Changing bulb for side light
(Cayenne, Cayenne S, Cayenne S Transsyberia)
.. 333
Changing bulb for side light, halogen
(Cayenne, Cayenne S, Cayenne S Transsyberia)
.. 333
Changing gas-discharge headlight
(Bi-Xenon headlights)
...................................... 330
Chart
........................................................... 342
Overview
...................................................... 342
Replacing brake light
...................................... 338
Replacing rear fog light
................................... 338
Replacing rear turn signal light
......................... 338
Replacing reversing light
................................. 338
Replacing tail light
.......................................... 338
Button overview
2-zone air conditioning
...................................... 70
4-zone air conditioning, front
.............................. 75
4-zone air conditioning, rear
.............................. 76
Manual air-conditioning
...................................... 67
Parking heater
................................................. 81
CCapacities
Brake fluid
.................................................... 359
Coolant
........................................................ 359
Engine oil
..................................................... 359
Fuel
............................................................. 359
Overview
...................................................... 359
Washer fluid
.................................................. 359
Car care
............................................................... 270Airbags
........................................................ 277
Alcantara
...................................................... 277
Cleaning the engine compartment
..................... 273
Decorative foils
............................................. 271
Fabric linings
................................................. 277
Floor mats
.................................................... 277
Headlights, plastic parts, adhesive films
............. 275
Leather
........................................................ 277
Light alloy wheels
.......................................... 276
Paint
............................................................ 273
Safety belts
.................................................. 278
Seals
........................................................... 276
Seat belts
..................................................... 278
Storing your Porsche
...................................... 278
Undercoating
................................................ 274
Use of high-pressure cleaning equipment
........... 271
Washing the vehicle, instructions
...................... 271
Wheel bolts
................................................... 293
Windows
...................................................... 274
Car key (remote control)
Changing battery
........................................... 322
Emergency operation of key in ignition lock
........ 159
Locking the vehicle door
................................... 21
Opening/closing Panorama roof system
.............. 99
Opening/closing sliding/lifting roof
...................... 93
Opening/closing windows
(without Porsche Entry & Drive)
.......................... 89
Unlocking the vehicle door
................................. 20
Car Telephone
........................................................ 219
10_Cayenne_21_KW17.book Seite 364 Donnerstag, 9. April 2009 3:33 15

Index
365
Care instructions
Airbags
........................................................ 277
Alcantara
...................................................... 277
Carpet
......................................................... 277
Cleaning the engine compartment
..................... 273
Fabric linings
................................................. 277
Floor mats
.................................................... 277
Headlights, plastic parts, adhesive films
............. 275
Leather
........................................................ 277
Light alloy wheels
........................................... 276
Paint
............................................................ 273
Safety belts
.................................................. 278
Seals
........................................................... 276
Seat belts
..................................................... 278
Storing your Porsche
...................................... 278
Undercoating
................................................ 274
Use of high-pressure cleaning equipment
............ 271
Washing
....................................................... 271
Wheel bolts
................................................... 293
Windows
....................................................... 274
Cargo
................................................................... 208
Cargo management system
...................................... 208
Inserting and adjusting the strap reel
................. 208
Inserting and adjusting the telescopic bar
........... 208
Inserting and adjusting tie-down rings
................ 210
Overview
...................................................... 208
Carpet, care instructions
.......................................... 277
Catalytic converter
.................................................. 264
Emission control (Check Engine)
....................... 123
Center armrest
Opening front storage compartment
.................. 224
Opening rear storage compartment
................... 224
Center differential lock
............................................. 178
Engaging
...................................................... 178
Central locking system
Changing settings via multi-purpose display
........ 143
Closing the rear window
.................................... 27
Functional description
....................................... 17
Locking the rear lid
.......................................... 23
Locking vehicle door with Porsche Entry & Drive
.... 21
Locking vehicle door with the car key
(remote control)
............................................... 21
Opening and locking vehicle door from inside
........ 28
Unlocking and opening rear lid
............................ 22
Unlocking and opening the rear window
............... 27
Unlocking vehicle door with Porsche Entry & Drive
.20
Unlocking vehicle door with the car key
