Q:What should I do if my vehicle stalls, or
is about to stall, and I can not make it up
the hill?
A:If this happens, there are some things you should
do, and there are some things you must not do.
First, here is what youshoulddo:
Push the brake pedal to stop the vehicle and
keep it from rolling backwards. Also, apply the
parking brake.
If your engine is still running, shift the transmission
to REVERSE (R), release the parking brake, and
slowly back down the hill in REVERSE (R).
If your engine has stopped running, you will need to
restart it. With the brake pedal pressed and the
parking brake still applied, shift the transmission to
PARK (P) and restart the engine. Then, shift to
REVERSE (R), release the parking brake, and
slowly back down the hill as straight as possible in
REVERSE (R).
As you are backing down the hill, put your left hand
on the steering wheel at the 12 o’clock position.
This way, you will be able to tell if your wheels are
straight and maneuver as you back down. It is
best that you back down the hill with your wheels
straight rather than in the left or right direction.
Turning the wheel too far to the left or right
will increase the possibility of a rollover.Here are some things youmust notdo if you stall, or
are about to stall, when going up a hill.
Never attempt to prevent a stall by shifting into
NEUTRAL (N) to “rev-up” the engine and regain
forward momentum. This will not work. Your vehicle
will roll backwards very quickly and you could go
out of control.
Instead, apply the regular brake to stop the vehicle.
Then apply the parking brake. Shift to
REVERSE (R), release the parking brake, and
slowly back straight down.
Never attempt to turn around if you are about to
stall when going up a hill. If the hill is steep
enough to stall your vehicle, it is steep enough to
cause you to roll over if you turn around. If you can
not make it up the hill, you must back straight
down the hill.
4-34

The fuel cap is located on
the driver’s side of the
vehicle.
Some vehicles may be
equipped with a fuel door.
Open the door to access
the fuel cap.Some vehicles may be equipped with a locking fuel cap.
Use the fuel cap key to unlock the fuel cap. If you
ever need a replacement key, your dealer can help you
get one.
Turn the fuel cap slowly to
the left (counterclockwise)
to remove it. While
refueling, let the fuel cap
hang by the tether, if it
has one.
{CAUTION:
If a re starts while you are refueling, do not
remove the nozzle. Shut off the ow of fuel by
shutting off the pump or by notifying the
station attendant. Leave the area immediately.
5-8

Be careful not to spill fuel. Don’t top off or overll your
tank and wait a few seconds after you’ve nished
pumping before you remove the nozzle. Clean any
spilled fuel from painted surfaces as soon as possible.
SeeCleaning the Outside of Your Vehicle on
page 5-95.
When you put the fuel cap back on, turn it to the right
(clockwise) until you hear a clicking sound. Make
sure you fully install the cap. The diagnostic system can
determine if the fuel cap has been left off or improperly
installed. this would allow fuel to evaporate into the
atmosphere. SeeMalfunction Indicator Lamp on
page 3-38.
Notice:If you need a new fuel cap, be sure to get
the right type. Your dealer can get one for you.
If you get the wrong type, it may not t properly.
This may cause your malfunction indicator lamp to
light and may damage your fuel tank and emissions
system. SeeMalfunction Indicator Lamp on
page 3-38.Filling a Portable Fuel Container
{CAUTION:
Never ll a portable fuel container while it is in
your vehicle. Static electricity discharge from
the container can ignite the gasoline vapor.
You can be badly burned and your vehicle
damaged if this occurs. To help avoid injury to
you and others:
Dispense gasoline only into approved
containers.
Do not ll a container while it is inside a
vehicle, in a vehicle’s trunk, pickup bed or
on any surface other than the ground.
Bring the ll nozzle in contact with the
inside of the ll opening before operating
the nozzle. Contact should be maintained
until the lling is complete.
Do not smoke while pumping gasoline.
5-9

{CAUTION:
Adding only plain water to your cooling
system can be dangerous. Plain water, or
some other liquid such as alcohol, can boil
before the proper coolant mixture will.
Yourvehicle’s coolant warning system is set
for the proper coolant mixture. With plain
water or the wrong mixture, your engine could
get too hot but you would not get the overheat
warning. Your engine could catch re and you
or others could be burned. Use a 50/50 mixture
of clean, drinkable water and DEX-COOL
®
coolant.
Notice:In cold weather, water can freeze and crack
the engine, radiator, heater core and other parts.
Use the recommended coolant and the proper
coolant mixture.
{CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol
and it will burn if the engine parts are hot
enough. Do not spill coolant on a hot engine.
1. Park the vehicle on a level surface.
2. Locate the coolant
surge tank pressure
cap that has this label.
You can remove the coolant surge tank pressure
capwhen the cooling system, including the
coolant surge tank pressure cap and upper radiator
hose, are no longer hot. Turn the pressure cap
slowly counterclockwise (left) about one full turn. If
you hear a hiss, wait for that to stop. A hiss
means there is still some pressure left.
5-33

Bulb Replacement
SeeReplacement Bulbs on page 5-58for the proper
type of bulbs to use.
For any bulb changing procedure not listed in this
section, contact your dealer.
Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas inside and
can burst if you drop or scratch the bulb. You or
others could be injured. Be sure to read and
follow the instructions on the bulb package.
Headlamps
1. Open the hood as described earlier underHood
Release on page 5-10and locate the affected
headlamp on the inner front portion of the hood.2. Turn the bulb/socket
retainer (arrow)
counterclockwise to
unlock the bulb/socket.
You may prefer to
unplug the electrical
connector before
removing the bulb/
socket. If so, complete
Step 4 before doing
this step.
3. Pull the bulb/socket
straight out from the
headlamp housing.
5-52

4. Unplug the electrical
connector.
5. Push the new bulb/socket into the headlamp
assembly making sure to align the splines on
the bulb/socket with the splines in the headlamp
housing. Use care not to touch the bulb with
your ngers or hands.
6. Turn the bulb/socket retainer clockwise to lock the
bulb/socket in place.
7. Plug in the electrical connector.Front Turn Signal and Parking
Lamps
1. Open the hood as described earlier underHood
Release on page 5-10and locate the affected lamp.
2. Turn the bulb socket
counterclockwise and
remove it from the lamp
housing.
3. Pull the bulb from the bulb socket.
4. Put the new bulb into the bulb socket.
5. Put the bulb socket into the lamp housing and turn
it clockwise until it locks.
5-53

Sidemarker Lamps
It is recommended that these components be replaced
by your dealer.
Daytime Running Lamps
1. Locate the lamp
assembly behind the
front bumper. It is
easiest to come in from
the side of the
vehicle through the
wheel opening.2. Turn the bulb socket
counterclockwise and
remove it from the lamp
housing.
3. Remove the bulb from the bulb socket.
4. Put the new bulb into the bulb socket.
5. Put the bulb socket into the lamp housing and turn
it clockwise until it locks.
5-54

Roof Marker Lamps
Corner Roof Marker Lamps
1. Remove the screw and lift off the lens.2. Turn the socket counterclockwise to remove it and
remove the old bulb.
3. Put a new bulb into the socket.
4. Reinstall the socket into the lens and turn it
clockwise to lock it into place.
5. Hook the side of the lens with the hook end in the
notch rst and then tighten the screw.
5-55
