2004 Peugeot 407 Owner's Manual

88 -
17-05-2004
89
-
17-05-2004
By pressing the navigator, you can
activate/deactivate the following func-
tions:
- random play with "RDM",
- playing of the start of the track
with "INTRO",
- repeating of a track with "RPT",
- programming of the tracks.You can also select a track directly via
the list of tracks on the CD:
- press the "LIST" button to display the list,
- press button 5 or 6 or turn the
dial to select the track,
- press the
navigator to start play-
ing the track.
Accelerated play
Press and hold button 7 or 8 for
backwards or forwards accelerated
play.
Accelerated play stops as soon as
the button is released.
Compact disc source
The use of copied compact discs
may cause faults.
Insert circular compact discs only.
Selecting CD mode
After inserting a disc,
printed face upwards,
the CD player starts
automatically.
If a disc has already
been inserted, press
the "SOURCE" button to select CD
mode.
Ejecting a disc
Press the button to
eject the disc from the
player.
Selecting a track
Press button 8 to
select the following
track.
Press button 7 to
return to the start of
the current track or
to select the previous
track.
"CD" menu
Interior comfort

90 -
17-05-2004
91
-
17-05-2004
"CHANGER" menu
Selecting a track
Press button
8 to select the next
track.
Press button 7 to return to the start
of the current track or to select the
previous track.
You can also select a track directly
via the list of tracks on the CD:
- press the "LIST" button to display the list,
- press the 5 or 6 down button or
turn the dial to select the track,
- press the
navigator to start paying
the track.
Compact disc changer source
The CD changer is located in the
boot on the right-hand side and can
contain 6 discs.
Press the navigator to activate/
deactivate the following functions:
- playing of the start of the track with "INTRO",
- random play with "RDM",
- repeating of the CD with "RPT".
Insert circular compact discs
only.
Compact discs of the irst
generation of laser technol-
ogy are no longer detected.
Some anti-pirating systems, on origi-
nal discs or CDs copied by a personal
writer may cause faults, irrespective
of the quality of the original player.
Selecting the CD changer source
Press the "SOURCE"
button several times.
Selecting a disc
Press one of the but-
tons "1" to "6" to select
the corresponding disc.
Buttons 5 and 6
permit the selection
of the previous/next
disc in the changer.
To insert a disc in the changer:
- open the sliding lap A,
- press button B to eject the car-
tridge C,
- open one of the six drawers of the cartridge by pulling the tab D,
- insert the disc in the cartridge,
printed face upwards, and close
the drawer,
- insert the cartridge in the changer following the direction of the
arrow,
- close the sliding lap A.
Interior comfort

90 -
17-05-2004
91
-
17-05-2004
MONOCHROME DISPLAY CT
Navigation - Guidance
* With the DT colour screen only.
COLOUR AND MAP DISPLAY DT
Displays the following information:
- the time,
- the date,
- the exterior temperature (the
value displayed lashes if there is
a risk of ice),
- the accesses check,
- the vehicle function status mes- sages, displayed temporarily,
- the warning displays,
- the RT3 audio equipment dis- plays, the direct inputting of the
frequency of a transmitter on the
numeric keypad,
- the telematic systems displays (telephone, services, ...),
- the trip computer displays,
- the air conditioning displays,
- the satellite navigation system displays.
Audio functions
Trip computer
Directory Telematics
Personalisation-
Coniguration
Map*
Air conditioning
Interior comfort

