2004 DAEWOO LACETTI power window

BODY WIRING SYSTEM 9A – 13
DAEWOO V–121 BL4
FUSE CHART
Engine Room Fuse Block
FuseRating/SourceCircuit
EF130AB+Battery Main (F13~F16, F21~F24)
EF260AB+EBCM, Oil Feeding Connector
EF330AB+Blower Relay
EF430AB+Ignition Switch–2
EF530AB+Ignition Switch–1
EF620AB+Cooling Fan Low Relay
EF730AB+Defog Relay
EF830AB+Cooling Fan HI Relay
EF920AIGN 2Power Window Switch
EF1015AIGN 1Fuel Connector, ECM (MR–140), LEGR, EI Sys-
tem
EF1110AB+ECM, Main Relay (Sirius D4)
EF1225AB+Head Lamp Relay, ILLUM. Relay
EF1315AB+Brake Switch
EF1420AIGN 2Power Window Switch
EF1515ALightHead Lamp HI
EF1615AB+Horn Relay, Siren, Hood Contact Switch
EF1710AB+A/C Comp. Relay
EF1815AIGN 1Fuel Pump
EF1915AB+Cluster, Key Remind S/W, Folding Mirror Unit,
MAP Lamp, Room Lamp, Trunk Open Lamp,
Trunk Open S/W
EF2010ALightHead Lamp Low
EF2115AIGN 1/B+EVAP Canister Purge Solenoid, HO2S, Cooling
Fan Relay
EF2215AIGN 1/B+Injector, EGR, EEGR
EF2310AIlluminationLicense Plate Lamp, Chime Bell, Tail Lamp,
Head Lamp
EF2415AB+Fog LampRelay
EF2510AIGN 2Electric OSRV Mirror
EF2615AB+Central Door Lock Unit
EF2710ALightHead Lamp Low
EF2810AIlluminationILLUM. Circuit, Head Lamp, Tail Lamp
EF2910ASpareNot Used
EF3015ASpareNot Used
EF3125ASpareNot Used

9A – 14IBODY WIRING SYSTEM
DAEWOO V–121 BL4
I/P Fuse Block
FuseRating/SourceCircuit
F110AIGN 1SDM
F210AIGN 1TCM, ECM, Generator, VGIS, VSS
F315AIGN 1Hazard Switch
F410AIGN 1Cluster, DRL Module, Chime Bell, Brake Switch,
SSPS Module, A/C Control Switch
F5–Spare–
F610AIGN 2A/C Comp. Relay, Defog Relay, Power Window
Relay, Head Lamp Relay
F720AIGN 2Blower Relay, A/C Control Switch, FATC
F815AIGN 2Electric Mirror Switch, Folding Mirror, Sun Roof
Module
F925AIGN 1Wiper Motor, Wiper Switch
F10–Spare–
F1110AIGN 1EBCM, Oil Feeding Connector
F1210AIGN 1Immobilizer, Anti Theft Control Unit, Rain Sensor
Unit
F1310AB+TCM
F1415AB+Hazard Switch
F1515AB+Anti Theft Control Unit
F1610AB+DLC
F1710AACCAudio, Clock
F1815AACCExtra Power Jack
F1915AACCCigar Lighter
F2010AIGN 1Reverse Lamp Switch, PNP Switch
F2115AB+Rear Fog Relay
F2215AB+Clock, FATC, A/C Control Switch
F2315AB+Audio
F2410AB+Immobilizer

WIPERS/WASHER SYSTEMS 9D – 11
DAEWOO V–121 BL4
REAR WINDOW WIPER (HATCHBACK)
Diagnostic Aids
If the front wiper is operating correctly, begin the diagnostic table at Step 5. It would not be necessary to check the fuse
or power supply circuit.
Rear Window Wiper (Hatchback)
StepActionValue(s)YesNo
1Check fuse F9.
Is fuse F9 blown?–Go to Step 2Go to Step 3
21. Check for a short circuit and repair, if neces-
sary.
2. Replace fuse F9.
Is the repair complete?–System OK–
31. Turn the ignition ON.
2. Check the voltage at fuse F9.
Does the voltage equal the specified value?11–14 vGo to Step 5Go to Step 4
4Repair the open power supply circuit for fuse F9.
Is the repair complete?–System OK–
51. Disconnect the rear wiper motor electrical con-
nector.
2. Turn the ignition ON.
3. Check the voltage at the PNK wire of the rear
wiper motor electrical connector.
Does the voltage equal the specified value?11–14 vGo to Step 7Go to Step 6
6Repair the open circuit for the BRN wire between
fuse F9 and connector at the rear wiper motor.
Is the repair complete?–System OK–
7With the rear wiper motor still disconnected, use an
ohmmeter to check continuity between ground and
the BLK wire of the rear wiper motor connector.
Does the ohmmeter indicate the specified value?
0 WGo to Step 9Go to Step 8
8Repair the open ground circuit for the rear wiper mo-
tor.
Is the repair complete?–System OK–
91. Turn the ignition ON.
2. Turn the rear wiper ON.
3. Check the voltage at the WHT wire at the rear
wiper motor connector.
Does the voltmeter indicate the specified value?11–14 vGo to Step 10Go to Step 11
10Replace the rear wiper motor.
Is the repair complete?–System OK–
111. Disconnect the wiper switch electrical connec-
tor.
2. Turn the ignition ON.
3. Check the voltage at terminal A3 (BRN).
Is the voltage equal to the specified value?11–14 vGo to Step 13Go to Step 12
12Repair the open circuit between fuse F9 and the wip-
er switch connector terminal A3.
Is the repair complete?–System OK–

