2004 Lexus GX470 Audio System / LEXUS 2004 GX470 FROM NOV. 2003 THROUGH DEC. 2003 PROD. OWNER'S MANUAL (OM60A74U)

AUDIO
328Push the Angleº switch on the screen or the ANGLEº
button on the controller, and the changing angle screen
will appear.
The angle can be selected for discs that are multi-angle
compatible when the º mark appears on the screen. Each
time you push the Angleº switch, the angle changes. The
angle number which you can select will appear on the screen.
To turn off the screen, push the Hideº switch.
Push the Backº switch to return to the previous screen.(k) Changing the initial setting
22PY074

1For DVD video2For DVD audio
3Controller button

AUDIO
329 Push the Set Upº switch on the screen or the SET UPº
button on the controller, and the initial setting screen will
appear. You can change the initial setting.
After the setting is done, the player plays from the beginning
of the chapter or the track.
There are initial setting switches on the Setup Menu 1º
screen (1) and Setup Menu 2º screen (2).
To change the screen, push the Top Pageº or Second Pageº
switch on the screen.
After you change the initial setting, push the Enterº switch.
The initial setting switch will be turned off and return to the
picture previously.
When the Initial Settingº switch on Setup Menu 2º is pushed,
all menus are initialized.(l) Changing the audio language
Push the Audio Lang.º switch on the Setup Menu 1º
screen (1) and the Select Audio Languageº screen
(2) appear.
Select the language you want to hear on the screen.
To return to the Setup Menu 1º screen, push the Backº switch.
If you cannot find a language you want to hear, push the
Othersº switch. The Enter Audio Lang. Codeº screen will
appear.

AUDIO
330
To enter the code of the language you want to hear, push the
number of the language code. For details about the language
codes, see the language code list. If you enter a wrong
number, push the Clearº switch to delete the number.
If numbers which are not on the list are entered and the Enterº
switch is pushed, the Incorrect Codeº screen will appear.
Push the language code you want to hear again.
To return to the Select Audio Languageº screen, push the
Backº switch.(m) Changing the subtitle language
Push the Subtitle Lang.º switch on the Setup Menu 1º
screen (1) and the Select Subtitle Lang.º screen (2)
appear.
Select the language you want to read on the screen.
To return to the Setup Menu 1º screen, push the Backº switch.
If you cannot find a language you want to read, push the
Othersº switch. The Enter Subtitle Lang. Codeº screen will
appear.

AUDIO
331
To enter the code of the language you want to read, push the
number of the language code. For details about the language
codes, see the language code list. If you enter a wrong
number, push the Clearº switch to delete the number.
Push the Enterº switch on the screen. If numbers which are
not on the list are entered and the Enterº switch is pushed, the
Incorrect codeº screen will appear. Push the language code
you want to read again.
To return to the Select Subtitle Lang.º screen, push the Backº
switch on the screen.(n) Changing the DVD language
Push the DVD Languageº switch on the Setup Menu 1º
screen (1) and Select DVD Languageº screen (2)
appear.
Select the language you want to read on the screen.
If you cannot find a language you want to read, push the
Othersº switch. The Enter DVD Language. Codeº screen will
appear.
To return to the Setup Menu 1º screen, push the Backº switch.
If you cannot find a language you want to read, push the
Othersº switch. The Enter DVD Language Codeº screen will
appear.

AUDIO
332
To enter the code of the language you want to read, push the
number of the language code. For details about the language
codes, see the language code list. If you enter a wrong
number, push the Clearº switch to delete the number.
Push the Enterº switch on the screen. If numbers which are
not on the list are entered and the Enterº switch is pushed, the
Incorrect codeº screen will appear. Push the language code
you want to read again.
To return to the Select DVD Languageº screen, push the
Backº switch on the screen.(o) Turning the angle mark on or off
The angle mark can be turned on for discs that are
multi-angle compatible.
Each time you push the Angle Markº switch on the screen, the
angle mark turns on or off alternately.

AUDIO
333 (p) Setting level of viewer restrictions
You can restrict the play back screen by setting the viewer
restrictions. You can prevent the restriction with a
password. Some discs do not supply a restriction.
To set the level of viewer restriction, push the Parentalº switch
on the Setup Menu 1º screen. The Enter Personal Codeº
screen will appear.
Push the number for the password and the Enterº switch. The
Select Restriction Levelº screen will appear.
If you enter a wrong number, push the Clearº switch to delete
the number.
You cannot change the setting without inputting the password.
When you forget or change the password, push the Clearº
switch ten times to initialize the password.
To return to the Setup Menu 1º screen, push the Backº switch.

AUDIO
334
Push a parental level (1 Ð 8). The smaller the level number,
the stricter the age limit. Push the Backº switch to return to the
Setup Menu 1º screen.(q) Setting the display mode
Each time you push the Display Modeº switch on the
Setup Menu 2º screen, the display mode is changed from
wide mode to auto mode.

AUDIO
335 (r) Language code list
Code
Language
1001Japanese
0514English
0618French
0405German
0920Italian
0519Spanish
2608Chinese
1412Dutch
1620Portuguese
1922Swedish
1821Russian
111 5Korean
0512Greek
0101Afar
0102Abkhazian
0106Afrikaans
0113Amharic
0118Arabic
0119Assamese
0125Aymara
