2004 DODGE SPRINTER Owners Manual

UNDERSTANDING YOUR INSTRUMENT PANEL 129
4
Settings with the A uxiliary Heater switched on
(only with Water Heater)In preheat mode, the blower is automatically switched
on at blower speed 1 when the water heater is switched
on. When driving, the airflow control switch (2) can be
set as desired.NOTE: Only on vehicles with automatic heater
control/regulated air conditioner:
Before switching on the heater or entering the switch-
on time, the temperature control (1) must be set to
maximum heater output (as illustrated).
Set the air distribution control (3) as required between
Y and Z.
AUXILIARY HEAT EXCHANGER IN LOAD
COM PA RTM ENT, ONLY WI TH A UXILIA RY WA TER
HEATER (OPTIONAL)
The auxiliary heat exchanger switch
is located on the right next to the
steering column.
Freightliner-all.book Pag e 129 Monday, December 1, 2003 2:54 PM

130 UNDERSTANDING YOUR INSTRUMENT PANELTo switch on at blower speed 1:
Press the upper section, the left-hand indicator lamp in
the switch lights up.
To switch on at blower speed 2:
Press the lower section, the right-hand indicator lamp
in the switch lights up.
To switch off :
Press the switch to the middle position.
Operation is only possible when the key is turned to
position 2 in the ignition lock.
NOTE: The auxiliary heat exchanger in the load
compartment should be switched off at coolant
temperatures below 176 °F (+80 °C) to quickly de-fog
and de-ice the windshield and front side windows.
A UXILIA RY HEA TER – TIPS FOR COPING WITH
PROBLEMSThe heater either does not switch on or automatically
switches off:
 Insufficient fuel, fill up the fuel tank. Start up heater
several times, until the fuel lines are filled.
 The auxiliary heater will automatically switch off if
the fuel level is under about 4 US gal (15 l).
 The fuses in the fuse box are damaged. Electric
fuses.
 The battery voltage is too low, an undervoltage
protector switches off the heater if the battery
voltage falls below about 10 volts.
The heater motor does not run
 The battery voltage is too low, check the battery.
Batteries.
 The fuses in the fuse box are damaged.
Electric fuses.
 The heater motor is damaged.
Freightliner-all.book Pag e 130 Monday, December 1, 2003 2:54 PM

UNDERSTANDING YOUR INSTRUMENT PANEL 131
4
Overheating (Water Heater) Insufficient coolant, check coolant level.
 The heater will remain switched off after it has been
overheated a number of times (about 10 times in
succession). Have the fault repaired by an
authorized Sprinter Dealer.
Overheating (A ir Heater) The air channels are clogged.
The heater can be restarted once the fault has been
repaired. When this is done, the heater should be
switched on and off.
 The heater will remain switched off after it has been
overheated a number of times (about 3 times in
succession). Have the fault repaired by an
authorized Sprinter Dealer.
NOTE: Repairs should only be made by an authorized
Sprinter Dealer.
Freightliner-all.book Pag e 131 Monday, December 1, 2003 2:54 PM

Freightliner-all.book Pag e 132 Monday, December 1, 2003 2:54 PM

STARTING AND OPERATING
5
CONTENTS
Power assistance . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Starting the Engine . . . . . . . . . . . . . . . . . . . . . . . . . 135Maximum Engine Speed . . . . . . . . . . . . . . . . . . 136Constant RPMs (Optional) . . . . . . . . . . . . . . . . 137

Stopping the Engine . . . . . . . . . . . . . . . . . . . . . . . . 138

Automatic Transmission . . . . . . . . . . . . . . . . . . . . 139Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139Accelerator Position . . . . . . . . . . . . . . . . . . . . . . 140Stopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140Maneuvering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140Selector Lever Position . . . . . . . . . . . . . . . . . . . 141Gear Selection for Special Circumstances . . . . 142

Transmission Selector Lever, Manually
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Loading the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 144Loading Guidelines . . . . . . . . . . . . . . . . . . . . . . 145

Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146Service Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146Brake Pad Wear Indicator . . . . . . . . . . . . . . . . . 147Brake Indicator and Electronic Brake Force
Distribution (EBD) Indicator Lamp . . . . . . . . . 148Parking Brake Indicator Lamp . . . . . . . . . . . . . 149Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . 150Driving Systems . . . . . . . . . . . . . . . . . . . . . . . . . 151Anti-Lock Brake System (ABS) Indicator
Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152Anti-Lock Brake System (ABS) . . . . . . . . . . . . . 153Electronic Brake Force Distribution (EBD) . . . 155Acceleration Skid Control Indicator Lamp
(ASR) and Brake Assist System (BAS)
if equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155Acceleration Skid Control (ASR) Warning
Lamp and Electronic Stability Program (ESP)–
if equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157Acceleration Skid Control (ASR) . . . . . . . . . . . 158
Freightliner-all.book Pag e 133 Monday, December 1, 2003 2:54 PM

