8 How do I use the avoid area feature?
Setting avoid areas................................8-2
Setting with the selected location key................8-5
Renaming the avoid areas.......................8-5Deleting the avoid areas.........................8-7
Setting with the
Map key
......................8-8
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/05/04Ðdebbie
X

Setting “avoid areas” will give you a route away
from areas you wish to avoid.
INFO:
If the vehicle icon is in the “avoid area,” route cal-
culation cannot be completed.
1. Press the SETTING button.
2. Select the
Navigation key.
The display shows the [NAVIGATION SETTING]
screen.3. Select theAvoid Area Setting key.
The display shows the [AVOID AREA SETTING]
screen.
INV1781INV1948
SETTING AVOID AREAS
8-2How do I use the avoid area feature?
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/05/04Ðdebbie
X

4. Select a key which is not set as an “avoid
area.”
INFO:
It is possible to set up to 10 areas to avoid.5. The display shows categories which can be
used to set an “avoid area.”
For example, use the
Map key to set an “avoid
area.”
Select the
Map key.
INFO:
For setting with other categories, please refer to
“Expert mode categories” on page 5-2.6. The display shows the map which centers
the area to be set as an “avoid area.”
Use the
( ZOOM IN ) or
( ZOOM OUT ) button to adjust the map
reduction scale.
INV1949INV1950INV1951
How do I use the avoid area feature?8-3
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/17/04Ðrhinson
X

7. Use the joystick to adjust the location.
INFO:
Area size: Max. 5 x 5miles (8x8km)8. The display shows the keys on the right of
the screen.
Select the
Set key.
INFO:
cIf you want to avoid the freeway in that area,
select the
Avoid Freeway key to turn on the
amber indicator on the key. (Indicator ON:
avoid, OFF: do not avoid)
cWhen altering the size of the “avoid area,” se-
lect the
Area key. The area size is increased
or decreased by three scales.9. The “avoid area” is set, and the grid will be
displayed on the screen.
INFO:
The grid color will be displayed in green or blue.
(Avoid Freeway ON: green, OFF: blue)
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.
INV1952INV1953INV1954
8-4How do I use the avoid area feature?
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/05/04Ðdebbie
X

10. Please refer to “Making the system guide
the route with detailed options” on page
5-31.
If the route guidance is not set, the display
shows the current vehicle location.When the stored “avoid area” is selected, it can
be renamed or deleted.
RENAMING THE AVOID AREAS
1. Press the SETTING button.
2. Select the
Navigation key.
The display shows the [NAVIGATION SET-
TINGS] screen.
INV1955INV1781
SETTING WITH THE SELECTED LO-
CATION KEY
How do I use the avoid area feature?8-5
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/05/04Ðdebbie
X

3. Select theAvoid Area Setting key.
The display shows the [AVOID AREA SETTING]
screen.4. Select a key which is set as an “avoid area.” 5. Select theRename key.
INV1948INV1956INV1957
8-6How do I use the avoid area feature?
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/05/04Ðdebbie
X

6. The display shows the keyboard.
Enter the area name using the keyboard.
When the
Set key is selected, the “avoid area”
is renamed, and the screen returns to the previ-
ous screen.
INFO:
When the
Back Space key is selected, the cur-
sor moves back to the previous letter. When the
Space key is selected, the cursor proceeds
to make one space.
DELETING THE AVOID AREAS
1. Select theDelete key on the screen in
step 5 under “Renaming the avoid areas”.2. Select the
Yes key.
The “avoid area” is deleted.
If the route guidance is set, the display shows
the [AVOID AREA SETTING] screen.
INFO:
When the
No key is selected, the “avoid area”
will not be deleted, and the screen returns to the
previous screen.
INV1958INV1959INV1960
How do I use the avoid area feature?8-7
ZREVIEW COPYÐ2004 Quest(van)
Navigation System OM(navi)ÐUSA_English(nna)
05/05/04Ðdebbie
X

3. Please refer to “Making the system guide
the route with detailed options” on page
5-31.
If the route guidance is not set, the display
shows the current vehicle location.
SETTING WITH THEMap KEY
When the stored “avoid area” is selected, it can
be adjusted or deleted.
Press the SETTING button.
Adjusting the stored avoid areas
1. Select theNavigation key.
The display shows the [NAVIGATION SET-
TINGS] screen.2. Select the
Avoid Area Setting key.
The display shows the [AVOID AREA SETTING]
screen.
INV1955INV1781INV1948
