YOUR 307 SW IN DETAIL
TELEPHONE
This function is a GSM dual-band
telephone (900 and 1 800 MHz)
incorporated in the RT3 GPS audio/
telephone system.
It is a ''hands free'' telephone. This
function is provided by a microphone
located next to the front courtesy
light, the speakers, a steering col-
umn control and voice commands
which allow access to most of the
functions (the audio/telephone con-
trol panel buttons allow access to all
the functions).
Display of the principal ''mobile''
type functions, as well as consulta-
tion of the directories, is provided by
the multi-function display.
This function is active, whatever
position the ignition key is in even af-
ter thirty minutes, when the message
''Economy mode active'' appears
on the multi-function display.
Using the menus
Press the ''MENU'' button to dis-
play the general menu . Select the
telematics application, validate "Tele-
phone functions" to access the
principal telephone functions, then the
various menus, in order to reach the
one required.
This menu allows you to access the
following functions: Within each menu:
- Network: allows you to select the
network search mode and to see
the networks available.
- Duration of calls: allows you to
consult the duration recorder of
calls made and zero re-set.
- Security: allows you to use or
modify the PIN code and to erase
the list of calls and text messages
(SMS).
- Telephone options: allows you to
conigure the calls with entering of
my number, automatic answering
after X rings, speciication of ring
options and allows you to conigure
the call diversion number. Move around and se-
lect a function by turn-
ing the
G button then
validate by pressing
the button.
Cancel an operation
using the ''ESC'' but-
ton.
Using the alphanumeric keypad
For a given button, to input a charac-
ter in the second or subsequent rows
press until you obtain the character
required.
Buttons Associated characters
[1] 1 or space
[2] 2 or A B C 2 or a b c 2
[3] 3 or D E F 3 or d e f 3
[4] 4 or G H I 4 or g h i 4
[5] 5 or J K L 5 or j k l 5
[6] 6 or M N O 6 or m n o 6
[7] 7 or P Q R S 7 or p q r s 7
[8] 8 or T U V 8 or t u v 8
[9] 9 or W X Y Z 9 or w x y z 9
[0] 0 or + (long press)
[#] # or validation
[*] * or erasing of last charac-
ter input (long press)

54
15-03-2004
55
15-03-2004
YOUR 307 SW IN DETAIL
Open lap L by pressing the
point of a pencil on the circu-
lar opening above the lap.
Insert your Micro-SIM card,
available from a mobile tel-
ephone operator, as indicated in the
graphics, then close the lap.
Note: removal or insertion of the SIM
card must only be carried out after
the RT3 audio/telephone has been
switched off.
Installing the SIM card Inputting the PIN code
Input your PIN code using the al-
phanumeric keypad and validate by
pressing button G or button # to ac-
cess the network. Connection to the
network is validated by the appear-
ance of a symbol on the screen.
Warning: if you make three errors in
succession when inputting your PIN
code, your SIM card will be blocked.
To unblock it, you will need to input
the PUK code. The PUK code will be
supplied to you by the person sell-
ing your SIM card (input of the PUK
code allows for 10 errors in succes-
sion; after this the SIM card becomes
permanently unusable).
Note: the PIN code is required each
time the ignition is switched on, un-
less the PIN code has been stored
in the memory or protection by PIN
code is not activated on the SIM
card. Cancelling of PIN code request
In the menu
''Telephone functions''
select ''Security'' , then ''Process
the PIN code'' , then validate the
''Cancel'' function.
Warning: in this case, do not lose
your SIM card. Losing it would mean
anyone who inds it would be able to
make unlimited calls.

56
15-03-2004
57
15-03-2004
Telephone function screens
Not in use
In use
YOUR 307 SW IN DETAIL
This screen indicates the presence
of voice messages or text mes-
sages (SMS) not listened to/read,
the cumulative time in use since the
last zero reset and the status of your
telephone.
This screen indicates the time
elapsed since the start of the con-
versation, as well as the number* or
name of the person to whom you are
speaking (if recorded in the directory)
and the status of your telephone.
* If this option and service are avail-able. Making a call
Press button
D to display the contex-
tual menu of the telephone.
Note: pressing the end 5 of the
steering column control for more
than 2 seconds calls up a contex-
tual menu limited to the "Directory",
"List of calls" and "Voice mail"
functions.
Entering a number
Select the function
''Enter number'' then
enter the number of
the person you wish
to speak to using the
alphanumeric key-
pad.
Press button D to
make the call. Making a call from a directory
Select the
"Directory" function
to access all the iles containing a
telephone number or the "List of
calls" function to access the list
of the last twenty incoming (if the
number display option is active) or
outgoing calls.
Note: there are two directories, the
RT3 GPS audio/telephone directory
and the SIM card directory. To con-
sult the SIM directory, insert your
SIM card and enter your PIN code.
Receiving a call
When a ringing sounds
to let you know that
a call is waiting, you
can choose either to
accept it by pressing
button D or the end of
the steering wheel re-
mote control or not to
accept it by pressing the button Q or
by selecting and validating the "NO"
button on the "Answer?" screen.
If you accept the call, to end your
communication, press button Q.
If you do not accept the call, it is
transferred to your voice mail or to a
call diversion number.
You can activate or deactivate this
transfer by pressing button Q for
more than two seconds.