134 STARTING AND OPERATING
Deactivating the Acceleration Skid Control
(ASR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159Brake Assist System (BAS) (Cargo/passenger
vans type 2500 C/HC/SHC only) . . . . . . . . . . 160Indicator Lamp Electronic Stability
Program (ESP) (Cargo/passenger vans
type 2500 C/HC/SHC only) . . . . . . . . . . . . . . 161Electronic Stability Program (ESP) (Cargo/
passenger vans type 2500 C/HC/SHC only) . . 162

Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Wheels and Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 163Tire Grip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165Hydroplaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 165

Tire Pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165Tire Pressures of Loaded Vehicle in PSI (kPa) . 167Tire Pressures of Loaded Vehicle in PSI (kPa) . 168Comfort Tire Pressures in PSI (kPa) . . . . . . . . 169Comfort Tire Pressures in PSI (kPa) . . . . . . . . 169

Snow Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170

Fuels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170Fuel Filter with Water Separator . . . . . . . . . . . 170Diesel Fuels for Use at Very Low
Temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Refueling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

Programmed Top Speed (Optional) . . . . . . . . . . 173

Bleeding Diesel Fuel System . . . . . . . . . . . . . . . . . 174

Draining Fuel Filter with Water Separator . . . . . 175Bleeding the Diesel Fuel System . . . . . . . . . . . 176

Permissible Roof Load . . . . . . . . . . . . . . . . . . . . . . 177

Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177Trailer Hitches (Optional) . . . . . . . . . . . . . . . . . 177Electrical Connections (Optional) . . . . . . . . . . 177Vehicle and Trailer Weights and Ratings . . . . 178Loading a Trailer . . . . . . . . . . . . . . . . . . . . . . . . 178Checking Weights of Vehicle and Trailer . . . . 179Attaching a Trailer . . . . . . . . . . . . . . . . . . . . . . . 179Towing a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . 180Parking a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . 182

Emissions Control System (Catalytic Converter) . 183

Fording (Wading Capability) . . . . . . . . . . . . . . . . 183

Body Builder Guideline . . . . . . . . . . . . . . . . . . . . . 183A Special Note Concerning Vehicle
Alteration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Freightliner-all.book Pag e 134 Monday, December 1, 2003 2:54 PM

STARTING AND OPERATING 135
5
POWER ASSISTANCE STARTING THE ENGINE
Battery charge warning lamp (1)
Engine oil level indicator lamp (2)
Preheater indicator lamp (3)
WARNING!
When the engine is not running, there is no power
assistance for the brake and steering system. In
this case, it is important to keep in mind that a
considerably higher degree of effort is necessary
to brake and steer the vehicle.
Freightliner-all.book Pag e 135 Monday, December 1, 2003 2:54 PM

136 STARTING AND OPERATING1. Apply the parking brake.
2. Automatic transmission, shift selector lever to "P"
or "N" position, refer to "Automatic Transmission".
3. Do not depress the accelerator pedal.
4. Turn the key to position 2 in the ignition lock.
The preheater indicator lampq lights up.5. Turn the key clockwise to the stop as soon as the
preheater indicator lamp
q
goes out.
If the engine is at its normal operating temperature,
the preheater indicator lamp will only light up briefly.
Release the key as soon as the engine is running.
NOTE: The key must be returned to position 0 in the
ignition lock before repeating the starting procedure.
If the displayÁ lights up alternately withî in
the multi-function display, there is an immobilizer
malfunction or the key used has not been
programmed.
The: engine oil level warning lamp and the#
battery charge warning lamp must go out after the
engine is started.
If either lamp remains on, stop the engine at once and
have the cause traced and repaired by an authorized
Sprinter Dealer.
During the trip, check the displays and the warning/
indicator lamps in the instrument cluster at regular
intervals.
For instrument cluster and indicator lamps.Maximum Engine SpeedThe maximum engine speed for all vehicles is
4,200 rpm.
Freightliner-all.book Pag e 136 Monday, December 1, 2003 2:54 PM
