2004 DAEWOO LACETTI trunk

NUBIRA/LACETTI FENDER, HOOD, TAILGATE AND TRUNK LID 7–5
4. TRUNK LID (NOTCHBACK)
4–1. REPAIR PROCEDURE
1. Remove the related parts.
S Wiring harness and solenoid valve.
S Lock set, latch set and others.
.
2. Remove the trunk lid.
S Remove the trunk lid mounting bolts from two hinge
bows.
Fig. 8
3. Preparation of the new trunk lid.
S Preparation of the new trunk lid and check damaged
areas.
.
4. Apply the paint.
.
CAUTION
S Ventilate when spraying paint. Most paint contains sub-
stances that are harmful if inhaled or swallowed. Read
the paint label before opening paint container.
S Avoid contact with skin. Wear an approved respirator,
gloves, eye protection and appropriate clothing when
painting.
S Paint is flammable. Store in a safe place, and keep it
away from sparks, flames or cigarettes.
5. Preinstall the trunk lid.
S Fasten to the trunk lid hinges bows at two places with
four bolts, carefully.
S Install bumper.
Fig. 9
S Close the trunk lid and check the clearances and level
difference of trunk lid, side panel outers and rear com-
bination lamps.
Fig. 10
6. Tighten fully.
S After checking and adjusting the mounting position,
tighten all bolts fully.
.
7. Install the related parts.
S Washer hose and nozzles.
S Install in the reverse order in which they were removed.
.

7–6 FENDER, HOOD, TAILGATE AND TRUNK LID NUBIRA/LACETTI
8. Check and adjust.
S Check clearances and level differences.
S Check the hood locking and unlocking condition.
S Check spary conditions of washer liquid and adjust
washer spray nozzels on the hood panel.
.

NUBIRA/LACETTI SEALING, CAULKING AND DEADNER 9–5
FLOOR & TRUNK ROOM
Fig. 4 Floor & Trunk Room

9–6 SEALING, CAULKING AND DEADNER NUBIRA/LACETTI
REAR LAMP & TRUNK ROOM
Fig. 5 Rear Lamp

NUBIRA/LACETTI SEALING, CAULKING AND DEADNER 9–11
HOOD & TRUNK LID
Fig. 10 Hood & Trunk Lid