56
15-03-2004
57
15-03-2004
Text messages (SMS)
Accessing text messagesSending a text message "Duration of calls" menu
Select the "Duration of calls"
function from the "Telephone func-
tions"
menu to consult the duration
counters for the calls made. The par-
tial counter totals the duration of the
calls since the last zero reset carried
out using the "Zero reset" button.
YOUR 307 SW IN DETAIL
When the buzzer sounds (if the SMS
text messages buzzer option is ac-
tive) and a superimposed screen
announces "Do you wish to read
the new text message (SMS)?" ,
you can choose to read the text mes-
sage received by selecting and vali-
dating "YES" or postpone reading
it by selecting and validating "NO",
by pressing the "ESC" button or by
waiting until the announcement dis-
appears. The message is read by the
voice synthesiser, if it is active.
Note: the old text messages stored
and the new text messages, the
reading of which you wished to
postpone, can be consulted. Press
the "MENU" button then validate
the telematic icon, select "Text
messages (SMS)" and validate the
function "Received text messages
reading" by pressing button G. Then
scroll through the list by turning the
button and press the button to select
the text message to be read.
Note: Before typing your irst text
message, check that your text mes-
sages (SMS) centre number is stored
correctly in the sub-menu "Server
centre N°" . If it is not, any text mes-
sages typed before this number is
entered will not be sent.
In the menu "Text messages
(SMS)" validate the function "Text
message writing" . Type your text
message using the alphanumeric
keypad and validate it using the
"OK" button to store it or validate the
"Send" button to send it. Validation
of the "Send" button enables you to
enter the number of your recipient or
select it from the directory or from the
list of calls and send the message. "Telephone options" menu
Select the
"Telephone options"
function from the "Telephone func-
tions" menu to access the func-
tions:
฀•฀฀ "Conigure the calls" which per-
mits activation and deactivation of
the "show my number" and "au-
tomatic answering after X rings"
functions.
฀•฀฀ "Ringing options" which permits
adjustment of the ringing volume
for voice calls, activation of the text
messages (SMS) receipt buzzer
and selection of a ring tone from
the ive offered.
฀•฀฀ "Diversion number/voice mail"
which permits recording of the call
diversion number chosen by the
customer, otherwise the call will be
transferred to the voice m
ail.

58
15-03-2004
59
15-03-2004
Services* Emergency call*"PEUGEOT Assistance" /
Emergency call
During a connection to "PEUGEOT
Assistance" or an emergency call,
it is not possible to send or receive
calls or SMS messages; these will
be transferred to your voice mail.
In this case, a green diode flashes
on the RT3 GPS audio/telephone
panel, when the emergency call
or "PEUGEOT Assistance" call
procedure begins, then lights con-
tinuously when the call is taken by
the services concerned.
If your call to "PEUGEOT Assist-
ance" is located, a star "´" will
appear in the text on the screen.
YOUR 307 SW IN DETAIL
Press button E to dis-
play the "Services"
menu and select one
of the following ser-
vices:
฀•฀฀ "Customer Contact Centre" which
enables you to contact the PEUGEOT
Customer Contact Centre directly
and access the services offered (this
type of call is suspended if an emer-
gency or breakdown call is made).
฀•฀฀ "PEUGEOT Assistance" which
enables you to contact the
call centre which controls the
PEUGEOT breakdown service
directly and receive rapid assist-
ance (you have 6 seconds within
which to cancel the call when it
is made). During the breakdown
call phase it is not possible to
make any other calls with the
exception of emergency calls.
If you have signed the specific
PEUGEOT contract, your call will
be located.
฀•฀฀ "Operator services" which gives
access to the list of services specif-
ic to your operator (e.g.: customer
service, consumption monitor-
ing, news, stock market, weather,
travel, games, etc) if they are avail-
able.
In an emergency, press
button V until a signal is
heard and a call validation /
deletion screen is displayed
(delay of 6 seconds) or enter
112 directly.
Make an emergency call if
you are involved in an situ-
ation which leads you to fear serious
consequences (injuries, ...) for those
who are exposed to it (if you witness
or are involved in an accident result-
ing in injuries, an attack, ...).
Before making a call of this kind, the
audio/telephone must detect a cel-
lular network.
If you have not signed the speciic
PEUGEOT contract, the parameters
of the SOS button are set so that a
call is made to 112 - unique number
made available by the worldwide
GSM network, reserved for emer-
gency calls.
No security mode is required and,
depending on the network, you do
not need to insert your SIM card or
enter your PIN.
If you have signed the speciic
PEUGEOT contract, your call will
be located and you will be put in
contact with a PEUGEOT assist-
ance team.
For further details, refer to the gen-
eral conditions of your contract.
* If option and service available.