92 -
17-05-2004
The general menu
Press the "MENU" button to access
the general menu and select one of
the following parameters and func-
tions: Navigation - Guidance, Audio
functions, Trip computer, Personalisa-
tion-coniguration, Directory, Telemat-
ics, Map* and Air Conditioning.
The "Personalisation-Coniguration"
menu provides access to successive
conirmation windows.
Deine the vehicle parameters
Permits the activation or deactiva-
tion of certain driving and comfort
functions:
- Deactivation of the driver wel- come function,
- Automatic switching on of the lights,
- Duration of the "follow-me-home" lighting,
- Activation of the automatic "follow- me-home" lighting,
- Activation of the permanent lock- ing of the boot. Display coniguration
- selection of the colours for the DT
display: selection of the colours
available for display.
- Sound: selection of the sound am- bience, setting of the voice synthe-
siser and of the voice commands.
- Brightness.
- Selection of the units of measure- ment.
Selection of the language
German, Spanish, French, English,
Italian, Dutch, Portuguese and Bra-
zilian Portuguese.
* With the DT colour display only.
Interior comfort

6 -
17/05/2004
General notes on the «Map»
application**
The “Map” application has two
display modes:
- “Vehicle following on map”
mode, representing active guidance
on the map on the right and a large-
scale view of the next intersection
on the left,
- “Selection - Movement on map”
mode, representing consultation
of the map at full screen size or
reduced size on the right with a
compass on the left.
To switch from one mode to the other,
press the dial on the right briely, then
select the “Move the map” or “Exit
the map mode” function.
* CT monochrome screen only.
** DT colour screen only.
6
“Navigation - Guidance”
contextual menu
The contextual menu associated with
the “Navigation - Guidance” appli-
cation appears as a superimposed
display, when this is the application
currently in use in the main screen
window.
This menu is limited to the following
functions:
- changing of the initial route (entering of a diversion)*,
- switching to “Selection - Movement on map” mode**,
- storing of the current location (postal address if available or, if it is
not, the GPS co-ordinates),
- changing of the route calculation criteria,- stopping or resuming of guidance (displaying of the message which
changes depending on the previous
status),
- displaying of the map, full screen or reduced size on the right
(displaying of the message which
varies depending on the previous
status)**.
RDS TMC Trafic Information (Trafic Message Channel)
04LVV.003016. - 04-04 Anglais
Video
It is possible to connect video
equipment (a camcorder, digital
camera, ...) using the three video
sockets situated inside the glove
box.
It is only possible to display
video images when the vehicle is
stationary.
Select the “Video” menu from the
main menu :
- “Activate video mode” to activate/ cancel the video function,
- “Video parameters” to adjust the display format, the brightness,
contrast and colour.
Press “MODE” or “DARK” to exit
video mode.
Successive presses on the
“SOURCE” button allow you to
select another audio source other
than the video.

93
-
17-05-2004
Interior comfort
Using the menus
Press the "MENU" button to dis-
play the general menu. Select the
telematics application, then validate
"Telephone functions" to access the
principal telephone functions, then
the various menus, in order to reach
the one required.
RT3 TELEPHONE
This function is a GSM dual-band
telephone (900 and 1 800 MHz)
incorporated in the RT3 GPS audio/
telephone.
It is a "hands-free" telephone. This
function is provided by a microphone
located next to the front courtesy
light, the speakers, a steering column
control and voice commands which
allow access to most of the functions
(the audio/telephone control panel
buttons allow access to all of the
functions).
Display of the principal "mobile" type
functions, as well as consultation of
the directories, is provided by the
multi-function display.
This function is active whatever
position the ignition key is in, even
after thirty minutes, when the mes-
sage appears on the multi-function
display.
For safety reasons, the driver must
carry out operations which require
prolonged attention while the vehicle
is stationary.
When the ignition has been switched
off, the audio/telephone can be
switched on again by pressing the
"TEL" (green), "LION" or "SOS"
button or by inserting a CD in the
player. Within each menu:
Move around by
pressing the 5 or 6
buttons or by turning
the navigator dial, then
validate by pressing
the dial to select a
function.
Cancel an operation by means of the
"ESC" button.
- Network: allows you to select the network search mode and to see
the networks available.
- Duration of calls: allows you to consult the duration recorder of
calls made and zero re-set.
- Security: allows you to use or modify the PIN code and to erase
the list of calls and text messages
(SMS).
- Telephone options: allows you to conigure the calls with entering of
my number, automatic answering
after X rings, speciication of ring
options and allows you to conig-
ure the call diversion number. This menu allows you
to access the following
functions:
Using the alphanumeric
keypad
For a given button, to input a charac-
ter in the second or subsequent rows
press until you obtain the character
required.

Buttons Associated characters
[1]
1 or space
[2] 2 or A B C 2 or a b c 2
[3] 3 or D E F 3 or d e f 3
[4] 4 or G H I 4 or g h i 4
[5] 5 or J K L 5 or j k l 5
[6] 6 or M N O 6 or m n o 6
[7] 7 or P Q R S 7 or p q r s 7
[8] 8 or T U V 8 or t u v 8
[9] 9 or W X Y Z 9 or w x y z 9
[0] 0 or + (long press)
[#] # or conirmation
[*] * or erasing of last charac-
ter input (long press)

94 -
17-05-2004
95
-
17-05-2004
Cancelling of PIN code request
In the menu "Telephone functions"

select "Security", then "Process the
PIN code", then validate the "Cancel"
function.
Recommendation: do not lose your
SIM card. Losing it would mean
anyone who inds it would be able to
make unlimited calls.
Interior comfort
Open the lap by pressing
the point of a pencil on the
circular opening above the
lap.
Insert your Micro-SIM card, available
from a mobile telephone operator, as
indicated in the graphics, then close
the lap.
Note: removal or insertion of the SIM
card must only be carried out after
the RT3 GPS audio/telephone has
been switched off.
Handle the SIM card with care to
avoid losing it in the fascia.
Installing the SIM card
The PIN code is required each time
the ignition is switched on, unless the
PIN code has been stored or protec-
tion by PIN is not activated on the
SIM card.
Input your PIN code using the alphanu-
meric keypad and validate by pres-
sing the navigator dial or button # to
access the network. Connection to
the network is validated by the ap-
pearance of a symbol on the screen.
If you make three errors in succes-
sion when inputting your PIN code,
your SIM card will be blocked. To
unblock it, you will need to input the
PUK code. The PUK code will be
supplied to you by the person sell-
ing your SIM card (input of the PUK
code allows for 10 errors in succes-
sion; after this the SIM card becomes
permanently unusable).
Inputting the PIN code

94 -
17-05-2004
95
-
17-05-2004
Telephone function screens
Not in use
The screen indicates the presence
of voice messages or text messages
(SMS) not listened to, the cumulative
time in use since the last zero reset
and the status of your telephone.
In use
The screen indicates the time
elapsed since the start of the con-
versation, as well as the number* or
name of the person to whom you are
speaking (if recorded in the directory)
and the status of your telephone.
* If this option and service are available.
Interior comfort
Press the button to display the con-
textual menu of the telephone.
Pressing the end of the steering col-
umn control
for more than 2 seconds
calls up a contextual menu limited
to the "Directory", "List of calls" and
"Voice mail" functions.
Making a call
Select the function "Enter
number" then enter the
number of the person you
wish to speak to using the
alphanumeric keypad.
Press the "Pick up" button to make
the call.
Entering a number
Making a call from a directory
Select the "Directory" function to
access all the iles containing a tele-
phone number or the "List of calls"

function to access the list of the last
twenty incoming (if the number display
option is active) or outgoing calls.
There are two directories, the RT3
GPS audio/telephone directory and
the SIM card directory. To consult the
SIM directory, insert your SIM card
and enter you PIN code. When a ringing sounds
to let you know that a
call is waiting, you can
choose either to accept
it by pressing the "pick
up" button or the end of the steering
wheel remote control or not to accept
it by pressing the "hang up" button or
by selecting and validating the "NO"
button on the "Answer?" screen.
Receiving a call
If you accept the call, to
end your communica-
tion, press the "hang up"
button.
If you do not accept the
call, it is transferred to your voice
mail or to a call diversion number.
You can activate or deactivate this
transfer by pressing the "hang up"
button for more than two seconds.