(remote control)
............................................... 20
When disconnecting battery
............................. 321
Changing bulb for license plate light
........................... 338
Changing wheels
..................................................... 294
Check engine (emission control)
Functional description
..................................... 123
Warning light on the tachometer
....................... 123
Checking hydraulic fluid (power steering)
..................... 259
Child restraint anchorages
.......................................... 54
Child restraint system
Installing with LATCH system
.............................. 53
LATCH restraint system
..................................... 53
Child seat
Installing with LATCH system
.............................. 53
LATCH restraint system
..................................... 53
Prescribed installation direction
.......................... 50
Child seat bracket
..................................................... 53
Cigarette lighter
...................................................... 228
Front
............................................................ 228
Rear
............................................................ 228
Cleaning the engine compartment
.............................. 273
Clock
Button for setting
........................................... 123
Setting on the multi-purpose display
.................. 146
Closing
Automatically closing the rear lid
......................... 25
Closing sliding/lifting roof
.................................. 93
Locking vehicle door from inside
......................... 28
Panorama roof system
...................................... 98
Persons/animals remaining in the vehicle
............. 21
Powerliftgate
................................................... 23
Rear window
................................................... 27
Spare wheel bracket
....................................... 311
Vehicle door with Porsche Entry & Drive (keyless)
.. 21
Vehicle door with the car key (remote control)
....... 21
Closing the rear lid automatically
................................. 25
Clutch
................................................................... 169
Cockpit
Adjusting illumination
...................................... 105
Clock
........................................................... 123
Cooling system temperature gage
.................... 122
Fuel level gage
.............................................. 120
Odometer
..................................................... 121
Oil temperature gage
...................................... 120
Speedometer
................................................ 120
Tachometer
.................................................. 120
Voltage indication
........................................... 121
Voltmeter
...................................................... 121
Warning and indicator lights, overview
................ 117
Collapsible spare wheel
PSM (Porsche Stability Management)
.................186
Tire size
.................................... 350
, 351
, 352
Collapsible spare wheel in the luggage compartment
.....305
Comfort function
Panorama roof system
......................................99
Comfort lighting
Dimming
.......................................................109
Comfort tire pressure
Data (bar/psi)
................................................354
Coming Home function
Setting lighting off delay
..................................146
Switching on
..................................................109
Compass
Setting on the multi-purpose display
..................147
Compressor
...........................................................307
Connection (on vehicles without air suspension)
...307
Storage location
(on vehicles without air suspension)
...................292
Tire filling connection
(on vehicles with air suspension)
.......................308
Control panel
............................................................79
2-zone air conditioning
......................................70
4-zone air conditioning, front
..............................75
4-zone air conditioning, rear
...............................76
Disabling control panel
for air-conditioned areas at the rear
.....................79
Manual air-conditioning
......................................67
Parking heater
.................................................81
Control systems
Overview (PTM, PTM Plus, PSM, PASM, PDCC)
....181
Coolant
Antifreeze
.....................................................255
Change quantity
.............................................359
Checking level
...............................................255
Cooling system
Engine coolant level warning
............................122
Engine coolant temperature warning
..................122
Temperature gage
..........................................122
Warning on multi-purpose display
......................122
Cornering light
........................................................330
Changing bulb (Bi-Xenon headlights)
...................332
Installing headlights
........................................328
Removing headlights
.......................................327
Cornering light,static
................................................332
Crankcase ventilation
...............................................264
Crossing obstacles
..................................................201
10_Cayenne_21_KW17.book Seite 365 Donnerstag, 9. April 2009 3:33 15

Index
367
Emergency unlocking
Of the filler flap
.............................................. 267
Spare wheel bracket
....................................... 311
Emission control (check engine)
Functional description
..................................... 123
Warning light on the tachometer
....................... 123
Emission Control System
.......................................... 263
Engaging the rear differential lock
.............................. 178
Engine
Break in hints
.................................................... 6
Cooling system
.............................................. 122
Data
............................................................ 349
Idling
........................................................... 171
Starting
........................................................ 160
Stopping
...................................................... 161
