2004 INFINITI QX56 sensor

RSU-44
HEIGHT SENSOR
Revision: August 20072004 QX56
HEIGHT SENSORPFP:53820
Removal and InstallationEES0011U
Rear Load Leveling Air Suspension System
REMOVAL
1. Use CONSULT-II “EXHAUST SOLENOID” active test to release the air pressure from the rear load level-
ing air suspension system.
2. Disconnect the electrical connector for the height sensor.
3. Remove the two height sensor bolts and height sensor arm
bracket bolt.
4. Remove the height sensor.
LEIA0072E
1. Rear load leveling air suspension
hose, RH2. Shock absorber, RH 3. Height sensor
4. Rear load leveling air suspension
hose, LH5. Shock absorber, LH 6. Rear load leveling air suspension
compressor assembly
LEIA0080E

HEIGHT SENSOR
RSU-45
C
D
F
G
H
I
J
K
L
MA
B
RSU
Revision: August 20072004 QX56
INSTALLATION
Installation is in the reverse order of removal.
1. Start the engine.
2. Use CONSULT-II to perform "STANDARD HEIGHT LEVEL" work support function.
3. Using data monitor of CONSULT-II, verify "HEIGT CALC" is at 0 mm.
4. Check the vehicle height. Refer to RSU-48, "
Wheelarch Height (Unladen*1 )" . If vehicle height is not
within ± 10 mm (0 ± 0.39 in) of the specification, perform the initialization procedure. Refer to RSU-46,
"Initialization Procedure" .

SB-4
SEAT BELTS
Revision: August 20072004 QX56
REMOVAL OF SEAT BELT RETRACTOR
CAUTION:

Before servicing SRS, turn the ignition switch off, disconnect both battery cables and wait at least
3 minutes.
1. Remove the center pillar upper/lower finishers. Refer to EI-34, "
BODY SIDE TRIM" .
2. Remove the seat belt retractor anchor bolts and seat belt retractor and belt assembly.

On RH side, disconnect the seat belt tension sensor.
3. Disconnect the seat belt pre-tensioner electrical connector.
CAUTION:

For installing/removing seat belt pre-tensioner connector,
insert a thin screwdriver wrapped in tape into the notch, lift
the lock and remove the connector.

Install the connector with the lock raised, and push the lock
into the connector.
INSTALLATION OF SEAT BELT RETRACTOR
Installation is in the reverse order of removal.

Install the seat belt retractor and belt assembly upper bolt first.

Ensure that seat belt height adjuster is locked in the lowest position during installation.
WHIA0237E
PHIA0341E

SE-1
SEAT
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION SE
A
B
SE
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Work ................................................ 3
PREPARATION ........................................................... 4
Special Service Tool ................................................. 4
Commercial Service Tool ......................................... 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINER ....................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS .................................................................. 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
AUTOMATIC DRIVE POSITIONER ...........................11
Component Parts And Harness Connector Location
....11
Manual Operation ................................................... 12
Automatic Operation .............................................. 12
System Description ................................................ 12
FAIL-SAFE MODE .............................................. 13
CANCEL OF FAIL-SAFE MODE ......................... 13
MEMORY STORING AND KEYFOB INTER-
LOCK STORING ................................................. 14
MEMORY OPERATION ...................................... 15
ENTRY OPERATION .......................................... 15
EXITING OPERATION ........................................ 15KEYFOB INTERLOCK OPERATION .................. 16
CAN Communication System Description .............. 16
Schematic ............................................................... 17
Wiring Diagram — AUT/DP — ............................... 19
Terminals and Reference Values for BCM .............. 29
Terminals and Reference Values for Driver Seat
Control Unit ............................................................. 29
Terminals and Reference Values for Automatic
Drive Positioner Control Unit .................................. 31
Work Flow ............................................................... 33
Preliminary Check .................................................. 34
SETTING CHANGE FUNCTION ......................... 34
POWER SUPPLY AND GROUND CIRCUIT
INSPECTION ...................................................... 34
CONSULT-II Function (AUTO DRIVE POS.) .......... 37
CONSULT-II INSPECTION PROCEDURE .......... 37
SELF-DIAGNOSIS RESULTS ............................. 39
DATA MONITOR ................................................. 40
ACTIVE TEST ..................................................... 41
CAN Communication Inspection Using CONSULT-
II (Self-Diagnosis) ................................................... 41
Symptom Chart ....................................................... 41
Sliding Motor Circuit Inspection .............................. 43
Reclining Motor LH Circuit Inspection .................... 44
Lifting Motor (Front) Circuit Inspection ................... 46
Lifting Motor (Rear) Circuit Inspection .................... 47
Pedal Adjusting Motor Circuit Inspection ................ 49
Mirror Motor LH Circuit Check ................................ 50
Mirror Motor RH Circuit Check ............................... 52
Steering Wheel Tilt Circuit Inspection ..................... 53
Sliding Sensor Circuit Inspection ............................ 55
Reclining Sensor Circuit Inspection ........................ 56
Lifting Sensor (Front) Circuit Inspection ................. 57
Lifting Sensor (Rear) Circuit Inspection .................. 58
Pedal Adjusting Sensor Circuit Inspection .............. 59
Mirror Sensor LH Circuit Check .............................. 60
Mirror Sensor RH Circuit Check ............................. 62
Steering Wheel Tilt Sensor Circuit Inspection ........ 64
Sliding Switch Circuit Inspection ............................. 66
Reclining Switch Inspection .................................... 67

