2004 PORSCHE 911 GT3 Owners Manual

A
Safety notes!

Motor racing isaterm weassociate withfascina-
tion andemotion.
On the one hand.
On the other hand, there's thetechnology that
makes thisfascination possible.
Your new911 GT3 hasbeen developed withexpe-
rience gained fromthedevelopment anduseof
countless GTvehicles, andhasbeen equipped
with technical preconditions thatfacilitate use
away frompublic roadsinmotor racing.
Depending onuse, itcan bepossible ornecessary
to adapt thevehicle tothe respective conditions.
In the case, itmust always betaken intoaccount
that amodern high-performance sportscarrepre-
sents acomplex systemwithindividual compo-
nents thatarecarefully adjusted towork together
perfectly.
Interfering inthis system isonly anoption ifitcan
be guaranteed thatallofthe components willcon-
tinue towork together inamanner adjusted tothe
actual conditions ofuse. Well-founded specialist
knowledge isnecessary forthis. Youshould seek
advice fromyourauthorized Porschedealer.
Here, youwillreceive information aboutsports
parts available fromPorsche, theirreliability on
public roadsandimportant maintenance notes.

8
Please
bearinmind thatuseonrace tracks sub-
jects allvehicle components toconsiderably more
wear thannormal use,making professional in-
spection andmaintenance aftereach useavital
preconditon forfunctioning andsafety.
Please useonly Original Porsche Partsforyour
car. These partsareavailable fromyourautho-
rized Porsche dealer,whichisconversant withthe
range ofapproved partsandwillbepleased toad-
vise youfurther.
Porsche acceptsresponsibility, inaccordance
with itslegal obligations, forGenuine Porsche
Parts andforparts andaccessories whichithas
approved foryour car.However, theuse ofother
parts oraccessories whichareneither Genuine
Porsche Partsnorapproved byPorsche mayad-
versely affectthesafety ofyour car,andPorsche
can take noresponsibility forany loss ordamage
caused bytheir use.
Even ifthe supplier ofother accessories orparts
is arecognised supplier,thesafety ofyour car
may stillbeaffected ifsuch items areinstalled.
Due tothe large variety ofproducts offeredinthe
accessory marketitis not possible forPorsche to
inspect andapprove everyone.
In addition, pleasenotethattheuse ofreplace-
ment parts which arenotGenuine Porsche Parts
or approved partsorthe use ofaccessories not
approved byPorsche mayalsodetrimentally
affect theWarranties relatingtoyour car.
Technical
modifications

Modifications maybecarried outonyour vehicle
only ifapproved byPorsche.This ensuresthat
your Porsche willremain reliable andsafe todrive
and that itwill notbedamaged asaresult ofthe'
modifications.Your authorizedPorschedealerwill
be pleased toadvise you.

Coverings
~ Donot affix anycoverings (e.g.films or"stone
guards") inthe area ofthe headlights andair
intakes. Damage duetoexcessive temperatures and
abrasion couldresult.

Motor racing

For reasons ofsafety, thebraking system, steer-
ing, running gear,wheels andtires ofyour car
should bechecked afterevery race.
On public highways, therunning gearandrear
spoiler mustbeinthe standard position.

Power transmission

The differential lock,which wasdesigned foruse
in motor sport,maymake aslight noisewhen
maneuvering andontight corners.

Porsche Ceramic Composite Brake
IPCCB)

The high-performance brakesystem isdesigned
for optimal braking effectatall speeds andtem-
peratures. Certainspeeds, brakingforcesandam-
bient conditions (suchastemperature andhumid-
ity) therefore mightcause brakenoises.
Wear onthe different components andbraking
system, suchasbrake padsorbrake discs,
depends toagreat extent onthe individual driving
style andtheconditions ofuse andtherefore
cannot beexpressed inactual milesonthe road.
The values communicated byPorsche arebased
on normal operation adaptedtotraffic. Wearin-
creases considerably whenthevehicle isdriven
on race tracks orthrough anaggressive driving
style.

I>
Please consult yourauthorized Porschedealer
about thecurrent guidelines
in
effect before
such useofyour vehicle.
Aerodynamic
components

To benefit fromthehigh driving performance with-
out impairing thedriving safetyorthe service life
of the vehicle components, certainvehicle parts
must bealways fullyoperational whiledriving.