Engine Braking Support
(assistance when driving downhill)
.............................. 189
Engine drag torque control (MSR)
Functional description
..................................... 184
Engine oil
.............................................................. 251Change
........................................................ 253
Change quantity
............................................. 359
Checking oil level with oil dipstick
...................... 252
Choosing the right oil
...................................... 253
Consumption
................................................. 349
Dipstick
........................................................ 253
Engine oil pressure
......................................... 153
Filler opening
................................................. 254
General information
........................................ 253
Level
........................................................... 252
Oil-level warning on the multi-purpose display
...... 252
Recommendation
........................................... 253
Temperature gage
......................................... 120
Topping up
................................................... 254
Engine oil level
....................................................... 252
Checking
...................................................... 252
Entry & Drive
Locking vehicle door with Porsche Entry & Drive
.... 21
Opening/closing Panorama roof system
with car key
.................................................... 99
Unlocking vehicle door with Porsche Entry & Drive
.20
Entry aid
Functional description
....................................... 39
Switching on/off
.............................................. 39
Error messages
Displaying
..................................................... 130
Overview of warning messages
on the multi-purpose display
............................. 149
Exhaust gas
Monitoring warning light
........................ 117
, 119
Exhaust pipes
............................................................. 3
Stainless steel tailpipes, care instructions
........... 276
Exit aid
Functional description
....................................... 39
Switching on/off
.............................................. 39
External audio source, interface
................................. 221
FFabric linings, care instructions
................................. 277
Factory settings
Resetting multi-purpose display
......................... 148
Faults
After charging the battery
................................ 325
Emergency operation of automatic rear lid
........... 26
Emergency operation of ignition key
in ignition lock
............................................... 159
Emergency operation of rear lid
.......................... 31
Emergency operation of sliding/lifting roof
............ 94
Emergency operation
of the Panorama roof system
........................... 101
Emergency operation of the spare wheel bracket
.311
Emergency operation of Tiptronic selector lever
.. 175
Emergency unlocking of the filler flap
................. 267
Overview of warning messages
on the multi-purpose display
............................. 149
Panorama roof system
...................................... 99
ParkAssist
.................................................... 240
Parking heater
................................................. 85
Power windows
................................................ 90
Sliding/lifting roof
............................................. 94
When opening and closing
................................. 31
Filler flap
............................................................... 267Emergency unlocking
...................................... 267
Filling pressure
Plate location
................................................ 348
Reducing
............................................ 307
, 308
Tires (bar/psi)
............................................... 354
Warning light on speedometer
.......................... 141
Warning message on multi-purpose display
......... 151
Filter
Air cleaner maintenance instructions
.................. 260
Particle filter maintenance instructions
............... 260
Fire extinguisher
....................................................... 40
Floor mats, care instructions
..................................... 277
Fluids and fuels
Brake fluid
....................................................359
Coolant
........................................................359
Engine oil
......................................................359
Fuel
.............................................................359
Hydraulic fluid for power steering
......................259
Overview
......................................................359
Washer fluid
..................................................359
Folding key bit in/out
.................................................16
Folding wedges to prevent rolling
...............................296
Footbrake
..............................................................163
Warning light
.................................................164
Footwell lightning
Dimming
.......................................................109
Four-wheel drive
Functional description
.....................................182
Warning message on multi-purpose display
.........154
Four-zone air conditioning
Air-conditioning sensors
.....................................76
Controlling rear air-conditioned areas
with the front control panel
................................79
Defrosting windshield
........................................75
Disabling control panel (rear)
..............................79
Disabling control panel for air-conditioned areas
at the rear
.......................................................79
Operating overview, front
...................................75
Operating overview, rear
...................................76
REST mode
.....................................................65
Setting air distribution
.......................................77
Setting air quantity
...........................................77
Setting temperature
..........................................77
Switching ECON mode on/off
.............................65
Switching Mono function on/off
...........................78
Switching on automatic recirculating-air mode
.......78
