2004 Hyundai Grandeur Owner's Manual

1- 12 FEATURES OF YOUR HYUNDAI
To move the seat toward the front or rear, pull the lock release lever up- ward. This will release the seat on itstrack so you can move it forward or rearward to the desired position. When you find the position you want, releasethe lever and slide the seat forward or rearward on its track until it locks into the desired position and cannot bemoved further.
HXG103
B080C02A-AAT Adjusting Seatback Angle
To recline the seatback, lean forward to take your weight off it, then pull up on the recliner control lever at theoutside edge of the seat. Now lean back until the desired seatback angle is achieved. To lock the seatback intoposition, release the recliner control lever. WARNING:
To minimize risk of severe injury in the event of a collision or a suddenstop, both the driver and passen- ger seatbacks should always be in an upright position while the ve-hicle is in motion. The protection provided by the seat belts and airbags in a frontal collision may bereduced significantly when the seatbacks are reclined. There is greater risk that the driver and pas-senger will slide under the seat belt which may result in serious injury if a crash occurs when the seatbacksare reclined. The seat belt and airbags cannot provide proper pro- tection to an occupant if the seatback is reclined.
!
WARNING:
To ensure the seat is locked se- curely, attempt to move the seat forward or rearward without usingthe lock release lever.!

FEATURES OF YOUR HYUNDAI 1- 13
B080E01L-AAT Lumbar Support Control To adjust the lumbar support, turn the handle on the outboard or left side of the seat. To increase the amount of lumbar support, pull the lever forward.To decrease it, push the lever toward the rear.
1. Minimum support
2. Maximum support HXG108
2
1
B080G01L
WARNING:
o For maximum effectiveness in case of an accident the headrestshould be adjusted so the top of the headrest is at the same heightas the top of the occupant's ears. For this reason, the use of a cush- ion that holds the body awayfrom the seatback should not be recommended.
o Do not operate vehicle with the headrests removed as injury tothe occupants may occur in the event of an accident. Headrestsmay provide protection against neck injuries when properly ad- justed.
!HXG200J
Lock Knob
B080D01L-GAT Adjustable Headrests Headrests are designed to help re- duce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lock knob. If equipped with a hori- zontally adjustable type of headrest,pull on the top.

1- 14 FEATURES OF YOUR HYUNDAI
B090A03L-AAT POWER SEAT (If installed) The front seat can be adjusted appro- priately by using the control knobs onthe left side of the seat. Before driving, adjust the seat to the proper position so as to easily control the steeringwheel, pedals and switches on the instrument panel.
HXG180
1
2
B090B01L-AAT Adjusting Seat Forward and Rearward Pull the control knob forward or back- ward to move the seat forward or back-ward to the desired position. Release the knob and then the seat will remain at that position.
1. Seat Back Reclining Control Knob
2. Seat Cushion Forward, Rearward
and Height Adjusting Control Knob
WARNING:
o Never attempt to adjust the seat while the vehicle is moving. Thiscould result in loss of control oran accident causing death, seri- ous injury, or property damage.
o Do not sit or lean unnecessarily
close to the airbag.
CAUTION:
Do not operate two knobs at the same time.
!
!
B080F01S-AAT Seat Cushion Height Adjustment (Driver's Seat Only)
To raise or lower the front part of the seat cushion, turn the front knob for-ward or rearward. To raise or lower the rear part of the seat cushion, turn the rear knob forward or rearward. HXG106

FEATURES OF YOUR HYUNDAI 1- 15
HXG181
B090D01Y-AAT Adjusting Seatback Angle
Rotate the upper portion of the control knob forward or backward to adjust the seatback to the desired position. Re- lease the control knob and then the seatback will remain in that position. WARNING:
To minimize the risk of personalinjury in the event of a collision ora sudden stop, both the driver's and passenger's seatbacks should remain in an upright position whilethe car is in motion. The protection provided by the seat belts and airbags may be reduced signifi-cantly when the seatbacks are re- clined. There is a greater risk that the seat occupants will slide underthe belt resulting in serious injury if a crash occurs when the seatbacks are reclined. The seat belt cannot provide full protection to an occu- pant if the seatback is reclined.
!
B090C01Y-AAT Seat Cushion Height Adjustment
Move the front portion of the control knob up or down to raise or lower the front part of the seat cushion. Move the rear portion of the control knob up ordown to raise or lower the rear part of the seat cushion. HXG182

1- 16 FEATURES OF YOUR HYUNDAI
!
CAUTION:
In the following conditions, the I.M.S will not operate.
1. When the "1" or "2" button is not pushed within five seconds.
2. When the seat is being adjusted.
3. When the "STOP" button is pushed.
4. While the vehicle is moving.
B090E05L-AAT I.M.S (Integrated Memory Sys- tem)(If Installed) The Integrated Memory System con- trols are located on the driver's door.After adjusting the position of the driver's seat and outside rearview mir- rors, use the I.M.S to memorize them.Two different driving position profiles can be entered in the I.M.S. If you turn the ignition key to the "ON" position,the memorized position is adjusted automatically. HXG212To memorize driving position
1. Turn the ignition key "ON".
2. Adjust the driver's seat and outside
rearview mirrors to the desired posi- tion.
3. Push the "M" button on the I.M.S
until the signal beeps.
4. Within five seconds, push button "1"
or "2" until the signal beeps twice. The beep sounds mean that the positions are memorized in the I.M.S. "AUTO" button function When the "AUTO" button is "ON", the system will move the driver's seat for- ward or rearward so you can comfort-ably enter and exit the vehicle.
o It will move driver's seat rearward
when the ignition key is pulled out.
o It will move driver's seat forward
when the ignition key is inserted.
Note: In order for the "AUTO" functions to work, the parking brake must be applied.
!
To activate the memorized posi- tion When you push button "1" or "2", the driving position will be automatically adjusted to the position recorded forthat button. CAUTION:
In the following conditions, the"AUTO" mode will not operate.
1. When AUTO button is in "OFF".
2. When the seat is being adjusted.
3. When the shift lever is positioned in other than "P" position.
Reverse Parking Aid Function When the "AUTO" button is "ON" and the vehicle is moving backward, theoutside rearview mirror(s) will move downward to aid reverse parking safely.

