2004 NISSAN 350Z washer fluid

1. Fuse/fusible link holder
2. Battery
3. Engine oil filler cap
4. Brake fluid reservoir
5. Clutch fluid reservoir (M/T models)
6. Windshield washer fluid reservoir
7. Power steering fluid reservoir
8. Engine coolant reservoir
9. Radiator filler cap
10. Engine oil dipstick
11. Air cleaner
Do not tamper with the strut tower bar
adjustment
A. The strut tower bar has
been adjusted to the most suitable posi-
tion at the factory.CAUTION
Tampering with the strut tower bar ad-
justment may cause a noise while driv-
ing or damage to the hood or engine.
SDI1519
ENGINE COMPARTMENT CHECK
LOCATIONS
Maintenance and do-it-yourself
8-7


04.5.17/Z33-D/V5.0


CLUTCH FLUIDCheck the fluid level in the reservoir. If the fluid
level is below the MIN. line, add Genuine
NISSAN Super Heavy Duty Brake Fluid or
equivalentDOT 3fluid up to the MAX. line.
If fluid is added frequently, the system should be
thoroughly checked by your NISSAN dealer.
WARNING
Use only new fluid from a sealed con-
tainer. Old, inferior or contaminated
fluid may damage the clutch system.
CAUTION
Do not spill the fluid on painted sur-
faces. This will damage the paint. If fluid
is spilled, wash the surface with water.
Open the cap and add fluid when the low
washer fluid warning light comes on. Add a
washer solvent to the washer fluid for better
cleaning. In the winter season, add a windshield
washer anti-freeze. Follow the manufacturer’s
instructions for the mixture ratio.
Recommended fluid is Genuine NISSAN Wind-
shield Washer Concentrate Cleaner & Anti-
freeze Fluid or equivalent.
SDI1478
SDI1444
WINDOW WASHER FLUID
8-14
Maintenance and do-it-yourself


04.5.17/Z33-D/V5.0


WARNING
Anti-freeze is poisonous and should be
stored carefully in marked containers
out of the reach of children.
CAUTION
Do not substitute engine anti-freeze
coolant for window washer solution.
This may result in damage to the paint.
Keep the battery surface clean and dry. Any
corrosion should be washed off with a solu-
tion of baking soda and water.

Make certain the terminal connections are
clean and securely tightened.

If the vehicle is not to be used for 30 days or
longer, disconnect the (—) negative battery
terminal to prevent discharging it.
CAUTION
When the battery cable is removed from
the battery terminal, do not close either
of the front doors. The automatic win-
dow adjusting function will not work,
and the side roof panel/top side rail
may be damaged by doing so.
To disconnect the negative (−) battery ter-
minal, perform the procedure in the follow-
ing order. Otherwise, the window and the
side roof panel/top side rail may contact
and be damaged.
1. Close the windows.
2. Open the hood.3. Close and lock all the doors using the
key or keyfob.
4. Disconnect the negative (−) battery ter-
minal.
5. Securely close the hood.
To connect the negative (−) battery termi-
nal, perform the procedure in the following
order. Otherwise, the window and the side
roof panel may contact and be damaged.
1. Unlock (using the key) and open the
driver side door. Do not close the door.
2. Open the hood.
3. Connect the negative (−) battery termi-
nal. Then close the hood.
4. Fully open the driver side door window.
5. Close the driver side door and the win-
dow.
WARNING

Do not expose the battery to flames
or electrical sparks. Hydrogen gas
generated by battery action is explo-
sive. Do not allow battery fluid to
contact your skin, eyes, fabrics, or
BATTERY
Maintenance and do-it-yourself
8-15


04.5.17/Z33-D/V5.0


Compact Disc (CD) player (See audio
system) ......................................................................... 4-11
Compact spare tire ................................................... 8-36
Console box................................................................ 2-32
Controls, Heater and air conditioner controls
(automatic) ..................................................................... 4-3
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cruise control............................................................. 5-15
Cup holders ................................................................ 2-31
Curtain side-impact air bag system (See
supplemental side air bag and curtain air bag
system) ......................................................................... 1-17
D
Daytime running light system ................................. 2-23
Defroster switch, Rear window and outside mirror
defroster switch ......................................................... 2-21
Dimensions and weights ............................................ 9-9
Door open warning light .......................................... 2-12
Drive belts ................................................................... 8-17
Driving
Cold weather driving ......................................... 5-24
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Precautions when starting and driving ............ 5-2E
Economy, Fuel............................................................ 5-17
Elapsed time ................................................................. 2-9
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-22
Engine
Before starting the engine .................................. 5-8
Break-in schedule............................................... 5-17
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil and filter ......................... 8-10
Checking engine coolant level........................... 8-8
Checking engine oil level ................................. 8-10
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-25
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil .............................................................. 8-10
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ...................................... 6-9
Oil pressure gauge ............................................... 2-6
Starting the engine ............................................... 5-8
Event data recorders ................................................ 9-23
Exhaust gas (Carbon monoxide).............................. 5-2
F
F.M.V.S.S. certification label................................... 9-11Filter
Air cleaner housing filter ................................... 8-18
Changing engine oil and filter ......................... 8-10
Flashers (See hazard warning flasher switch) ... 2-25
Flat tire............................................................................ 6-2
Flat tire, Low tire pressure warning system .......... 5-3
Floor mat cleaning ....................................................... 7-4
Fluid
Automatic transmission fluid (ATF) ................ 8-12
Brake and clutch fluid ....................................... 8-13
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Engine coolant ....................................................... 8-8
Engine oil .............................................................. 8-10
Power steering fluid ........................................... 8-13
Window washer fluid ......................................... 8-14
FM-AM radio with Compact Disc (CD) player .... 4-9
FM-AM-SAT radio with cassette player and
Compact Disc (CD) changer ................................. 4-13
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Distance to empty ................................................. 2-9
filler cap................................................................. 3-13
filler lid ................................................................... 3-13
Fuel economy ...................................................... 5-17
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Gauge ...................................................................... 2-6
Fuses ............................................................................ 8-22
Fusible links ................................................................ 8-23


