2004 DODGE STRATUS COUPE Owners Manual

PUBLICATION ORDER FORMS
11

DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES
The following describes the tire grading categories estab-
lished by the National highway Traffic Safety Adminis-
tration. The specific grade rating assigned by the tire's
manufacturer in each category is shown on the sidewall
of the tires on your car.
All Passenger Car Tires Must Conform to Federal Safety
Requirements in Addition to These Grades.
Treadwear
The treadwear grade is a comparative rating based on the
wear rate of the tire when tested under controlled con-
ditions on a specified government test course. For ex-
ample, a tire graded 150 would wear one and a half
(1 1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and
may depart significantly from the norm due to variations
in driving habits, service practices and differences in road
characteristics and climate.
Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B
and C. Those grades represent the tire's ability to stop on
wet pavement as measured under controlled conditions
on specified government test surfaces of asphalt and
concrete. A tire marked C may have poor traction perfor-
mance.
WARNING!
The traction grade assigned to this tire is based on
straight-ahead braking traction tests and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
IF YOU NEED CONSUMER ASSISTANCE 379
11

Temperature A, B, C
The temperature grades are A (the highest), B and C,
representing the tire's resistance to the generation of heat
and its ability to dissipate heat when tested under
controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperatures can cause the
material of the tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden tire failure. The
grade C corresponds to a level of performance which all
passenger vehicle tires must meet under the Federal
Motor Vehicle Safety Standard No. 109. Grades B and A
represent higher levels of performance on the laboratory
test wheel than the minimum required by law.WARNING!
The temperature grade for this tire is established for
a tire that is properly inflated and not overloaded.
Excessive speed, under-inflation, or excessive load-
ing, either separately or in combination, can cause
heat build-up and possible tire failure.
380 IF YOU NEED CONSUMER ASSISTANCE

INDEX
12

Accessory boxes........................ 213
Accessory (installation)................... 248
Adding Fuel.......................... 147
Air cleaner filter........................ 316
Air conditioning........................ 236
Aluminum wheel....................... 259
Antenna.............................. 219
Anti-lock braking system warning light . . . 107,113
Assist-starting procedures if battery is low.... 279
Automatic transaxle indicator.............. 119
Automatic transaxle oil temperature
warning light.......................... 107
Automatic transaxle
Automatic transaxle fluid............... 327
Driving speed........................ 157
Gear positions....................... 156
Holding on an upgrade................ 165
Oil temperature warning light............ 107
Parking............................ 169
Reset Mode.......................158,166
Selector lever operation................. 153
Automatic transmission.................. 158
Autostick............................. 163Ball joint, steering linkage seal and drive
shaft boots............................ 329
Battery............................... 325
Charging system warning light........107,114
During cold weather................... 202
Specification......................... 366
Brake pad wear alarm................... 172
Brake System.......................... 172
Fluid.............................. 323
Hose.............................. 329
Parking brake.....................169,332
Pedal.............................. 171
Power brakes........................ 172
Warning light........................ 117
Warning sound for brake pad wear........ 172
Brake
Parking brake........................ 332
Pedal.............................. 171
Break-in recommendations................ 144
Bulb chart.........................293,294
Car preparation before driving............. 199
Cargo loads........................... 337
382 INDEX

Cassette Tape and Player Maintenance....... 224
Cassette Tape Player..................219,221
CD Player.........................219,227
Center console......................... 215
Center console box...................... 213
Charging system warning light..........107,114
Check engine/malfunction indicator
lamp.............................107,115
Child restraint.......................... 76
Clean Air Gasoline...................... 145
Cleaning
Exterior of your car................... 254
Interior of your car.................... 253
Clock................................ 216
Compact spare tire...................267,367
Contract, Service....................... 374
Coolant (engine)....................... 322
Cruise control (for non-turbo)
Indicator.........................107,113
Cruise control (for turbo)
Indicator.........................107,113
Cup holder........................... 212Customer Arbitration Board............... 375
Customer Assistance.................... 372
Dealer Service......................... 372
Defroster (rear window).................. 125
Diagnostic System, Onboard............... 314
Dimmer control........................ 122
Disc brake pads........................ 329
Dome light........................... 305
Dome light/Reading light................ 129
Door hinges, rear hatch hinges, hood lock
release mechanism and safety catch......... 330
Door Opener, Garage.................... 132
Door-ajar warning light...............107,112
Doors
Lock............................... 26
Power door locks...................... 34
Drive belt............................ 333
Driving, alcohol and drugs................ 201
Driving speed
Automatic transaxle................... 157
Manual transaxle..................... 169
INDEX 383

Electric rear window defroster switch........ 125
Emission-control system maintenance........ 313
Engine compartment.................259,311
Engine coolant......................... 322
Engine coolant level warning light.......... 107
Engine coolant temperature gauge.......106,111
Engine hood release...................... 41
Engine oil and oil filter.................. 318
Engine overheating..................... 278
Engine serial number.................... 365
Engine specifications.................... 369
Exhaust system.....................330,369
Fluid
Automatic transaxle fluid............... 327
Brake fluid.......................... 323
Clutch fluid......................... 324
Fog light switch........................ 123
Front fog lamp indicator lamp............. 114
Front seat adjustment..................... 57
Fuel
Filler Cap........................... 148
Fuel economy........................ 149Fuel filler............................ 39
Fuel gauge.......................106,109
Fuel hoses.......................... 315
Fuel selection........................ 144
Low-fuel warning light..............107,113
Fuses................................ 286
Fusible links.......................... 287
Garage Door Opener.................... 132
GasCap .............................. 148
Gasoline/Oxygenate Blends............... 146
Gauges.........................106,109,111
Gear positions......................... 156
General maintenance
Maintenance service................... 318
General vehicle data..................... 367
Glove compartment..................213,214
Handling of Compact Discs............... 232
Hazard warning flasher switch............. 124
Hazard warning light.................107,112
Head restraints......................... 66
Headlights (Type 1)..................... 294
384 INDEX
