2004 Lexus ES330 Destination Input and Route Guidance / LEXUS 2004 ES330 OWNER'S MANUAL (OM33633U)

AIR CONDITIONING
208
INFORMATION
The air conditioning filter should be installed properly
in position. The use of air conditioning with the filter
removed may cause deteriorated dustproof
performance and then affect air conditioning
performance.

AIR CONDITIONING
209

SECTION 2 ± 2
210
AIR CONDITIONING AND AUDIO
Audio
Audio system (type A)211 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio system (type B)235 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
For vehicles equipped with Navigation System,
please refer to the separate Navigation System
Owner's Manualº.

AUDIO
211
AUDIO SYSTEM (type A)
Quick reference for your audio system
20E426

You can adjust the brightness of the display. See Instrument panel light controlº on page 68 for details.

AUDIO
212
1Ejecting a compact disc
(See page 224 for details.)
2Function buttons
1 Ð 6:Station selector buttons
(See page 220 for details.)
SCAN:Scan tuning
(See page 221 for details.)
P.SCAN:Preset scan tuning
(See page 221 for details.)
3Display of functions in TAPE or CD mode
:DOLBY NR
(See page 222 for details.)
:Rewinding or reversing
(See page 222 or 227 for details.)


:Fast forwarding
(See page 222 or 227 for details.)
RPT:Automatic repeat
(See page 223 or 228 for details.)
SKIP:Automatic skip of blank portions of tape
(See page 223 for details.)
:Disc selection
(See page 226 for details.)
RAND:Random access
(See page 228 for details.)
SCAN:Scan selection
(See page 227 for details.)
4Compact disc slot
(See page 224 for details.)
5Automatic sound levelizer/Mute
(See page 214 or 216 for details.)
6TUNE/AUDIO CONTROL knob
(See page 215 for details.)
7

:Side change
(See page 222 for details.)
8Mode selectors
(See page 215 for details.)
9Stopping and ejecting a cassette tape
(See page 221 for details.)
10Turning the system on and adjusting the volume
(See page 214 for details.)
11Cassette tape slot
(See page 221 for details.)
12Radio mode:Seek tuning
(See page 220 for details.)
TAPE mode:Direct access to a desired program
(See page 223 for details.)
CD mode:Direct access to a desired program
(See page 227 for details.)

AUDIO
213
Using your audio system: some basics
This section describes some of the basic features of the Lexus
audio system. Some information may not pertain to your
system.Your audio system adjusts to the optimum volume and tone
quality automatically. While the system is adjusting the audio
sound, the audio sound fades out and then fades in.
Your audio system works when the ignition switch is in the
ACCº or ONº position.
NOTICE
To prevent the battery from being discharged, do not
leave the car audio on longer than necessary when the
engine is not running.

AUDIO
214(a) Turning the system on and off
Push this knob to turn the audio system on and off. Turn
this knob to adjust the volume.
The system turns on in the last mode used.
Push the MUTEº button to decrease the volume
momentarily.
To return to its original volume, push the same button again.
When the audio system is turned on, the mute is always off
regardless of the previous mode.

AUDIO
215
Push the AMº, FMº, TAPEº or DISCº button to turn on
that mode. The selected mode turns on directly.
Push these buttons if you want to switch from one mode to
another.
If the tape or disc is not set, the cassette player or compact disc
player does not turn on.
You can turn off each player by ejecting the cassette tape or
compact disc. If the audio system was previously off, then the
entire audio system will be turned off when you eject the
cassette tape or compact disc. If the another function was
previously playing, it will come on again.In the TAPEº or CDº mode, the applicable functions are
shown in the lowest part of the display. Push the switch
just below to turn on each function.
(b) Tone and balance
How good an audio program sounds to you is largely
determined by the mix of the treble, mid-range, and bass
levels. In fact, different kinds of music and vocal programs
usually sound better with different mixes of treble, mid-range
and bass.
A good balance of the left and right stereo channels and of the
front and rear sound levels is also important.
