INTERIOR EQUIPMENT
88
COAT HOOKS
To use the coat hook, push the hook.
CAUTION
Do not hook a hanger, heavy or sharp pointed object on
the coat hook. If the curtain shield airbag inflates, those
items will be hurled away with great force or the curtain
shield airbag may not activate correctly. When you
hang clothes, hang them on the coat hook directly.
REAR ELECTRIC SUNSHADE
14E137
To raise the rear electric sunshade, push the switch. To
lower the sunshade, push the same switch again.
The sunshade works when the ignition switch is in the ONº
position.
When the selector lever is shifted into the Rº position
while the sunshade is raised, the sunshade will be
automatically lowered. To raise the sunshade, move the
selector lever out of Rº position and push the switch
again.

Finish
INTERIOR EQUIPMENT
89
CAUTION
Do not touch the brackets fastening the sunshade to
avoid injuring your fingers or hands.
Do not put your fingers in the sunshade groove while
the sunshade is operating to avoid getting them
caught or injured by the runner.
NOTICE
To prevent the vehicle battery from being discharged,
always operate the sunshade while the engine is
running.
Observe the following to avoid damage and/or
malfunction:
Do not overload the sunshade motor and other parts
(for instance by pushing down on the sunshade
bracket while it is opening).
Do not place anything where they may hinder the
opening/closing of the sunshade.
Do not affix anything to the sunshade.
Clean the sunshade groove if there is any foreign
matter or dust on it.
Do not operate the rear electric sunshade repeatedly
for a long time as its motor may overheat.
TIE-DOWN HOOKS
14E092
To secure your luggage, use the tie-down hooks as shown
above.
See Stowage precautionsº on page 277 for precautions when
loading luggage.

Finish
INTERIOR EQUIPMENT
90

SECTION 1 ± 5
91
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood92 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel tank cap96 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon roof99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EXTERIOR EQUIPMENT
92
HOOD
1. To open the hood, pull the hood lock release lever under
the instrument panel. The hood will spring up slightly.
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. Then lower the hood and make
sure it locks.
CAUTION
Before driving, be sure that the hood is securely locked.
Otherwise, the hood may open unexpectedly while
driving and an accident may occur.

EXTERIOR EQUIPMENT
93
TRUNK LID
Trunk lid opener
To open the trunk lid, push the switch.
To close the trunk lid, lower it and press down on it. After
closing the trunk lid, try pulling it up to make sure it is securely
closed.
The trunk lid can be unlocked using the wireless remote control
key. For details, see page 21.
CAUTION
Keep the trunk lid closed while driving. This not only
keeps the luggage from being thrown out, but also
prevents exhaust gases from entering the vehicle.
Trunk lid opener main switch

1Main switch2Operative3Inoperative
If you do not want to activate the trunk lid opener system,
turn off the main switch in the glove box. To turn it on,
push in the main switch.

EXTERIOR EQUIPMENT
94The trunk lid can be opened using a loop of wire in the trunk
even with the main switch in the glove box turned off. When
keeping items in the trunk, be sure to turn off the main switch
and lock the glove box and rear armrest door. For locking the
glove box, see page 77. For locking the rear armrest door, see
page 86.
In case the opener is not actuated
1. Pull down the rear armrest and open the rear armrest
door.
2. Pull the loop of wire to unlock the trunk lid.
This is used in case the trunk lid cannot be unlocked due to a
discharged battery or other trouble.

EXTERIOR EQUIPMENT
95
Internal trunk release handle
If a person is locked in the trunk, he/she can pull down the
phosphorescent handle on the inside of trunk lid to open
the trunk lid.
The phosphorescent (glow-in-the-dark) handle will continue
to glow for a time after the trunk lid is closed. Exposing the
handle to stronger light will cause it to glow longer.
CAUTION
Always lock the trunk lid and all doors, and keep
away the vehicle keys out of children's reach.
Never leave children unattended in the vehicle.
Unsupervised children may lock themselves in the
vehicle or trunk and suffer serious injuries or death.
