SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2004 November 2004 FX35/FX45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsADS000O9
2WD MODEL
AW D M OD E L
Front Propeller ShaftADS000OA
JOURNAL AXIAL PLAY
PROPELLER SHAFT RUNOUT LIMIT
Rear Propeller ShaftADS000OB
JOURNAL AXIAL PLAY
PROPELLER SHAFT RUNOUT LIMIT
Applied model VQ35DE
Propeller shaft model 3S80A-1VL107
Number of joints3
Coupling method with transmission Sleeve type
Applied model VQ35DE VK45DE
Front propeller shaftPropeller shaft model 2S56A
Number of joints 2
Coupling method with front final drive Flange type
Coupling method with transfer Sleeve type
Rear propeller shaftPropeller shaft model 3F80A-1VL107
Number of joints 3
Coupling method with transfer Flange type
Model2S56A
Yoke journal bearing axial play 0 mm (0 in)
Model2S56A
Propeller shaft runout limit 0.6 mm (0.024 in) or less
Model3S80A-1VL107, 3F80A-1VL107
Yoke journal bearing thrust play 0 mm (0 in)
Model3S80A-1VL107, 3F80A-1VL107
Propeller shaft runout limit 0.6 mm (0.024 in) or less