SE-2Revision: August 20072004 QX56 Lifting Switch (Front) Circuit Inspection .................. 69
Lifting Switch (Rear) Circuit Inspection ................... 70
Power Seat Switch Ground Inspection ................... 71
Pedal Adjusting Switch Circuit Inspection .............. 72
Door Mirror Switch (Changeover Switch) Circuit
Check ..................................................................... 74
Door Mirror Switch (Mirror Switch) Circuit Check ... 75
Door Mirror Switch Ground Circuit Inspection ........ 76
Seat Memory Switch Circuit Inspection .................. 77
Seat Memory Indicator Lamp Circuit Inspection ..... 79
Door Mirror Sensor Power Supply and Ground Cir-
cuit inspection ......................................................... 80
A/T Device (Detent Switch) Circuit Inspection ........ 81
Steering Wheel Tilt Switch Circuit Inspection ......... 82
Front Door Switch LH Circuit Inspection ................. 84
UART Communication Line Circuit Inspection ........ 85
Removal and Installation ........................................ 87
POWER SEAT ........................................................... 88
Wiring Diagram — SEAT — for Passenger Seat .... 88
HEATED SEAT .......................................................... 89Description ..............................................................89
Schematic ...............................................................90
Wiring Diagram — HSEAT — .................................91
FRONT SEAT ............................................................96
Components ............................................................96
Removal and Installation .........................................99
REMOVAL ............................................................99
INSTALLATION ....................................................99
Disassembly and Assembly ....................................99
SEATBACK TRIM AND PAD ...............................99
REMOVAL OF SEATBACK ASSEMBLY ........... 101
INSTALLATION OF SEATBACK ASSEMBLY ... 101
SEAT CUSHION TRIM AND PAD ...................... 101
REAR SEAT ............................................................. 103
Removal and Installation ....................................... 103
SECOND ROW OUTBOARD ............................ 103
SECOND ROW CENTER .................................. 103
THIRD ROW ...................................................... 103
Disassembly and Assembly .................................. 105

AUTOMATIC DRIVE POSITIONER
SE-29
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
Terminals and Reference Values for BCMEIS0038I
Terminals and Reference Values for Driver Seat Control UnitEIS0038J
TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
11 O Ignition switch (ACC or ON) Ignition switch (ACC or ON position) Battery voltage
38 W/L Ignition switch (ON or START)Ignition switch (ON or START posi-
tion)Battery voltage
39 W CAN-H — —
40 R CAN-L — —
47 SB Front door switch LH ON (Open) → OFF (Closed) 0 → Battery voltage
67 B Ground — 0
70 W/BBattery power supply (Fusible
link)— Battery voltage
TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
1 L UART LINE (RX)Pedal adjusting switch ON (FOR-
WARD or BACKWARD operation)
3 W CAN-H — —
6 O Ignition switch (START) Ignition switch (START position) Battery voltage
9 L/R Reclining motor sensor signalON (seat reclining motor opera-
tion)
Other than above 0 or 5
10 W Rear lifting motor sensor signalON (rear lifting motor operation)
Other than above 0 or 5
11 R / BSliding switch BACKWARD sig-
nalON (seat sliding switch BACK-
WARD operation)0
Other than above Battery voltage
12 O/BReclining switch BACKWARD
signalON (seat reclining switch BACK-
WARD operation)0
Other than above Battery voltage
13 L/B Front lifting switch DOWN signalON (front lifting switch DOWN
operation)0
Other than above Battery voltage
PIIA4813E
SIIA0692J
SIIA0693J

