Center Roof Marker Lamps
1. Push in on the notch with a at tool and pull the
lamp out.
2. Turn the bulb socket counterclockwise and remove
it from the lamp housing.
3. Remove the bulb from the bulb socket.
4. Put the new bulb into the bulb socket.
5. Place the hook end of the lamp in place on one
side and push the other end of the lamp down
until it locks in place.
5-56

Center High-Mounted Stoplamp
(CHMSL)
If your vehicle has this component and it needs
replacement, it is recommended that it be replaced as a
unit by your dealer.
Taillamps
A. Stoplamp
B. Turn Signal Lamp
C. Back-Up Lamp
1. Open the liftgate.2. Remove the two
screws from the rear
lamp assembly
and remove the rear
lamp assembly.
3. Turn the bulb socket counterclockwise to remove it
from the taillamp housing.
5-57

4. Pull the bulb straight
out from the socket.
5. Press a new bulb into the socket, insert it into the
taillamp housing and turn the socket
counterclockwise until it is locked in place.
6. Reinstall the rear lamp assembly and tighten the
screws.Replacement Bulbs
Exterior Lamp Bulb Number
Low-Beam and High-Beam
Headlamps9007
Daytime Running Lamps (DRL) 4114K
Front Turn Signal and Parking
Lamps4157K or 3157KX
Rear Taillamp and Stoplamp 3157
Rear Turn Lamp 3157
Back-up Lamp 4157 or 3157
Roof Marker Lamps 168
For replacement bulbs not listed here, please consult
your dealer.
5-58

The following steps will tell you how to use the jack and
change a tire.
Removing the Spare Tire and Tools
The equipment you’ll need is behind and to the side of
the driver’s side second row seat. To remove the
equipment, do the following:
1. Fold the driver’s side second row seat down. See
60/40 Split Bench Seat on page 1-8.
2. Turn the wingnut (A),
which holds the jack,
counterclockwise
to release the jack.
3. Turn the wingnut (B), which holds the jack tool kit,
counterclockwise to release it.Open the tool bag and you will nd the following tools
which you will use to remove the spare tire and at tire:
A. Jack Handle Extension (Used for Rear Flats Only)
B. Jack Handle
C. Wheel Wrench
D. Ratchet
E. Spanner Wrench
F. Locking Pin (If Equipped) Not used for tire changing
procedure. See “Power Winch Platform” underIf You
Are Stuck: In Sand, Mud, Ice or Snow on page 4-56.
5-80

The spare tire and wheel blocks are stored in the rear
cargo area. Remove the tire cover to get to them.
A. Spare or Flat Tire
B. Receiver Extension (If Equipped) Not used for tire
changing procedure. See “Receiver Extension” under
If You Are Stuck: In Sand, Mud, Ice or Snow on
page 4-56.
C. Tire Retainer Plate
D. Nut
E. Wheel BlocksFollow the instructions to remove the wheel blocks and
spare tire:
1. Remove the wheel blocks from the tire retainer
plate by turning the wingnut counterclockwise.
2. Place the at end of the wheel wrench through the
hole in the spanner wrench.
5-81

3. Place the end of the
spanner wrench on the
nut and then turn
the wheel wrench
counterclockwise to
loosen the nut holding
the tire to the
carrier.
4. Pull off the tire retainer plate and set it aside.
Remove the spare tire from the wheel carrier.
5. Put the spare tire near the at tire.
Use the art and text following to nish changing a
at tire.The tools you’ll be using include the jack (A), the wheel
blocks (B), the wheel wrench (C), jack handle
extension (D), the jack handle (E) and the ratchet (F).
Before proceeding, be sure to set the wheel
blocks (B) on the appropriate tire as shown previously.
5-82

Removing the Flat Tire and Installing
the Spare Tire
1. To remove the center
cap, place the at end
of the wheel wrench
in the slot on the wheel
and gently pry the
center cap out.
2. Slide the ratchet onto the wheel wrench with the
DOWN mark facing you.
3. Turn the ratchet counterclockwise to loosen the
wheel nuts. Don’t remove them yet.
You will now need to jack the vehicle up using the
instructions following.
4. Assemble the jack and tools as follows:
Front Flat Tire:Attach the jack handle (E) with the
hook end connected to the u-hook/clevis on the
jack (A). Slide the ratchet (F) onto the jack handle (E)
with the UP mark facing you.
5-83

Rear Flat Tire:Attach the jack handle extension (D)
to the jack handle (E) and then press the clip (arrow)
so it engages. Then attach the jack handle (E) with
the hook end connected to the u-hook/clevis on the
jack (A). Slide the ratchet (F) onto the jack handle
extension (D) with the UP mark facing you.
5. Turn the ratchet (F) clockwise to raise the jack
head to the lifting point.Front Flat Tire:Position
the jack under the vehicle
on the frame behind
the at tire where the
frame sections overlap.
See the graphic following
for an approximate
measurement of the jack
location on the frame.
Front Position