58
15-03-2004
59
15-03-2004
The Directory
General
The "Directory" application gives
access to 400 iles divided into 4 in-
dependent sub-directories ("User1",
"User2", "User3" and "User4"). It
enables you to manage these iles,
make calls using the SIM card and
activate guidance.
Main menu
YOUR 307 SW IN DETAIL
From the general menu , select the
"Directory" application to access its
main menu and select one of the fol-
lowing functions:
• "Call", to call a number stored in a ile,
• "Activate guidance to", to initiate guidance to a location stored in a
ile,
• "Management of directory iles", to add, delete, modify and consult di-
rectory iles or exchange them with
the SIM card,
• "Directory coniguration", to select the working directory and deine
the directory when the system is
switched on. Creation / Modiication of a ile
To create a ile, from the
"Directory"
menu, select the function "Manage-
ment of directory iles" then "Add".
On the ile select the section to be
illed in, validate then enter the in-
formation.
To modify an existing ile, select it
using the "Consult or modify the
ile" function of the "Management of
directory iles" menu then make the
modiications.
Note: when the address is entered,
the navigation CD-Rom must be
present in order to obtain guidance
to this destination. Description of a directory ile
When a description is linked to a
directory ile, you can record the
description vocally so that it can be
used subsequently for direct access
by voice commands (e.g.: "
Call"
" [Name of the voice description] "
or "Guide to" "[Name of the voice
description]" ).
Select "Consult or modify the ile"
from the "Management of direc-
tory iles" menu to access the screen
which permits entering and recording
of the description.
Press the record button and follow
the instructions.
TMC (Trafic Message Channel)
RDS Trafic Information
You can access information regard-
ing the trafic conditions from the
"Audio functions"
or "Telematics"
menu, then from the "Trafic Infor-
mation TMC" function (see section
"Satellite navigation system").

60
15-03-2004
61
15-03-2004
VOICE COMMANDS
The voice commands make it pos-
sible to use pre-recorded words or
phrases to control a certain number
of functions of the RT3 GPS audio/telephone.
Activation of the voice commands
Press the button on the end of the
lights stalk to activate or deactivate
this function.
Example: to recall the radio station
stored on button 3, the key words
are: "Radio" "Memory" "3" .
To use these key words, you must
say the word "Radio", wait for the
audible conirmation signal, then
say the word "Memory", wait for the
audible conirmation signal, then end
with the word "3", wait for the audible
conirmation signal which will carry
out the action requested.
Notes:
- between two key words, a screen indicates the time remaining and
the key word recognised,
- in the absence of any voice commands, this function will be
switched off after approximately
ive seconds,
- if a command is not understood, the system transmits "Pardon"
and displays "Word not recog-
nised" on the screen.
Saying the phrase "Help" or "What
can I say" displays all of the com-
mands available on the screen. List
of commands available
- For the radio, say "RADIO", then:
"PREVIOUS" / "NEXT" /
"MEMORY" + 1...6 /
"AUTOSTORE" / "LIST"
- For the CD, say "CD PLAYER", then:
" PREVIOUS TRACK" / "NEXT TRACK" / "TRACK NUMBER" +
1...20 / "RANDOM" / "SCAN" /
"LIST"
- for the CD changer, say "CHANGER", then:
" PREVIOUS TRACK" / "NEXT TRACK" / "TRACK NUMBER"
+ 1...20 / "PREVIOUS DISC" /
"NEXT DISC" /
"DISC NUMBER" + 1...5 / "RANDOM" / "SCAN" /
"REPEAT" / "LIST"
- For the telephone, say "TELEPHONE", then:
"REDIAL" / "ADDRESS BOOK" + DESCRIPTION / "SERVICES" /
"SOUND BOX" / "VOICE
MESSAGE"
- For the SMS text messages, say "SMS" or "MESSAGE" then:
"DISPLAY" / "READ"
- For the RDS traffic information TMC, say "TRAFFIC-INFO" then:
"DISPLAY" / "READ"
YOUR 307 SW IN DETAIL
- For navigation/guidance, say "NAVIGATION" or "GUIDANCE",
then:
"STOP" / "RE-START" / "ADDRESS BOOK" +
DESCRIPTION / "ZOOM IN" /
"ZOOM OUT" / "SHOW" +
"DESTINATION" / "SHOW" +
"VEHICLE"
- To change the permanent application, say "DISPLAY", then:
"AUDIO" / "TELEPHONE" / "NAVIGATION" / "TRIP
COMPUTER" / "GUIDANCE"
- To call someone recorded in the directory directly, say "CALL" +
DESCRIPTION
- To be guided to the address of someone recorded in the
directory, say "GUIDE TO" +
DESCRIPTION
- Various:
"CANCEL" / "HELP" / "WHAT CAN I SAY" / "STOP" /
"DELETE" / "YES" / "NO" /
"PREVIOUS" / "NEXT"

60
15-03-2004
61
15-03-2004
YOUR 307 SW IN DETAIL
CD CHANGER
This is located in the centre of the
fascia under the radio. It holds up to
5 discs.
To load the changer, insert the discs
with the printed side upwards.
To remove a disc, press and hold one
of the buttons "1" to "5" .
The use of copied com-
pact discs may cause
faults.
Insert circular compact
discs only.