Switching on recirculating-air mode
.....................78
Using engine residual heat
.................................65
Fresh-air intake
.........................................................80
Front seat
Adjusting
........................................................36
Drawer under the right front seat
......................225
Passenger mirror as parking aid
.........................38
Recalling settings (memory)
...............................37
Storing driver’s seat settings (memory)
................38
Storing passenger’s seat settings (memory)
..........38
Front seat with memory
..............................................37
Storing door mirror settings
...............................56
Front seats
..............................................................34
10_Cayenne_21_KW17.book Seite 367 Donnerstag, 9. April 2009 3:33 15

370
Index
Lights
Care instructions
........................................... 276
Changing
..................................................... 326
Chart
........................................................... 342
Dimming comfort lighting
................................ 109
Dimming footwell light
.................................... 109
Switching front reading lights on/off automatically
108
Switching interior light on/off
........................... 108
Switching interior light on/off automatically
........ 108
Switching rear reading lights on/off
.................. 108
Switching rear reading lights on/off automatically
108
When towing a trailer
...................................... 234
Limit speed
Off-road shifting
............................................. 177
Limp-home mode
.................................................... 175
Load
.................................................................... 233Compartment cover
....................................... 222
General information on loading
......................... 231
Installing luggage compartment cover
............... 212
Loading and securing ski bag
.......................... 214
Luggage compartment cover,
pulling out/retracting
...................................... 211
Luggage safety net, permitted uses
.................. 212
Position of tie-down rings
................................ 207
Removing luggage compartment cover
............. 211
Safety net
.................................................... 222
Ski bag
........................................................ 214
Stowing
.............................................. 233
, 234
Vehicle settings on the multi-purpose display
...... 135
Loading
General information
........................................ 231
Installing luggage compartment cover
............... 212
Loading and securing ski bag
.......................... 214
Loading level
....................................... 191
, 357
Lowering the car for loading
............................ 191
Luggage compartment cover,
pulling out/retracting
...................................... 211
Luggage safety net, permitted uses
.................. 212
Position of tie-down rings
................................ 207
Removing luggage compartment cover
............. 211
Loadspace
............................................................ 233
Cargo management system
............................. 208
Closing the floor
............................................ 207
Opening floor
................................................ 207
Overview
...................................................... 207
Position of tie-down rings
................................ 207
Setting loading level
....................................... 191
Lock
Child lock
....................................................... 79
Disabling control panel for air-conditioned areas
at the rear
...................................................... 79
Locking
Closing the rear window
.................................... 27
Disabling central locking buttons on the rear doors
29
Locking vehicle door from inside
........................ 28
Locking vehicle door with Porsche Entry & Drive
... 21
Locking vehicle door with the car key
(remote control)
.............................................. 21
Persons/animals remaining in the vehicle
............. 21
Rear lid
.......................................................... 23
Spare wheel bracket
...................................... 311
Vehicle door with car key (remote control)
............ 21
Vehicle door with Porsche Entry & Drive (keyless)
.. 21
Vehicle door with the car key (remote control)
...... 21
Locks
Displaying status on the multi-purpose display
..... 131
Engaging the center differential lock
................. 178
Engaging the rear differential lock
.................... 178
Longitudinal lock
Displaying status of locks
on the multi-purpose display
............................ 131
Engaging
..................................................... 178
Low beam
Changing bulb, halogen, xenon
......................... 329
Changing gas-discharge headlight
(Bi-Xenon headlights)
...................................... 330
Door-surrounding lighting
................................ 109
Installing headlights
........................................ 328
Removing headlights
...................................... 327
Switch
......................................................... 104
Switching on/off
............................................ 104
Low level
............................................................... 190
Low Range (reduction)
Displaying status on the multi-purpose display
..... 131
Indicator light
................................................ 179
Switching off
................................................. 178
Switching on
................................................. 178
Luggage
Compartment cover
....................................... 222
General information on loading
......................... 231
Loading and securing ski bag
.......................... 214
Luggage compartment cover,
pulling out/retracting
...................................... 211
Luggage safety net, permitted uses
.................. 212
Position of tie-down rings
................................ 207
Removing safety net from rear seat backrest
...... 213
Safety net
............................................ 213
, 222
Ski bag
........................................................ 214
Luggage compartment