I>
Regularly checkyourvehicle forsigns ofdam-
age.
Damaged, wornormissing aerodynamic com-
ponents suchasspoilers orunderside panels
affect driving behaviour andmust therefore be
replaced immediately.
To optimise thecooling ofthe PCCS brakediscs,
large airbrake spoilers arefitted tothe front and
rear running gearcontrol arms.
If these air-brake spoilersarenotfitted andthere
is ahigh thermal demand onthe braking system,
the service lifeofthe PCCS brakediscscould be
reduced.
The aerodynamic stabilityofthe vehicle isinflu-
enced considerably athigh speeds bythe front lip.
Due tothe small ground clearance requiredforthe
optimisation ofthe driving behaviour, thefront lip
and theair-brake spoilershavetobe placed inex-
posed positions tofulfil their function. Theycanbe
damaged, forexample byground orcurbstone
contact.
Ground
clearance

Please bear
in
mind thelimited ground clearance
of your caronuneven surfaces, whenparking
(curbs), onramps, liftingplatforms, etc.

Seating
Your carhas two seats.
The area behind theseats isnot intended forpas-
sengers.

A
Danger!
Severe personal injuryordeath canresult in
the event ofan accident.

I>
Never allowanyone tosit inthe area behind the
seats.

Setting andoperating vehicle
components whendriving

A
Warning!
There isadanger ofaccident ifyou setorop-
erate theon-board computer, radio,naviga-
tion system, telephone orother equipment
when driving.
This could distract youfrom thetraffic and
cause youtolose control ofthe vehicle.

t> Operate thecomponents whiledriving onlyif
the traffic situation allowsyoutodo sosafely.

t>
Carry outany complicated operatingorsetting
procedures onlywiththevehicle stationary.

10
Portable
FuelContainers

A
Danger!
Portable fuelcontainers, fullorpartially
empty, mayleak, causing anexplosion, or
result infire incase ofan accident.

t> Never carryadditional fuelinportable contain-
ers inyour vehicle.
Engine
Exhaust

A
Danger!
Engine exhaust isdangerous ifinhaled.
Engine exhaust fumeshavemany compo-
nents which youcansmell. Theyalsocontain
carbon monoxide (CO),which isacolorless
and odorless gas.
Carbon monoxide cancause unconscious-
ness andeven death ifinhaled.

t> Never startorlet the engine runinan en-
closed, unventilated area.
It is not recommended tosit inyour carforpro-
longed periods withtheengine onand thecar
not moving.

Controls,Instruments
Maintenance, CarCare
Practical Tips,Emergency Service
Vehicle Identification, TechnicalData
Index
13
-110
112 -138
140 -178
180 -189
190 -194

11

12

Beforedrivingoff.. 14
Break inhints forthe first
1,000 miles/1,600 kilometers 16
Keys 19
Security WheelBolts 19
Doors 21
Central Locking 22
Alarm System, InfraredPassenger
Compartment Monitoring 24
Power Windows 26
Inside mirror 28
Rear View Mirrors 28
Rear Window Defogger,
Door Mirror Heating 29
Seat Adjustment 30
Steering WheelAdjustment.. 31
Safety Belts 32
Child Restraint Anchorages 35
Child Restraint Systems 36
Airbag Systems 38
Clutch Pedal 40
Parking Brake 40
Brakes 41
ABS Brake System
(Antilock BrakeSystem) 44
Interior lights 46
Footwell Lights 47
Operation, Instruments 48
Ignition/Starter Switchwith
anti-theft SteeringLock 50
Starting Procedures 52
Stopping Engine 53Instrument
PanelUSAModels 54
Instrument PanelCanada Models 56
Voltmeter 58
Automatic SpeedControl 58
Instrument Illumination 59
Trip Odometer 59
Speedometer 60
Changing overbetween
Miles /Kilometers 60
Tachometer 61
Turn Signal Indicator Light 61
High Beam 61
Cooling System 62
Fuel 63

C~k ~

Engine OilPressure 65
Check Engine
Warning Light 66
On-Board Computer (BC) 67
Warnings inthe Instrument Panelandinthe On-
Board Computer 75
Emergency FlasherSwitch 81
Light Switch 82
Automatic HeadlightBeamAdjustment 82
Turn Signal /
Headlight Dimmer/Flasher Lever 83
Windshield Wiper/Washer Lever 84
Automatic SpeedControl 86
Heating andVentilation 88
Automatic AirConditioning 90
Central andSide Vents 93
Fresh-air Intake 93Controls,
Instruments
Ashtray 94
Cigarette Lighter 94
Cupholder 95
Storage inthe Passenger Compartment 96
Luggage Compartment Lidand
Engine Compartment Lid 98
Luggage Compartment.. 100
Trunk Entrapment 101
Sun Visors 103
Spoiler, SideMember Panels 104
Car Audio Operation/Tips 105
Car Telephone and
Aftermarket Alarms 107
Roof Transport System 108
Gearshifting 109
Controls, Instruments

DearPorsche Owner

A lot has gone intothemanufacture ofyour
Porsche, includingadvanced engineering, rigid
quality control anddemanding inspections.
These engineering andsafety features willbe
enhanced byyou ...

the safe driver ...

