WINDSHIELD GLASS
GW-11
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
WINDSHIELD GLASSPFP:72712
Removal and InstallationEIS002UL
REMOVAL
1. Remove inside mirror. Refer to GW-77, "Removal and Installation" .
2. Partially remove the headlining (front edge). Refer to EI-37, "
HEADLINING" .
3. Remove cowl top cover. Refer to EI-18, "
Removal and Installation" .
4. Apply a protective tape around the windshield glass to protect the painted surface from damage.

Remove glass using piano wire or power cutting tool and an inflatable pump bag.

If a windshield glass is to be reused, mark the body and the glass with mating marks.
WA RN ING:
When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent
glass splinters from entering your eyes or cutting your hands.
CAUTION:

When a windshield glass is to be reused, do not use a cutting knife or power cutting tool.

Be careful not to scratch the glass when removing.

Do not set or stand glass on its edge. Small chips may develop into cracks.
INSTALLATION

Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur-
nished with it.

While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced
out by passenger compartment air pressure when a door is closed.

The molding must be installed securely so that it is in position and leaves no gap.
LIIA0652E
PIIA0186E

REAR WINDOW GLASS AND MOLDING
GW-13
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
REAR WINDOW GLASS AND MOLDINGPFP:79712
Removal and InstallationEIS0 05 T U
REMOVAL
1. Remove the rear spoiler. Refer to EI-26, "REAR SPOILER" .
2. Disconnect the rear window defogger electrical connectors.
3. Remove the rear glass stays.
4. Remove the hinge nuts and the rear glass assembly.
5. Remove the striker and handle.
1. Back door assembly 2. Weatherstrip 3. Rear glass stay RH, LH
4. Rear window hinge assembly RH,
LH5. Rear window glass handle 6. Rear window glass latch striker
7. Rear glass assembly
LIIA1892E

GW-14
REAR WINDOW GLASS AND MOLDING
Revision: August 20072004 QX56
6. Remove the rear glass hinges.
INSTALLATION
Installation is in the reverse order of removal.

POWER WINDOW SYSTEM
GW-15
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
POWER WINDOW SYSTEMPFP:25401
Component Parts and Harness Connector LocationEIS002UM
System DescriptionEIS002UN
Power is supplied at all time

from 50A fusible link (letter f , located in the fuse and fusible link box)

to BCM terminal 70

through BCM terminal 69

to main power window and door lock/unlock switch terminal 19

to power window and door lock/unlock switch RH terminal 10.
With ignition switch in ON or START position,
Power is supplied

through 10A fuse (No. 59, located in the fuse and relay box)

to BCM terminal 38

through BCM terminal 68

to main power window and door lock/unlock switch terminal 10.

to rear power vent window relays (OPEN and CLOSE) terminal 1.
With ignition switch in ON or START position,
Ground is supplied

to BCM terminal 67

to main power window and door lock/unlock switch terminal 17

to power window and door lock/unlock switch RH terminal 11

through body grounds M57, M61 and M79.
LIIA1890E

GW-16
POWER WINDOW SYSTEM
Revision: August 20072004 QX56
MANUAL OPERATION
Front Driver Side Door
WINDOW UP
When the front LH switch in the main power window and door lock/unlock switch is pressed in the up position,
Power is supplied

through main power window and door lock/unlock switch terminal 8

to front power window motor LH terminal 2.
Ground is supplied

through main power window and door lock/unlock switch terminal 11

to front power window motor LH terminal 1.
Then, the motor raises the window until the switch is released.
WINDOW DOWN
When the front LH switch in the main power window and door lock/unlock switch is pressed in the down posi-
tion
Power is supplied

through main power window and door lock/unlock switch terminal 11

to front power window motor LH terminal 1.
Ground is supplied

through main power window and door lock/unlock switch terminal 8

to front power window motor LH terminal 2.
Then, the motor lowers the window until the switch is released.
Front Passenger Side Door
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH OPERATION
WINDOW UP
When the power window and door lock/unlock switch RH is pressed in the up position
Power is supplied

through power window and door lock/unlock switch RH terminal 8

to front power window motor RH terminal 2.
Ground is supplied

through power window and door lock/unlock switch RH terminal 9

to front power window motor RH terminal 1.
Then, the motor raises the window until the switch is released.
WINDOW DOWN
When the power window and door lock/unlock switch RH is pressed in the down position
Power is supplied

through power window and door lock/unlock switch RH terminal 9

to front power window motor RH terminal 1.
Ground is supplied

through power window and door lock/unlock switch RH terminal 8

to front power window motor RH terminal 2.
Then, the motor lowers the window until the switch is released.
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OPERATION
Signal is sent

through main power window and door lock/unlock switch terminal 14

to power window and door lock/unlock switch RH terminal 16.
The operation of power window after receiving the signal is the same as operating the power window with
power window and door lock/unlock switch RH.
Rear Door (LH or RH)
REAR POWER WINDOW SWITCH LH OR RH OPERATION
WINDOW UP
When the rear power window switch LH or RH is pressed in the up position
Power is supplied