Cargo management system
............................. 208
Closing luggage compartment lid
........................ 23
Closing the floor
............................................ 207
Closing the luggage compartment window
........... 27
Opening floor
................................................ 207
Opening luggage compartment lid
...................... 22
Opening luggage compartment window
............... 27
Overview
...................................................... 207
Position of tie-down rings
................................ 207
Setting loading level
....................................... 191
Luggage compartment cover
Installing
...................................................... 212
Pulling out
.................................................... 211
Removing
..................................................... 211
Retracting
.................................................... 211
Luggage compartment lid
.......................................... 23
Luggage net
.......................................................... 207
Luggage safety net
Bracket
........................................................ 212
Permitted uses
.............................................. 212
Removing from rear seat backrest
.................... 213
Securing passenger compartment
.................... 213
MMaintenance work
Adding washer fluid
........................................ 258
Changing air cleaner
...................................... 260
Changing particle filter
.................................... 260
Changing the brake fluid
................................. 258
Checking and adding hydraulic fluid
for power steering
......................................... 259
Checking brake fluid level
................................ 257
Checking engine-oil level
................................. 252
Checking the coolant level and adding coolant
.... 255
Notes on Maintenance
.................................... 250
Replacing front wiper blades
............................ 261
Replacing rear wiper blade
.............................. 262
Make-up mirror
......................................................... 62
Malfunctions
After charging the battery
............................... 322
Automatic rear lid
............................................ 26
Emergency operation of automatic rear lid
........... 26
10_Cayenne_21_KW17.book Seite 370 Donnerstag, 9. April 2009 3:33 15

372
Index
Sand
........................................................... 201
Switching off Low Range (reduction)
.................. 178
Switching on Low Range (reduction)
.................. 178
Track ruts
.................................................... 202
Uphill driving
................................................. 197
Water crossing
.............................................. 199
Off-road PSM functional description
........................... 184
Off-road roof-mounted headlights
............................... 217
Off-road shifting
Limit speed
.................................................. 177
Oil....................................................................... 251Change quantity
............................................ 359
Checking oil level with oil dipstick
..................... 252
Choosing the right oil
..................................... 253
Consumption
........................................... 6
, 349
Dipstick
....................................................... 253
Engine oil pressure
........................................ 153
Filler opening
................................................ 254
General information
........................................ 253
Oil-level warning on the multi-purpose display
...... 252
Temperature gage
......................................... 120
Topping up
................................................... 254
Oil level
Checking
...................................................... 252
On-board computer
Activating synchronous mirror adjustment
.......... 143
Changing settings
for opening and locking the vehicle
................... 143
Changing settings of central locking system
....... 143
Displaying status of level control
...................... 131
Displaying status of locks/reduction
................. 131
Displaying warning messages
.......................... 130
Displaying/resetting average consumption
......... 132
Gear display for Tiptronic S
............................. 171
Operating principle
........................................ 124
Overview of warning messages
........................ 149
Resetting to factory settings
............................ 148
Setting a speed limit
...................................... 129
Setting compass
........................................... 147
Setting language for displays
........................... 148
Setting lighting off delay
................................. 146
Setting the clock
........................................... 146
Setting the tire type and size
........................... 134
Setting Tire Pressure Monitoring
...................... 132
Setting tire sealant/sealing set
......................... 140
Setting units of displays
.................................. 148
Setting vehicle loading
.................................... 135
Switching daytime driving lights on/off
.............. 145
Switching off passenger compartment monitoring
142
Using the telephone
....................................... 128
Opening and closing
Automatically closing the rear lid
........................ 25
Closing the rear window
.................................... 27
Closing the spare wheel bracket
....................... 311
Engine compartment lid
.................................... 29
Loadspace floor
............................................ 207
Locking vehicle door with the car key
(remote control)
.............................................. 21
Opening the rear lid automatically
....................... 24
Opening the spare wheel bracket
...................... 310
Panorama roof system
..................................... 97
Roller blind for Panorama roof system
............... 100
Sliding/lifting roof
............................................ 92
Unlocking and opening rear window
.................... 27
Unlocking vehicle door with Porsche Entry & Drive
.20
Unlocking vehicle door with the car key
(remote control)
