2004 MAZDA MODEL SPEED MX-5 MIATA Owners Manual

4-9
Before Driving Your Mazda
Driving Tips
Form No. 8T02-EA-03L
•Carry emergency gear, including tire
chains, window scraper, flares, a small
shovel, jumper cables, and a small bag
of sand or salt.
Ask an Authorized Mazda Dealer to
perform the following precautions:
• Have the proper ratio of antifreeze in
the radiator.
• Inspect the battery and its cables. Cold
reduces battery capacity.
• Use only cold-weather engine oil
(page 8-13).
• Inspect the ignition system for damage
and loose connections.
• Use washer fluid made with
antifreeze—but don
’t use engine
coolant antifreeze for washer fluid
(page 8-22).
• Don
’t use the parking brake in freezing
weather as the parking brake may
freeze. Instead, shift to P with an
automatic transmission and to 1 or R
with a manual transmission. Block the
rear wheels.

Snow Tires
Use snow tires on all four wheels
Don
’t go faster than 120 km/h (75 mph)
while driving with snow tires. Inflate
snow tires 30 kPa (0.3 kgf/cm2, 4.3 psi)
more than recommended on the tire
pressure label (driver ’s door), but never
more than the maximum cold-tire
pressure shown on the tires.
Your vehicle is originally equipped with
summer tires designed for optimum
traction on wet and dry roads. If your
vehicle is to be used on snow and ice
covered roads, you may find it necessary
to replace the original equipment tires
with snow tires, during the winter months.
Winter Driving
Mixing Tire Types:
Using tires different in size or type is
dangerous. Your vehicle ’s handling
could be greatly affected and result in
an accident. Use only the same size
and type tires (snow, radial, or non-
radial) on all four wheels.
Check local regulations before using
studded tires.
WARNING
CAUTION
J07S_8T02-EA-03L_Edition1.book Page 9 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-10
Before Driving Your Mazda
Driving Tips
Form No. 8T02-EA-03L

Tire Chains
Check local regulations before using tire
chains.
Install the chains on the rear tires.
Don
’t use chains on the front tires.
Use only SAE Class "S" chains, and make
sure they fit. Installing the chains1. Remove the wheel covers, or the chain
bands will scratch them.
2. Secure the chains on the rear tires as tightly as possible. Always follow the
chain manufacturer ’s instructions.
3. Retighten the chains after driving 1/2— 1 km (1/4— 1/2 mile).
•
Chains may scratch or chip
aluminum wheels. Install tire chains
on steel wheels only.
• Chains may affect handling.
• Don
’t go faster than 50 km/h (30
mph) or the chain manufacturer ’s
recommended limit, whichever is
lower.
• Drive carefully and avoid bumps,
holes, and sharp turns.
• Avoid locked-wheel braking.
• Don
’t use chains on a temporary
spare tire; it may result in damage to
the vehicle and to the tire.
• Don
’t use chains on roads that are
free of snow or ice. The tires and
chains could be damaged.
NOTE
Use of tire chains on a vehicle
equipped with 205/40R17
specification tires could cause
interference with the vehicle body and
scratching. If tire chains are to be used,
replace both front and rear tires with
205/45R16 tires. Please consult an
Authorized Mazda Dealer.
CAUTION
J07S_8T02-EA-03L_Edition1.book Page 10 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-11
Before Driving Your Mazda
Driving Tips
Form No. 8T02-EA-03L
Driving In Flooded Area
Driving with Wet Brakes:
Driving with wet brakes is dangerous.
Increased stopping distance or the
vehicle pulling to one side when
braking could result in a serious
accident. Light braking will indicate
whether the brakes have been
affected. Dry the brakes by driving
very slowly and applying the brakes
lightly until brake performance
returns to normal.
Make sure water does not enter the
vehicle interior or the engine area. The
vehicle interior could become wet or
the engine could be damaged.
WARNING
CAUTION
Overloading
Vehicle Load Weight:
The gross axle weight rating (GAWR)
and the gross vehicle weight rating
(GVWR) of your vehicle are on the
Motor Vehicle Safety Standard Label
on the driver’s door frame. Exceeding
these ratings can cause an accident or
vehicle damage. You can estimate the
weight of your load by weighing the
items (or people) before putting them
in the vehicle. Be careful not to
overload your vehicle.
WARNING
J07S_8T02-EA-03L_Edition1.book Page 11 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-12
Before Driving Your Mazda
Driving Tips
Form No. 8T02-EA-03L
The turbocharger greatly enhances engine power. Its advanced design provides better
operation and requires minimum additional maintenance. To get maximum performance
from your turbocharged engine, take note of the following tips:
•The turbocharged engine is designed for optimal operation with premium unleaded
gasoline (page 4-2). Do not use fuel with a lower octane rating. Extra fuel additives are
NOT recommended.
• Change the engine oil and filter using the turbo engine interval outlined in the
maintenance schedule (for your driving condition).
• Use only the recommended engine oil (page 8-13).Extra oil additives are NOT
recommended.
• After driving at freeway speeds or up a long hill, idle the engine at least 30 seconds to
cool the turbo. Avoid simply shutting the engine off abruptly after a hard or long drive.
Damage to the turbocharger may result.
• Don
’t race or over-rev the engine when starting. This should not be done with ANY
engine, especially not with one that ’s turbocharged.
• Do not add any aftermarket devices to alter the engine
’s ignition timing, fuel delivery, or
turbo boost pressure. This may lead to serious engine damage and may void your
warranty.
Turbocharger Information (MAZDASPEED MX-5)
J07S_8T02-EA-03L_Edition1.book Page 12 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-13
Before Driving Your Mazda
Form No. 8T02-EA-03L
To w i n g
Never tow a trailer with your Mazda.
Trailer Towing
J07S_8T02-EA-03L_Edition1.book Page 13 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

