2004 CHRYSLER TOWN AND COUNTRY Owners Manual

Rear Seat Descriptions
7 Passenger Model Ð 2± passenger bucket seats in the
second position and 3± passenger bench seat or 50/50
bench seat in the third position. All rear seats are remov-
able.
Rear Bench Seating Flexibility
The 3± passenger bench seat may be adjusted to any of 3
positions on its tracks while installed in the vehicle. The
bench seat may also be moved to the second seating
position or removed from the vehicle.
1. Normal SeatingÐ
The 2nd and 3rd row seats are installed. The 3rd row
bench seat is in the full rear position on the tracks.2. Increased StorageÐ
Increased storage area is provided by adjusting 3rd row
bench seat to the intermediate track position. Rear seat-
ing for 3 passengers (children) is still provided.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97
3

3. Additional StorageÐ
The 2nd and 3rd row seats installed. The 3rd row bench
seat is in the full forward position on the tracks and one
or both of the rear seatbacks are folded down.4. Auxiliary SeatingÐ
The middle quad seats are removed from the vehicle. The
3± passenger bench seat can be installed in either the
second or third row.
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Rear Quad and 50/50 Seating Flexibility
The seats may be used with either or both seatbacks
folded forward for additional storage space, or with
either or both seats removed from the vehicle. Both 50/50
seats may also be moved to the 2nd row seating position
when the middle quad seats are removed.
1. Normal SeatingÐ
The 2nd and 3rd row seats are installed. Both seatbacks
are in the upright position.
2. Increased StorageÐ
Increased storage area is provided by folding either or
both seatbacks. With one seatback folded forward, rear
seating for another occupant is still provided. Either orboth seats may Fold and Tumble forward for more
storage space. For maximum storage, remove the head
restraint and place on the seat cushion, then fold the
seatback over the head restraint by lifting lever ª1º and
tumble the seat forward by lifting lever ª2º.
NOTE:
Driving with the 2nd-row seats in the tumbled position is
not recommended when passengers occupy the 3rd row
seats. This position is intended only to increase available
cargo area without requiring removal of the seats.
Do not leave the head restraint stored between the
cushions for extended periods of time or inadvertent
damage to the seat cover or head restraint may occur.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99
3

3. Additional StorageÐ
The 2nd row seats are installed in the middle seating
position. Either or both of the rear seats are removed
from the vehicle.
4. Auxiliary SeatingÐ
The 2nd row seats are removed from the vehicle. Then
the third row seats can be installed in either the rear or
middle seat position.
If the seat is not occupied, the seatback can be folded
forward to obtain additional cargo space. To fold the
seatback forward, pull the handle labeled ª1º located
behind the seat on the passenger side.The seatback will latch in the folded position. To assure
the seatback is latched in the folded position, additional
downward pressure on the seatback may be required
when folding.
The same lever is used to return the seatback to the
upright position.
NOTE:The head restraints are removable, if needed. To
remove them, press the release tab on the right side of the
base of the head restraint.
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
²Not all head restraints in this vehicle are the same.
Head restraints from one seating position should not
be removed and installed in any other seating posi-
tion. In a collision, serious injury or death may result
if the proper head restraint is not installed on each
seat.
²The cargo area in the rear of the vehicle should not
be used as a play area by children. They could be
seriously injured in a collision. Children should be
seated and using the proper restraint system.
²It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
²Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
²Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
DRIVER MEMORY SYSTEM Ð IF EQUIPPED
Once programmed, the memory buttons 1 and 2 on the
driver's door panel can be used to recall the driver's seat,
driver's outside mirror, adjustable brake and accelerator
pedals, and radio station preset settings. Your Remote Key-
less Entry transmitters can also be programmed to recall the
same positions when the Unlock button is pressed.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101
3

Your vehicle may have been delivered with two Remote
Keyless Entry transmitters. One or both transmitters can
be linked to either memory position. The memory system
can accommodate up to four transmitters, each one
linked to either of the two memory positions.
Setting Memory Positions and Linking Remote
Keyless Entry Transmitter to Memory
NOTE:Each time the SET (S) button and a numbered
button (1 or 2) are pressed, you erase the memory settings
for that button and store a new one.
1. Insert the ignition key and turn the ignition switch to
the ON position.
2. Press the driver door memory button number 1 if you
are setting the memory for driver 1, or button number 2
if you are setting the memory for driver 2. The system
will recall any stored settings. Wait for the system to
complete the memory recall before continuing to step 3.3. Adjust the driver's seat, recliner, and driver's side
view mirror to the desired positions.
4. Adjust the brake and accelerator pedals to the desired
positions.
5. Turn on the radio and set the radio station presets (up
to 10 AM and 10 FM stations can be set).
6. Turn the ignition switch to the OFF position and
remove the key.
7. Press and release the SET (S) button located on the
driver's door. A chime will sound signaling that you are
in the memory set mode.
8. Within 5 seconds, press and release memory button 1
or 2 on the driver's door. A chime will sound signaling to
you that the driver memory has been set. The next step
must be performed within 5 seconds if you desire to also
use a Remote Keyless Entry transmitter to recall memory
positions.
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

9. Press and release the LOCK button on one of the
transmitters. A chime will sound signaling to you that the
transmitter has been successfully linked to memory.
10. Insert the ignition key and turn the ignition switch to
the ON position.
11. Select9Remote Linked to Memory9in the Electronic
Vehicle Information Center (EVIC) and enter9Ye s9or
select9Use Factory Settings9from the EVIC and enter
9Ye s9. Refer to the Customer Programmable features in
the Electronic Vehicle Information Center (EVIC) section
for more information.
12. Repeat the above steps to set the next memory
position using the other numbered memory button or to
link another Remote Keyless Entry transmitter to
memory.Memory Position Recall
NOTE:The vehicle must be in Park to recall memory
positions. If a recall is attempted when the vehicle is not
in Park, a message will be displayed in the Electronic
Vehicle Information Center (EVIC).
To recall the memory settings for driver one, press
memory button number 1 on the driver's door or the
Unlock button on the Remote Keyless Entry transmitter
linked to memory position 1.
To recall the memory setting for driver two, press
memory button number 2 on the driver's door or the
Unlock button on the Remote Keyless Entry transmitter
linked to memory position 2.
A recall can be cancelled by pressing any of the memory
buttons on the drivers door during a recall (S, 1, or 2).
When a recall is cancelled, the driver's seat, driver's
mirror, and the pedals stop moving. A delay of one
second will occur before another recall can be selected.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103
3

To Disable A Transmitter Linked to Memory
1. Turn the ignition switch to the OFF position and
remove the key.
2. Press and release memory button number 1. The
system will recall any memory settings stored in position
1. Wait for the system to complete the memory recall
before continuing to step 3.
3. Press and release the memory SET (S) button located
on the driver's door. A chime will sound signaling that
you are in the memory set mode.
4. Within 5 seconds, press and release memory button 1
on the driver's door. A chime will sound signaling to you
that the driver memory has been set.5. Within 5 seconds, press and release the UNLOCK
button on the Remote Keyless Entry transmitter. A chime
will sound signaling to you that the transmitter link has
been successfully disabled.
To disable another transmitter linked to either memory
position, repeat steps 1-5 for each transmitter.
NOTE:Once programmed, all transmitters linked to
memory can be easily enabled or disabled at one time.
Refer to the Remote Linked to Memory9Customer Pro-
grammable Features9in the Electronic Vehicle Informa-
tion Center (EVIC) for more information.