.............................................. 20
Opening and closing the engine compartment lid
............ 29
Opening and locking
Closing the rear lid automatically
........................ 25
Closing the rear window
.................................... 27
Engine compartment lid
.................................... 29
Locking vehicle door with Porsche Entry & Drive
... 21
Locking vehicle door with the car key
(remote control)
.............................................. 21
Opening and locking vehicle door from inside
....... 28
Opening the rear lid automatically
....................... 24
Unlocking and opening the rear window
............... 27
Unlocking vehicle door with car key
(remote control)
.............................................. 20
Unlocking vehicle door with Porsche Entry & Drive
.20
Opening the rear lid automatically
................................ 24
Operating in other countries
..................................... 266
Operating overview
2-zone air conditioning
...................................... 70
4-zone air conditioning, front
............................. 75
4-zone air conditioning, rear
.............................. 76
Manual air-conditioning
..................................... 67
Parking heater
................................................ 81
Operating the function keys on steering wheel
............... 60
Operating the horn
.................................................... 58
Overview of capacities
Engine oil
..................................................... 359
Oxygen sensor
....................................................... 264
PPaint
Care instructions
........................................... 273
Polishing
...................................................... 273
Preserving
.................................................... 273
Removing spots and stains
.............................. 273
Repairing damage
.......................................... 273
Panic button
............................................................ 17
Panorama roof system
Brief overview
................................................. 96
Comfort function
.............................................. 99
Emergency operation
..................................... 101
Functional description
....................................... 97
Malfunctions
................................................... 99
Opening closing with car key
............................. 99
Opening/closing
.............................................. 98
Opening/closing roller blind
............................. 100
Roller blind cleaning position
............................ 101
ParkAssist
............................................................. 235
Distance display, front
.................................... 239
Distance display, rear
..................................... 239
Functional description
..................................... 237
Sensors
....................................................... 238
Switching on/off
............................................ 237
When driving with a trailer
............................... 240
Parking
................................................................. 175Applying the parking brake
.............................. 162
Distance display, front
.................................... 239
Distance display, rear
..................................... 239
Locking the vehicle
.......................................... 21
ParkAssist, functional description
..................... 237
Sensors
....................................................... 238
Switching ParkAssist on and off
........................ 237
When towing a trailer
...................................... 240
Parking aid
.............................................................. 56
Distance display, front
.................................... 239
Distance display, rear
..................................... 239
Functional description
..................................... 237
Sensors
....................................................... 238
Storing door mirror setting as parking aid
............ 38
Switching on/off
............................................ 237
Swivelling down mirror glass
.............................. 56
When driving with a trailer
............................... 240
10_Cayenne_21_KW17.book Seite 372 Donnerstag, 9. April 2009 3:33 15

Index
377
Technical data
Capacities
.................................................... 359
Comfort tire pressure (bar/psi)
......................... 354
Dimensions
................................................... 360
Driving performance
....................................... 361
Engine
......................................................... 349
Ground clearance
........................................... 357
Tire pressure (bar/psi)
.................................... 354
Tires, wheels, tracks
...................................... 350
Weights
........................................................ 356
Telephone
............................................................. 219
Using via multi-purpose display
......................... 128
Telescopic bar (cargo management system)
Inserting and adjusting
.................................... 208
Temperature sensor
For 2-zone air conditioning
................................. 71
For 4-zone air conditioning
................................. 76
Temporary change-down
.......................................... 172
Terrain level
........................................................... 190
Test stands
Brake test
..................................................... 189
Theft protection
........................................................ 15
Tie-down
Belts
............................................................ 207
Equipment
.................................................... 233
Rings
........................................................... 212
Tie-down rings,
securing points in the luggage compartment
................ 207
Tiptronic S
............................................................... 58
Functional description
..................................... 170
Gear display on the multi-purpose display
........... 171
Gear selector
................................................ 171
Rocker switches
............................................ 172
Rocker switches on the steering wheel
................ 58