04.5.17/Z33-D/V5.0

10-2

Uniform tire quality grading .............................. 9-21
Tires
Spare tire .............................................................. 8-36
Tire chains ............................................................ 8-34
Tire pressure ........................................................ 8-30
Tire rotation .......................................................... 8-34
Types of tires ....................................................... 8-33
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-30
Top
If the top does not open or close
electrically ............................................................. 3-24
Soft top operation .............................................. 3-18
Top latch lever ..................................................... 3-21
Top tether strap child restraint........................ 1-36
Towing
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-16
Towing load/specification chart ...................... 9-16
Towing safety....................................................... 9-17
Traction control system (TCS)............................... 5-22
Traction control system (TCS) off switch ........... 2-27
Trailer towing .............................................................. 9-16
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-39
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Transmission selector lever lock release ...... 5-12
Transmitter (See remote keyless entry system) ... 3-4
Traveling or registering your vehicle in another
country ......................................................................... 9-10
Trip computer ............................................................... 2-8Trip odometer ............................................................... 2-9
Trunk
Interior trunk lid release .................................... 3-12
Secondary trunk lid release ............................. 3-13
Turn signal switch ..................................................... 2-24
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-21
Up-shift indicator (M/T models) ............................ 5-13
Up-shift indicator setting (rpm) (M/T models) ... 2-10
V
Vanity mirror light ...................................................... 2-38
Vehicle
Dimensions and weights ..................................... 9-9
Identification number (VIN)............................... 9-10
Loading information............................................ 9-14
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-17
Vehicle dynamic control (VDC) off switch ... 2-27
Vehicle dynamic control (VDC) system ........ 5-22
Ventilated net seats..................................................... 1-6
Ventilators ...................................................................... 4-2
Volt meter ...................................................................... 2-7
W
Warning labels, Air bag warning labels .............. 1-20
Warning light
Air bag warning light .............................. 1-21, 2-14Anti-lock brake warning light ........................... 2-11
Brake warning light ............................................ 2-12
Door open warning light ................................... 2-12
Low tire pressure warning light ...................... 2-13
Warning lights ............................................................ 2-11
Warning, Hazard warning flasher switch ............ 2-25
Warning, Low tire pressure warning
system.................................................................... 5-3, 6-2
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-11
Warranty, Emission control system warranty ..... 9-22
Washer switch
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-9
Wheel/tire size.............................................................. 9-9
Wheels and tires ....................................................... 8-30
Cleaning aluminum alloy wheels ....................... 7-4
Window washer fluid ............................................... 8-14
Window(s)
Automatic adjusting function ........................... 2-37
Cleaning................................................................... 7-3
Power windows................................................... 2-35
Windshield wiper and washer switch .................. 2-20
Wiper
Rear window wiper and washer switch........ 2-21
Windshield wiper and washer switch ........... 2-20
Wiper blades ....................................................... 8-19
X
Xenon headlights....................................................... 2-22


04.5.17/Z33-D/V5.0

10-6

QUICK REFERENCE1. Engine oil (P.8-10)
2. Brake fluid (P.8-13)
3. Meters and gauges (P.2-3)
4. Fuel filler lid release (P.3-13)
5. Hood release (P.3-9)
6. Seat belt (P.1-23)
7. Door lock/key (P.3-2)
8. Rear hatch release (Coupe) (P.3-10) or
Trunk lid release (Roadster) (P.3-11)
9. Engine coolant (P.8-8)
10. Windshield washer fluid (P.8-14)
11. Power steering fluid (P.8-13)
12. Battery (P.8-15)
13. Audio system (P.4-6)/
Heater and air conditioner (P.4-3)
14. Soft top (Roadster models) (P.3-18)
15. Fuel (P.3-13, P.9-3)
16. Spare tire (P.6-3, P.8-36)
STI0364

04.5.17/Z33-D/V5.0