POWER WINDOW SYSTEM
GW-17
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56

to rear power window control unit LH or RH terminal 1

through rear power window control unit LH or RH terminal 7

through rear power window switch LH or RH terminal 2 and 3

through rear power window switch LH or RH terminal 5

through rear power window control unit LH or RH terminal 11

to rear power window motor LH or RH terminal 2.
Ground is supplied

to rear power window control unit LH or RH terminal 15

through rear power window control unit LH or RH terminal 16

through rear power window switch LH or RH terminal 1 and 7

through rear power window switch LH or RH terminal 4

through rear power window control unit LH or RH terminal 12

to rear power window motor LH or RH terminal 1.
Then, the motor raises the window until the switch is released.
WINDOW DOWN
When the rear power window switch LH or RH is pressed in the down position
Power is supplied

to rear power window control unit LH or RH terminal 1

through rear power window control unit LH or RH terminal 7

through rear power window switch LH or RH terminal 2 and 3

through rear power window switch LH or RH terminal 4

through rear power window control unit LH or RH terminal 12

to rear power window motor LH or RH terminal 1.
Ground is supplied

to rear power window control unit LH or RH terminal 15

through rear power window control unit LH or RH terminal 16

through rear power window switch LH or RH terminal 1 and 7

through rear power window switch LH or RH terminal 5

through rear power window control unit LH or RH terminal 11

to rear power window motor LH or RH terminal 2.
Then, the motor lowers the window until the switch is released.
MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OPERATION
Signal is sent

through main power window and door lock/unlock switch terminal 14

to rear power window control unit LH or RH terminal 1.
The operation of power window after receiving the signal is the same as operating the power window with rear
power window switch LH or RH.
VENT WINDOW CLOSE
When the rear power vent window switch is pressed in the close position
Power is supplied

to rear power vent window relay (CLOSE) terminal 5

through rear power vent window relay (CLOSE) terminal 3

to rear power vent window motors terminal 2.
Ground is supplied

to rear power vent window relay (OPEN) terminal 4

through rear power vent window relay (OPEN) terminal 3

to rear power vent window motors terminal 1.
Then, the motors close the windows until the switch is released.
VENT WINDOW OPEN
When the main power window and door lock/unlock switch (rear LH) is pressed in the open position
Power is supplied

GW-18
POWER WINDOW SYSTEM
Revision: August 20072004 QX56

to rear power vent window relay (OPEN) terminal 5

through rear power vent window relay (OPEN) terminal 3

to rear power vent window motors terminal 1.
Ground is supplied

to rear power vent window relay (CLOSE) terminal 4

through rear power vent window relay (CLOSE) terminal 3

to rear power vent window motors terminal 2.
Then, the motors open the windows until the switch is released.
AUTO OPERATION
The power window AUTO feature enables the driver to open or close the window without holding the window
switch in the down or up position.
POWER WINDOW SERIAL LINK
Main power window and door lock/unlock switch, power window and door lock/unlock switch RH, rear power
window control units and BCM transmit and receive the signal by power window serial link.
The signal is transmitted from BCM to main power window and door lock/unlock switch and power window and
door lock/unlock switch RH

Keyless power window down signal.

Rear power window switch illumination.
The signal is transmitted from main power window and door lock/unlock switch to power window and door
lock/unlock switch RH

Front door window RH operation signal.

Power window control by front door lock assembly LH (key cylinder switch) signal.

Power window lock signal.

Retained power operation signal.

Rear power window operation.
POWER WINDOW LOCK
The power window lock is designed to lock operation of all windows except for front door window LH.
When in the lock position, the power window lock signal is transmitted to power window and door lock/unlock
switch RH by power window serial link. This prevents the power window motor from operating.
RETAINED POWER OPERATION
When the ignition switch is turned to the OFF position from ON or START position.
Power is supplied for 45 seconds

to main power window and door lock/unlock switch terminal 10

from BCM terminal 68.
When power and ground are supplied, the BCM continues to be energized, and the power window can be
operated.
The retained power operation is canceled when the front LH or front RH door is opened.
RAP signal period can be changed by CONSULT-II. Refer to GW-33, "
CONSULT-II Function (BCM)" .
ANTI-PINCH SYSTEM
Main power window and door lock/unlock switch, power window and door lock/unlock switch RH and rear
power window control unit LH and RH monitors the power window motor operation and the power window
position (full closed or other) for each power window by the signals from encoder and limit switch in power win-
dow motor.
When a window switch detects interruption during the following close operation,

automatic close operation when ignition switch is in the ON position

automatic close operation during retained power operation
Main power window and door lock/unlock switch, power window and door lock/unlock switch RH and rear
power window control unit LH and RH controls each power window motor for open and the power window will
be lowered about 150 mm (5.91 in).