FEATURES OF YOUR HYUNDAI 1- 17
Driver's seat
B100A02Y-AAT SEAT WARMER (If installed)
HXG620
Passenger's seat
The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" posi- tion, push either of the switches towarm the driver's seat or the passenger's seat. During mild weather or under condi-tions where the operation of the seat warmer is not needed, keep the switches in the "OFF" position.
B140A03L
B140A01S-AAT REAR SEAT WARNING For the safety of all passengers, lug- gage or other cargo should not be piled higher than the top of the seatback. In addition, do not place objects on therear shelf as they may move forward during braking or in an accident and strike vehicle passengers.
According to the position of the outside rearview mirror switch knob, the out- side rearview mirror(s) will operate asfollows. L
: When the remote control outside
rearview mirror switch knob is se- lected to the "L" position, both of the outside rearview mirrors willmove downward.
R : When the remote control outside
rearview mirror switch knob is se-lected to the "R" position, only the passenger's outside rearview mir- ror will move downward.
Neutral : When the remote control
outside rearview mirrorswitch knob is placed in themiddle position, the outside rearview mirrors will not op- erate while the vehicle ismoving backward.
NOTE: When the ignition key is in the "LOCK" position, the selector leveris moved to any position except "R" position, or the remote control out- side rearview mirror switch knob isplaced in the middle position, the outside rearview mirrors will auto- matically revert to original position. WARNING:
It is recommended that the seatheater not be used when elderly people or people who are ill occupy the seat. Also, do not use the seatwarmer if the occupant is sleeping.
!

1- 18 FEATURES OF YOUR HYUNDAI
FREE
LOCK
B120A01L-GAT REAR SEATBACK SAFETY LOCK (If installed) If the rear seatback lock lever (located on the backside of the rear seatback) is in the "LOCK" position when the rear seatbacks are closed, it will not bepossible to fold the rear seatback by using the seatback locking button. In this instance, move the lock lever tothe "FREE" position and fold the rear seatback. The rear seatback lock le- ver is designed to provide protectionfrom unauthorized entry into the trunk. B120A03L
WARNING:
The purpose of the folding rear seatbacks is to allow you to carrylonger objects than could other- wise be accommodated. Never al- low passengers to sit on top of thefolded down seatback. This could result in injury in case of an acci- dent or a sudden braking as this isnot a designated seating position and seat belt restraint systems are not accessible when the seatbacksare folded down. B110A02L!B110A01L
B110A01L-GAT FOLDING REAR SEATBACKS
o To unlock the seatback, depress
the seatback locking button, then pull forward on the seatback panel.
o When you return the seatback to its
upright position, always be sure ithas locked into position by pulling and pushing on the top of theseatback.

FEATURES OF YOUR HYUNDAI 1- 19
B150D01A-AAT Pregnant Women The use of a seat belt is recommended for pregnant women to lessen thechance of injury in an accident. When a seat belt is used, the lap belt portion should be placed as low and snugly aspossible on the hips, not across the abdomen. For specific recommenda- tions, consult a physician.
B150C02A-AAT Larger Children Children who are too large for child restraint systems should always oc-cupy the rear seat and use the avail- able lap/shoulder belts. The lap por- tion should be fastened snug on thehips and as low as possible. Check belt fit periodically. A child's squirming could put the belt out of position. Chil-dren are afforded the most safety in the event of an accident when they are restrained by a proper restraint sys-tem in the rear seat. If a larger child (over age 13) must be seated in the front seat, the child should be securelyrestrained by the available lap/shoul- der belt and the seat should be placed in the rear most position. Children un-der the age of 13 should be restrained securely in the rear seat. NEVER place a child under the age of 13 in the frontseat. NEVER place a rear facing child seat in the front seat of a vehicle.
B150F01A-AAT One Person Per Belt Two people (including children) should never attempt to use a single seat belt. This could increase the severity of injuries in case of an accident.
B150E01A-AAT Injured Person A seat belt should be used when an injured person is being transported. When this is necessary, you shouldconsult a physician for recommenda- tions.
B150B01Y-GAT Infant or Small Child Some countries require the use of child restraint systems for infants andsmall children. Whether this is required by law or not, it is strongly recom- mended that a child restraint seat orinfant restraint system be used for infants or small children weighing less than 18 kilograms (40 pounds). NOTE: Small children are best protected in an accident when properly re- strained by a child restraint sys-tem.
B150A02A-GAT SEAT BELT PRECAUTIONS All occupants of the vehicle should wear their seat belts at all times. In-deed, your province's laws may re- quire that some or all occupants of the vehicle use seat belts.The possibility of injury or the severity of injury in an accident will be de- creased if this elementary safety pre-caution is observed. In addition, the following recommendations are made:
