Height of viewDistance
between gridsDepth of distance
512,000 feet
(160,000 m)160 miles
(256 km)approx. 2,240
miles
(approx. 1,792 km)
128,000 feet
(40,000 m)40 miles
(64 km)approx. 560 miles
(approx. 896 km)
64,000 feet
(20,000 m)20 miles
(32 km)approx. 280 miles
(approx. 448 km)
32,000 feet
(10,000 m)10 miles
(16 km)approx. 140 miles
(approx. 224 km)
16,000 feet
(4,800 m)4.0 miles
(8 km)approx. 70 miles
(approx. 112 km)
8,000 feet
(2,400 m)2.0 miles
(4 km)approx. 35 miles
(approx. 56 km)
4,000 feet
(1,200 m)1.0 mile
(2 km)approx. 17-1/2
miles
(approx. 28 km)
2,000 feet
(600 m)1/2 mile
(1 km)approx. 8-3/4
miles
(approx. 14 km)
1,000 feet
(300 m)1/4 mile
(500 m)approx. 4-3/8
miles
(approx. 7 km)
Height of view: 1,000 feet (300 m)
Height of view: 16,000 feet
(4,800 m)
SWITCHING BETWEEN Bird-
viewTMand PLANVIEW DIS-
PLAYS
The BirdviewTMmode displays the view from
above, looking down toward the direction the
vehicle is traveling. This combines the detailed
display close to the vehicle and the long dis-
tance view in one screen.
INV1688
INV1689
INV1690
HOW DO I ADJUST THE DISPLAY?
11-3
terimage is inherent in displays and is not
abnormal.
INFO:
The screen may become distorted by strong
magnetic fields.
MAINTENANCE OF THE DIS-
PLAY
CAUTION
T o clean the display , never use a
rough cloth, alcohol, benzine,
thinner , any kind of solvent, or pa-
per towel with chemical cleaning
agent. They will scratch or dete-
riorate the panel.
Do not splash any liquid such as
water or car fragrance on the dis-
play . Contact with liquid will
cause the system to malfunction.If you need to clean the display screen, use a
dry soft cloth. If additional cleaning is neces-
sary , use a small amount of neutral detergent
with a soft cloth. Never soak the exterior with
water or detergent.
HOW DO I ADJUST THE DISPLAY?
11-22