INTERIOR TRIM 9G – 3
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
FRONT DOOR TRIM PANEL
Tools Required
KM–475–B Trim Remover
Removal Procedure
1. Lower the front window.
2. Pry off the inside door handle trim bezel.
3. Remove the rear deck lid remote switch and the
power window/mirror control switch.
4. Disconnect the electrical connectors.
5. Remove the door trim panel screws.
6. Pry off the trim panel using the trim remover
KM–475–B.
Installation Procedure
1. Install the trim panel.
2. Connect the electrical connectors.
3. Install the rear deck lid remote switch and the pow-
er window/mirror control switch.

9G – 4IINTERIOR TRIM
DAEWOO V–121 BL4
4. Install the door trim panel screws.
Tighten
Tighten the door trim panel screws to 2.5 NSm (22 lb–
in).
5. Install the inside door handle trim bezel.
6. Raise the front window.
REAR DOOR TRIM PANEL
Tools Required
KM–475–B Trim Remover
Removal Procedure
1. Lower the rear window.
2. Pry off the inside door handle trim bezel.
3. Remove the power window control switch.
4. Disconnect the power window control switch electri-
cal connector.
5. Remove the door trim panel screws.
6. Pry off the trim panel using the trim remover
KM–475–B.
Installation Procedure
1. Install the trim panel.
2. Connect the power window control switch electrical
connector, if equipped.
3. Install the power window control switch..
4. Install the door trim panel screws.
Tighten
Tighten the door trim panel screws to 2.5 NSm(22 lb–
in).
5. Install the inside door handle trim bezel.
6. Raise the rear window.
A–PILLAR TRIM PANEL
Removal Procedure
1. Remove the A–pillar trim panel.

SECTION : 9P
DOORS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS9P–2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Tightening Specification 9P–2. . . . . . . . . . . . .
SCHEMATIC AND ROUTING DIAGRAMS9P–3 . . . . .
Power Door Locks Circuit 9P–3. . . . . . . . . . . . . . . . . . . .
Power Windows Circuit (Front Only) 9P–4. . . . . . . . . .
Power Windows Circuit (Front and Rear) 9P–5. . . . . .
DIAGNOSIS9P–6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Windows 9P–6. . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND REPAIR9P–16 . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9P–16. . . . . . . . . . . . . . . . . . . .
Outside Channel Molding 9P–16. . . . . . . . . . . . . . . . . . .
Front Door Glass Run 9P–16. . . . . . . . . . . . . . . . . . . . . .
Door Weatherstrip 9P–17. . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Glass Run 9P–18. . . . . . . . . . . . . . . . . . . . . .
Front Door Secondary Weatherstrip 9P–18. . . . . . . . . .
Rear Door Secondary Weatherstrip 9P–19. . . . . . . . . .
Front Door Opening Weatherstrip 9P–19. . . . . . . . . . . .
Rear Door Opening Weatherstrip 9P–20. . . . . . . . . . . . Door Seal Trim 9P–20. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker 9P–21. . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker Adjustment 9P–22. . . . . . . . . . . . . . .
Front Door Lock 9P–23. . . . . . . . . . . . . . . . . . . . . . . . . . .
Childproof Rear Door Lock 9P–23. . . . . . . . . . . . . . . . . .
Inside Door Handle 9P–24. . . . . . . . . . . . . . . . . . . . . . . .
Outside Door Handle 9P–24. . . . . . . . . . . . . . . . . . . . . . .
Inside Lock Rod 9P–25. . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Cylinder 9P–25. . . . . . . . . . . . . . . . . . . . . . . .
Power Window Regulator 9P–26. . . . . . . . . . . . . . . . . . .
Door Assembly 9P–26. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Hinge 9P–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Hold–Open Link 9P–28. . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION9P–29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Striker 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . .
Childproof Rear Door Lock 9P–29. . . . . . . . . . . . . . . . . .
Power Door Locks 9P–29. . . . . . . . . . . . . . . . . . . . . . . . .
Power Windows 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . . .

9P – 4IDOORS
DAEWOO V–121 BL4
POWER WINDOWS CIRCUIT (FRONT ONLY)

DOORS 9P – 5
DAEWOO V–121 BL4
POWER WINDOWS CIRCUIT (FRONT AND REAR)
