2004 CHRYSLER SEBRING CONVERTIBLE windshield wipers

NInterior Lights........................64
NMulti-Function Control Lever..............66
NHeadlights, Parking Lights, Instrument Panel
Lights..............................66
NDaytime Running Lights (Canada Only)......66
NLights-On Reminder....................67
NFog Lights Ð If Equipped................67
NTurn Signals..........................67
NHeadlight Beam Select Switch.............67
NPassing Light.........................67
NHeadlight Time Delay...................67
mWindshield Wipers And Washers...........68
NMist................................68
NSpeed Sensitive Intermittent Wiper System....69
mTilt Steering Column.....................69
mTraction ControlÐ If Equipped.............70
mElectronic Speed ControlÐ If Equipped......70
NTo Activate...........................71
NTo Set At A Desired Speed................71
NTo Deactivate.........................71
NTo Resume Speed......................71
NTo Vary The Speed Setting................71
NTo Accelerate For Passing................72
NUsing Speed Control On Hills.............72
mGarage Door Opener Ð If Equipped.........73
NProgramming The Universal Transceiver......74
NªRolling Codeº Programming.............75
NCanadian Programming/Gate Programming . . .77
NOperation............................77
NReprogramming A Single Button...........77
NSecurity.............................77
mElectrical Power Outlet...................78
46 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by a switch in the
right side control lever. Turn the end of the control lever
to select the desired wiper speed.
NOTE:Always remove any build-up of snow that
prevents the windshield wiper blades from returning to
the OFF position. If the windshield wiper switch is
turned OFF and the blades cannot return to the OFF
position, damage to the wiper motor may occur.
To use the washer, pull the lever toward you and hold
while spray is desired. If the lever is pulled while in thedelay range, the wiper will operate for several cycles
after the lever is released, and then resume the intermit-
tent interval previously selected.
If the lever is pulled while in the OFF position, the wipers
will operate for several cycles, then turn OFF.
WARNING!
Sudden loss of visibility through the windshield
could lead to an accident. You might not see other
vehicles or other obstacles. To avoid sudden icing of
the windshield during freezing weather, warm the
windshield with defroster before and during wind-
shield washer use.
Mist
Use this feature when weather conditions make occa-
sional usage of the wipers necessary. Pull down and
release the control lever for a single wiping cycle.
68 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild non abrasive cleaner. This will remove accumula-
tions of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to
remove frost or ice from the windshield. Keep the blade
rubber out of contact with petroleum products such as
engine oil, gasoline, etc.
Windshield Wiper Blade Replacement
²
Lift the wiper arm away from the glass.
²Push the release tab and slide the wiper blade assem-
bly away from the wiper arm. Gently place the wiper
arm on the windshield.
²Install the new blade assembly onto the wiper arm tip
until it locks in place.
Windshield Washers
The fluid reservoir in the engine compartment should be
checked for fluid level at regular intervals. Fill the
reservoir with windshield antifreeze (not radiator anti-
freeze) rated not to freeze at -25ÉF (-31ÉC). Operate the
system for a few seconds to flush out the residual water.
MAINTAINING YOUR VEHICLE 205
7

Windows
Power.............................. 21
Windshield Washers...................68,205Windshield Wipers....................68,205
Wiper Blade Replacement................. 205
Wipers, Intermittent...................... 69
INDEX 271
