2004 PEUGEOT 307 BREAK DAG Owners Manual

94
30-08-2004
95
30-08-2004
YOUR 307 IN DETAIL
THE ALARM
This provides two types of
protection: - exterior protection: it sounds if
a door, the boot or the bonnet is
opened.
- interior protection:
it sounds if
the volume inside the passenger
compartment changes (breaking of
a window or a movement inside the
vehicle). When the alarm is triggered, the si-
ren sounds and the direction indica-
tor lights lash for thirty seconds.
After triggering, the alarm remains
set.
Warning:
if the alarm has been trig-
gered ten times in succession, on the
eleventh time it becomes inactive.
Note: if button A indicator light
lashes rapidly, the alarm has been
triggered while you were away from
your vehicle. F
Set the alarm by locking or dead-
locking using the remote control
(button A indicator light lashes
once a second).
Note: when the alarm is set but the
remote control does not operate:
F Unlock the doors with the key and
open the door. The alarm is trig-
gered.
F Switch on the ignition. The alarm
is disarmed.
Setting the alarm
F Switch off the ignition and get out
of the vehicle.
F Set the alarm, by locking or dead-
locking using the remote control
(button A indicator light lashes
once per second).
Note: if you wish to lock your vehicle
without setting the alarm, use the
door lock.
Disarming
Unlock the vehicle with the remote
control key (button A indicator light
goes out).
Note: if the alarm has been triggered
while you were away from your vehi-
cle, the rapid lashing of the indicator
light will stop when you switch on the
ignition.
To set the alarm with exterior
protection only
If, while you are away from the ve-
hicle, you wish to leave a window
partially open or a pet inside the
vehicle, you should choose exterior
protection only.
F Switch off the ignition.
F In the next ten seconds, press
button A until the indicator light is
on continuously.
F Get out of the vehicle.
Incorrect operation
When the ignition is switched on, if
button A lights for ten seconds, there
is a fault in the siren connection.
Contact a PEUGEOT dealer to have
the system checked.
Automatic activation*
The alarm is activated automatically
two minutes after the last closure of a
door or the boot.
In order to avoid accidental triggering
of the alarm when a door or the boot
is opened, it is essential to irst press
the unlocking button on the remote
control.
* According to country.

96
30-08-2004
97
30-08-2004
YOUR 307 IN DETAIL
Opening the doors from inside
The opening control of the front
doors permits complete unlocking of
the vehicle.
However, the opening control of the
rear doors only unlocks the door
concerned.
Note: the door opening switches
do not function when the vehicle is
deadlocked. Locking/Unlocking from the
inside
Pressing button
A permits:
- locking of the vehicle,
- unlocking of the vehicle if you place the key in the switch.
The red warning light on the button
comes on when the vehicle is locked
and switches off when it is unlocked.
Note: if the vehicle is locked or dead-
locked from outside, the red warning
light lashes and button A does not
function. In this case, use the key or
the remote control for unlocking.
THE DOORS
Opening the doors from outside To switch on
Press and hold button
A.
Activation of the function is accom-
panied by an audible signal and the
message ''Deadlocking active'' on
the multi-function display.
The message is displayed each time
the vehicle is started.
Automatic central locking of the
doors
The doors can lock automatically
when you are driving (at a speed of
more than 6 mph (10 km/h)).
Above 6 mph (10 km/h), press button
A briely to unlock the doors tempo-
rarily.
You can activate or deactivate this
function. To switch off
Press and hold button
A.
Notes: If one of the doors is open,
locking from the inside and automatic
central locking are not possible.
If the boot is open, automatic central
locking of the doors is active.
"Door open" alert
With the key in the accessories posi-
tion, the ignition on or the engine run-
ning (speed below 3 mph (5 km/h)), a
diagram displayed briely on the multi-
function display warns you that a door
is not properly closed.
In addition, when the vehicle is moving,
the courtesy lights lash.

98
30-08-2004
99
30-08-2004
Simultaneous locking or
unlocking of the tailgate and the
doors
The tailgate is locked or unlocked
by the remote control or the driver's
door lock.
To open, pull handle A and lift the
tailgate. Note:
if the "automatic central locking"
function is active (see corresponding
section), the tailgate locks automati-
cally when the vehicle is being driven
at 6 mph (10 km/h). It unlocks when
one of the doors is opened or when
the central locking button is pressed,
with the key in the switch (speed be-
low 6 mph (10 km/h)).
YOUR 307 IN DETAIL
Child safety
This prevents either of the rear doors
being opened from inside. F Turn the switch a quarter of a turn
using the ignition key.
TAILGATE
Saloon
Tailgate release
This enables the tailgate to be
unlocked in the event of a central
locking fault.
- Fold back the rear seats to gain
access to the lock from inside the
boot,
- Insert a small screwdriver into hole A of the lock to unlock the tailgate.
Estate
"Tailgate open" warning
With the key in the accessories posi-
tion, the ignition on or the engine run-
ning (speed below 3 mph (5 km/h)),
a diagram displayed briely on the
multi-function screen warns you that
the tailgate is not properly closed.
In addition, if the vehicle is being
driven, the courtesy lights lash.