- who knows hiscar and allcontrols,
- who maintains thevehicle properly,
- who uses driving skillswisely andalways
drives withinher/his owncapabilities andthe
level offamiliarity withthevehicle.
You willfind helpful hintsinthis manual onhow to
perform mostofthe checks listedonthe following
pages.
If in doubt, havethese checks performed byyour
authorized Porschedealer.
Controls, Instruments
Before
driving off...

Check thefollowing itemsfirst

I>
Turn theengine offbefore youattempt any
checks orrepairs onthe vehicle.

I>
Besure thetires areinflated correctly.
Check tiresfordamage andtirewear.

I>
See that wheel boltsareproperly tightened
and notloose ormissing.

I>
Check engine oillevel, addifnecessary.
Make itahabit tohave engine oilchecked with
every fuelfilling.

I>
Check allfluid levels suchaswindshield
washer andbrake fluidlevels.

I>
Besure thevehicle battery iswell charged and
cranks theengine properly.

I>
Check alldoors andlidsforproper operation
and latch them properly.

I>
Check, andifnecessary replacewornor
cracked wiperblades.

I>
See that allwindows areclear andunob-
structed.

I>
Check airintake slotsandarea between lug-
gage compartment lidand windshield arefree
of snow andice,sothe heater andthewind-
shield wipers workproperly.
I>

Ifachild willberiding inthe vehicle, check
child seat/child seatrestraint systemtoen-
sure thatrestraints areproperly adjusted.

I>
Check allexterior andinterior lightsforopera-
tion andthat thelenses areclean.

I>
Check theheadlights forproper aim,andif
necessary, havethem adjusted.

I>
Check underthevehicle forleaks.

I>
Besure allluggage isstowed securely.

Emergency equipment

It is good practice tocarry emergency equipment
in your vehicle.
Some ofthe items youshould haveare:
window scraper, snowbrush, container orbag of
sand orsalt, emergency light,small shovel, first-
aid kit, etc.

Inthe driver's seat...

c>
Check operation ofthe horn.

c>
Position seatforeasy reach offoot pedals and
controls.
To reduce thepossibility ofinjury fromthe
airbag deployment, youshould always sitback
as far from thesteering wheelasispractical,
while stillmaintaining fullvehicle control.

c>
Adjustthe insideandoutside rearview mirrors.

c>
Buckle yoursafety belts.

C>
Check operation ofthe foot andparking brake.

C>
Check allwarning andindicator lightswith
ignition onand engine notrunning.

C>
Start engine andcheck allwarning displays for
warning symbols.

C>
Never leaveanidling carunattended.

C>
Lock doors frominside, especially withchil-
dren inthe cartoprevent inadvertent opening
of doors frominside oroutside.
Drive withdoors locked.
On
the road ...

C>
Never driveafteryouhave consumed alcohol
or drugs.

C>
Always haveyoursafety beltfastened.

C>
Always drivedefensively.
Expect theunexpected.

C>
Use signals toindicate turnsandlane changes.

C>
Turn onheadlights atdusk orwhen thedriving
conditions warrantit.

C>
Always keepasafe distance fromthevehicle
in front ofyou, depending ontraffic, roadand
weather conditions.

C>
Reduce speedatnight andduring inclement
weather. Driving inwet weather requirescautionandre-
duced speeds, particularly onroads with
standing water,asthe handling characteristics
of the vehicle maybeimpaired duetohydro-
planing ofthe tires.

C>
Always observe speedlimitsandobey road
signs andtraffic laws.

C>
When tired,getwell offthe road, stopandtake
a rest. Turntheengine off.Donot sitinthe ve-
hicle withengine idling.
Please observe thechapter "ENGINE EX-
HAUST" onPage 10.
C>

When parked, alwayssetthe parking brake.
Move thegearshift levertoreverse orfirst
gear.
On hills also turnthefront wheels towardthe
curb.

C>
When emergency repairsbecome necessary,
move thevehicle welloffthe road. Turnonthe
emergency flasheranduseother warning de-
vices toalert other motorists. Donot park or
operate thevehicle inareas where thehotex-
haust system maycome incontact withdry
grass, brush,fuelspill orother flammable ma-
terial.

C>
Make itahabit tohave theengine oilchecked
with every fuelfilling.
Controls, Instruments