4-14
Form No. 8T02-EA-03L
J07S_8T02-EA-03L_Edition1.book Page 14 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

5-1
Form No. 8T02-EA-03L
5Driving Your Mazda
Explanation of instruments and controls.
Starting and Driving ..................................................................... 5-2
Ignition Switch .......................................................................... 5-2
Starting the Engine .................................................................... 5-3
Brake System ............................................................................. 5-4
Manual Transmission Operation ............................................... 5-9
Automatic Transmission Controls ........................................... 5-10
Power Steering ......................................................................... 5-14
Cruise Control* ....................................................................... 5-15
Instrument Cluster and Indicators ............................................ 5-18
Meters and Gauges .................................................................. 5-18
Warning/Indicator Lights and Beep Sounds ............................ 5-23
Warning/Indicator Lights ......................................................... 5-23
Beep Sounds ............................................................................ 5-30
Switches and Controls ................................................................. 5-31
Lighting Control ...................................................................... 5-31
Turn and Lane-Change Signals ............................................... 5-32
Fog Lights* .............................................................................. 5-32
Daytime Running Lights (Canada) .......................................... 5-33
Windshield Wipers and Washer ............................................... 5-33
Rear Window Defroster ........................................................... 5-35
Horn ......................................................................................... 5-35
Hazard Warning Flasher .......................................................... 5-36
*Some models.
J07S_8T02-EA-03L_Edition1.book Page 1 Monday, November 10, 2003 11:21 AM
Black process 45.0 ° 240.0 LPI

5-2
Driving Your Mazda
Form No. 8T02-EA-03L
Starting and Driving

Ignition Switch Positions
LOCK
The steering wheel locks to protect
against theft. Only in this position can the
key be removed.
Manual transmission
To turn the key from the ACC to the
LOCK position, push the key in at the
ACC position, then turn it to the LOCK
position. Automatic transmission
To turn the key from the ACC to the
LOCK position, the shift lever must be in
the P position.
Ignition Switch
LOCK
Push the key
ACC ON
Removing the Key:
It
’s dangerous to remove the key from
the ignition switch while the vehicle is
moving. Removing the key allows the
steering wheel to lock. You will lose
steering control and a serious
accident could occur.
Remove the key only when the vehicle
is parked.
Not Setting the Parking Brake:
Leaving the driver ’s seat without
setting the parking brake is
dangerous. Unexpected vehicle
movement could occur if the parking
brake is not set. This could cause an
accident. Before leaving the driver ’s
seat, always set the parking brake and
make sure the shift lever is in P with
an automatic transmission or in 1 or
R with a manual transmission.
LOCK Shift lever
engaged in P
(park)
ACC
ON
WARNING