Selector lever
................................................ 171
Tire
Care
............................................................ 285
Checking pressure
......................................... 306
Life.............................................................. 285Traction
....................................................... 283
Wear
............................................................ 285
Tire and rim sizes
................................................... 353
Tire pressure
Air pressure (bar/psi)
...................................... 354
Comfort tire pressure (bar/psi)
......................... 354
Load
............................................................ 233
Plate
............................................................ 348
Plate location
................................................ 348
Reducing
............................................ 307
, 308
Warning light
....................................... 117
, 119
Warning light on speedometer
.......................... 141
Warning message on multi-purpose display
......... 151
When towing a trailer
...................................... 234
Tire Pressure Monitoring
Functional description
..................................... 133
Setting on the multi-purpose display
.................. 132
Setting the tire type and size
............................ 134
Setting vehicle loading
.................................... 135
Tire sealant/sealing set
For defective tires
.......................................... 296
Setting on the multi-purpose display
.................. 140
Tires
Breaking in new tires
.......................................... 6
Changing
............................................ 220
, 302
Comfort tire pressure, data (bar/psi)
................. 354
Damage
....................................................... 286
Fitting spare wheel on spare wheel bracket
......... 309
Flat
.............................................................. 295
General information
........................................ 281
Inflating
........................................................ 307
Inflating (with compressor from tool kit)
.............. 307
Inflating (with compressor
on vehicles with air suspension)
........................ 308
Inscription on radial tire
................................... 290
Overview
...................................................... 350
Removing spare wheel from spare wheel bracket
.309
Removing/fitting spacers
................................. 303
Replacing tires (general information)
.................. 286
Rim offset
..................................................... 350
Sealant
......................................................... 296
Sidewall
........................................................ 290
Size
................................................... 290
, 350
Snow chains (general information)
..................... 289
Spare wheel (general information)
..................... 309
Storage
........................................................ 287
Tire pressure plate
......................................... 348
Tire pressure, data (bar/psi)
............................ 354
Tracks
......................................................... 350
Valves
.......................................................... 286
Wheel bolt wrench
.......................................... 292
Winter tires (general information)
....................... 288
Tool kit
.................................................................. 281Compressor (on vehicles without air suspension)
.292
Jack
............................................................ 291
Screwdriver
.................................................. 292
Wedges
........................................................ 296
Wheel bolt wrench
..........................................292
Tools
....................................................................281Compressor (on vehicles without air suspension)
.292
Jack
.............................................................291
Screwdriver
...................................................292
Wedges
........................................................296
Wheel bolt wrench
..........................................292
Torque, Technical data
.............................................349
Towing
Capacity
.......................................................231
General information
........................................342
Screwing in front towing hook
...........................344
Screwing in rear towing hook
...........................343
Towing bar
....................................................342
Towing hook when recovering the vehicle
...........345
Towing rope
..................................................342
Track
Data
............................................................350
Traction
.................................................................198
Traction control system (TCS)
Functional description
.....................................182
Trailer
Coupling
.......................................................230
Definitions
.....................................................231
Effects on ParkAssist
......................................240
Electrical connection
.......................................230
Hitching
........................................................230
Operation
......................................................230
Retrofitting
....................................................230
Tips on driving
...............................................235
Trailer load data
.............................................356
Unhitching
.....................................................230
Transmission
Shift pattern
..................................................169
Transport (on car trains, ferries, etc.)
Securing the vehicle
.......................................192
Transverse lock
Displaying status of locks
on the multi-purpose display
.............................131
Engaging
......................................................178
Trip counter
Display
.........................................................121
Resetting
......................................................121
Turn signal
Switch
..........................................................106
10_Cayenne_21_KW17.book Seite 377 Donnerstag, 9. April 2009 3:33 15