98
30-08-2004
99
30-08-2004
YOUR 307 IN DETAIL
Notes:
After reconnecting the battery, in the
event of a malfunction, you must
reinitialise the safety auto-reverse:
- place the control in the maximum partial opening position (3rd notch
to the right),
- wait until the roof is in the maxi- mum partially open position,
- press the control for at least one second.
In the event of unwanted opening of
the roof on closing (for example, in
the presence of ice), and immedi-
ately after the roof stops:
- move the control to the "O" posi-
tion and press the control immedi-
ately,
- continue to press the control until the roof is fully closed.
In the partially open position, the roof
closes automatically above 60 mph
(100 km/h). Press the control to return
it to its initial position.
The safety auto-reverse function
is not active during these opera-
tions.
THE SUNROOF
- To partially open the roof: Turn
the switch to the right (three pos-
sible settings).
- To open the roof completely:
Turn the switch to the left (six
possible settings).
- To close it completely: Turn the
switch back to position "O".
- Safety auto-reverse: When the
sunroof is closing and meets an
obstacle, it stops then partially
opens again.
The sunroof shutter is manual. Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
In the event of contact during
operation of the roof, you must
reverse the movement of the roof.
To do this, press the switch con-
cerned.
When the driver operates the roof
switch, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that the
passengers use the sunroof cor-
rectly.
Be aware of children when operat-
ing the roof.

100
30-08-2004
101
30-08-2004
YOUR 307 IN DETAIL
OPENING THE BONNET
From inside: push the handle on the
left-hand side under the fascia.
From outside: lift the catch and
raise the bonnet. The engine must be switched off

when illing with fuel.F Open the fuel iller lap.
F Insert the key then turn it to the left.
F Remove the cap and hang it on
the hook located on the inside of
the lap.
A label afixed to the inside of the fuel
iller lap indicates which type of fuel
to use.
When you ill your tank, do not con-
tinue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
The capacity of the tank is ap-
proximately 60 litres. F After illing the tank, lock the cap
and close the fuel iller lap.
FILLING WITH FUEL
Low fuel level
When the minimum
fuel level in the tank is
reached, this warning
light comes on.
You can still drive approximately
30 miles (50 km).
Flashing of the warning light indicates
a malfunction of the fuel gauge.
Contact a PEUGEOT dealer.
Bonnet strut
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is properly locked.

100
30-08-2004
101
30-08-2004
YOUR 307 IN DETAIL
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped/Main beam change
Pull the stalk towards you.
Note:
with the ignition off, when the
driver's door is opened, a buzzer
sounds if you have left your lights on. Vehicles itted with front fog
lamps and a rear fog lamp (ring C)
Lights off
Side lights
Dipped/main beam
headlampsAutomatic switching on
of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off
the rear fog lamp and the front fog
lamps, turn the ring backwards twice
in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights will remain
on (turn the ring backwards to switch
off the front fog lamps. The side lights
will then be switched off).
Vehicles itted with a rear fog
lamp (ring B)
This only operates with the dipped/
main beam headlamps.
Note:
when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps will re-
main on (turn the ring backwards
to switch off the rear fog lamp. The
dipped headlamps and side lights will
then be switched off). The front fog lamps operate with
the side lights and the dipped head-
lamps.
When the main beam headlamps are
switched on, the front fog lamps are
switched off. They are switched on
again when the main beam head-
lamps are switched off.
Front fog lamps and rear fog lamp
Rotate the ring forwards to switch on
and backwards to switch off. The sta-
tus is conirmed by the indicator light
on the instrument panel.

102
30-08-2004
103
30-08-2004
AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the
vehicle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/
0 position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompanied
by an audible signal and a message
on the multifunction display.
YOUR 307 IN DETAIL
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards.
"Follow me home" lighting
In poor light or at night, if you leave
your vehicle, the side lights and
dipped headlamps can be left on for
approximately one minute.
To do this:
- place the key in the
STOP posi-
tion,
- place the lights stalk in the 0 posi-
tion,
- lash the headlamps,
- get out of the vehicle and lock it. Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly,
the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.

102
30-08-2004
103
30-08-2004
AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the
vehicle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/
0 position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompanied
by an audible signal and a message
on the multifunction display.
YOUR 307 IN DETAIL
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards.
"Follow me home" lighting
In poor light or at night, if you leave
your vehicle, the side lights and
dipped headlamps can be left on for
approximately one minute.
To do this:
- place the key in the
STOP posi-
tion,
- place the lights stalk in the 0 posi-
tion,
- lash the headlamps,
- get out of the vehicle and lock it. Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly,
the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