SE-30
AUTOMATIC DRIVE POSITIONER
Revision: August 20072004 QX56
14 G/W Rear lifting switch DOWN signalON (rear lifting switch DOWN
operation)0
Other than above Battery voltage
15 LPedal adjusting switch BACK-
WARD signalON (pedal adjusting switch BACK-
WARD operation) 0
Other than above Battery voltage
16 W Seat sensor power Ignition switch ON 5
17 W UART LINE (TX)Pedal adjusting switch ON (FOR-
WARD or BACKWARD operation)
19 R CAN-L — —
21 L/R A/T device (detent switch) signalSelector lever in P position 0
Selector lever other than P posi-
tion with ignition key in ignition cyl-
inderBattery voltage
24 Y/G Seat sliding motor sensor signalON (seat sliding motor operation)
Other than above 0 or 5
25 LG Front lifting motor sensor signalON (front lifting motor operation)
Other than above. 0 or 5
26 P/BSeat sliding switch FORWARD
signalON (seat sliding switch FOR-
WARD operation)0
Other than above Battery voltage
27 G/BSeat reclining switch FOR-
WARD signalON (seat reclining switch FOR-
WARD operation)0
Other than above Battery voltage
28 Y/B Front lifting switch UP signalON (front lifting switch UP opera-
tion)0
Other than above Battery voltage
29 R/W Rear lifting switch UP signalON (rear lifting switch UP opera-
tion)0
Other than above Battery voltage
30 RPedal adjusting switch FOR-
WARD signalON (pedal adjusting switch FOR-
WARD operation)0
Other than above Battery voltage TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
PIIA4814E
PIIA3277E
SIIA0691J

AUTOMATIC DRIVE POSITIONER
SE-31
C
D
E
F
G
H
J
K
L
MA
B
SE
Revision: August 20072004 QX56
Terminals and Reference Values for Automatic Drive Positioner Control UnitEIS0038K
31 L/Y Sensor ground — 0
32 B Ground — 0
33 W/L Battery power supply (PTC) — Battery voltage
35 V/WSliding motor FORWARD out-
put signalSliding switch FORWARD opera-
tion (Motor operated)Battery voltage
Other than above 0
36 Y/GReclining motor FORWARD out-
put signalReclining switch FORWARD oper-
ation (Motor operated)Battery voltage
Other than above 0
37 BRFront lifting motor DOWN output
signalFront lifting switch DOWN opera-
tion (Motor operated)Battery voltage
Other than above 0
38 B/WRear lifting motor UP output sig-
nalRear end lifting switch UP opera-
tion (Motor operated)Battery voltage
Other than above 0
39 YRear lifting motor DOWN output
signalRear end lifting switch DOWN
operation (Motor operated)Battery voltage
Other than above 0
40 Y/R Battery power supply — Battery voltage
42 O/BSliding motor BACKWARD out-
put signalSliding switch BACKWARD oper-
ation (Motor operated)Battery voltage
Other than above 0
44 Y/RReclining motor BACKWARD
output signalReclining switch BACKWARD
operation (Motor operated)Battery voltage
Other than above 0
45 GRFront lifting motor UP output sig-
nalFront lifting switch UP operation
(Motor operated)Battery voltage
Other than above 0
48 B Ground — 0 TERMINALWIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
TERMINAL WIRE
COLORITEM CONDITIONVOLTAGE (V)
(Approx.)
1 W/G ADP steering switch TILT UPADP steering switch in UP position 0
Other than above 5
2 LG Changeover switch RH signalChangeover switch in RH position 0
Other than above 5
3 Y/B Mirror switch UP signalMirror switch in UP position 0
Other than above 5
4 V/W Mirror switch LEFT signalMirror switch in LEFT position 0
Other than above 5
5R/BMirror sensor (RH vertical) sig-
nalMirror motor RH is operated UP or
DOWNChanges between 3.4 (close to
peak) 0.6 (close to valley)
6L/YMirror sensor (LH vertical) sig-
nalMirror motor LH is operated UP or
DOWNChanges between 3.4 (close to
peak) 0.6 (close to valley)
7 Y/BR Tilt sensor inputTilt position TOP 2
Tilt position BOTTOM 4
