6. PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-44, "
Idle Air Volume Learning" .
Is Idle Air Volume Learning carried out successfully?
Ye s o r N o
Yes >> GO TO 7.
No >> 1. Follow the instruction of Idle Air Volume Learning.
2. GO TO 4.
7. CHECK TARGET IDLE SPEED AGAIN
With CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Read idle speed in “DATA MONITOR” mode with CONSULT-II.
Without CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed.
OK or NG
OK >> GO TO 10.
NG >> GO TO 8.
8. DETECT MALFUNCTIONING PART
Check the following.

Check camshaft position sensor (PHASE) and circuit. Refer to EC-261 .

Check crankshaft position sensor (POS) and circuit. Refer to EC-255 .
OK or NG
OK >> GO TO 9.
NG >> 1. Repair or replace.
2. GO TO 4.
9. CHECK ECM FUNCTION
1. Substitute another known-good ECM to check ECM function. (ECM may be the cause of an incident, but
this is a rare case.)
2. Perform initialization of IVIS (NATS) system and registration of all IVIS (NATS) ignition key IDs. Refer to
BL-138, "
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)" .
>> GO TO 4. 650 ± 50 rpm (in P or N position)
650 ± 50 rpm (in P or N position)

EC-84Revision: August 2007
TROUBLE DIAGNOSIS
2004 QX56
Symptom Matrix ChartUBS00H00
SYSTEM — BASIC ENGINE CONTROL SYSTEM
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel pump circuit 1 1 2 3 2 2 2 3 2EC-601
Fuel pressure regulator system 3 3 4 4 4 4 4 4 4 4EC-46
Injector circuit 1 1 2 3 2 2 2 2EC-595
Evaporative emission system 3 3 4 4 4 4 4 4 4 4EC-633
Air Positive crankcase ventilation sys-
tem
334444444 41EC-645
Incorrect idle speed adjustment 1 1 1 1 1EC-79
Electric throttle control actuator 1 1 2 3 3 2 2 2 2 2 2EC-365,
EC-367
Ignition Incorrect ignition timing adjustment 3 3 1 1 1 1 1 1EC-79
Ignition circuit 1 1 2 2 2 2 2 2EC-583
Main power supply and ground circuit 2 2 3 3 3 3 3 2 3EC-128
Mass air flow sensor circuit
1
122
222 2EC-146,
EC-154
Engine coolant temperature sensor circuit
333EC-165,
EC-178
A/F sensor 1 circuitEC-429
,
EC-437
,
EC-445
,
EC-454
,
EC-463
,
EC-472
,
EC-484
Throttle position sensor circuit
22EC-171
,
EC-236
,
EC-420
,
EC-422
,
EC-569
Accelerator pedal position sensor circuit 3 2 1EC-424
,
EC-556
,
EC-562
,
EC-576
Knock sensor circuit 2 3EC-250
Crankshaft position sensor (POS) circuit 2 2EC-255
Camshaft position sensor (PHASE) circuit 3 2EC-261

TROUBLE DIAGNOSIS
EC-85
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX56
1 - 6: The numbers refer to the order of inspection.
(continued on next page)
SYSTEM — ENGINE MECHANICAL & OTHER
Vehicle speed signal circuit 2 3 3 3EC-340
Power steering pressure sensor circuit 2 3 3EC-346
ECM 22333333333EC-351,
EC-361
PNP switch circuit 3 3 3 3 3EC-546
Refrigerant pressure sensor circuit 2 3 3 4EC-607
Electrical load signal circuit 3EC-612
Air conditioner circuit 2 2 3 3 3 3 3 3 3 3 2AT C - 3 3
ABS actuator and electric unit (control unit) 4BRC-11
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel tank
5
5FL-9
Fuel piping 5 5 5 5 5 5FL-3
Vapor lock—
Valve deposit
555555 5—
Poor fuel (Heavy weight gaso-
line, Low octane)—

EC-96Revision: August 2007
TROUBLE DIAGNOSIS
2004 QX56
ECM Harness Connector Terminal LayoutUBS00H03
ECM Terminals and Reference ValueUBS00H04
PREPARATION
1. ECM is located in the engine room passenger side behind bat-
tery.
2. Remove ECM harness connector.
3. When disconnecting ECM harness connector, loosen it with
levers as far as they will go as shown in the figure.
4. Connect a break-out box (SST) and Y-cable adapter (SST)
between the ECM and ECM harness connector.

Use extreme care not to touch 2 pins at one time.

Data is for comparison and may not be exact.
ECM INSPECTION TABLE
Specification data are reference values and are measured between each terminal and ground.
Pulse signal is measured by CONSULT-II.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECMs transistor. Use a ground other than ECM terminals, such as the ground.
PBIB1192E
BBIA0386E
BBIA0387E
TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
1 B ECM ground[Engine is running]

Idle speedBody ground
2O/BA/F sensor 1 heater
(bank 1)[Engine is running]

Warm-up condition

Idle speedApproximately 5V
PBIB1584E

TROUBLE DIAGNOSIS
EC-97
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: August 20072004 QX563LThrottle control motor relay
power supply[Ignition switch: ON]BATTERY VOLTAGE
(11 - 14V)
4 L/W Throttle control motor (Close)[Ignition switch: ON]

Engine stopped

Shift lever position: D

Accelerator pedal: Released0 - 14V
5 L/B Throttle control motor (Open)[Ignition switch: ON]

Engine stopped

Shift lever position: D

Accelerator pedal: Fully depressed0 - 14V
6GRHeated oxygen sensor 2
heater (bank 1)[Engine is running]

Engine speed is below 3,600 rpm after the
following conditions are met.
–Engine: After warming up
–Keeping the engine speed between 3,500
and 4,000 rpm for 1 minute and at idle for 1
minute under no load0 - 1.0V
[Ignition switch: ON]

Engine stopped
[Engine is running]

Engine speed is above 3,600 rpm.BATTERY VOLTAGE
(11 - 14V)
12 RPower steering pressure
sensor[Engine is running]

Steering wheel is being turned.0.5 - 4.5V
[Engine is running]

Steering wheel is not being turned.0.4 - 0.8V
13 OCrankshaft position sensor
