2004 CHRYSLER 300 M Owners Manual

Miles 93,000 96,000 99,000 100,000 102,000 105,000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000) (168 000)
Change engine oil and engine oil filter. X X X X X
Inspect theair cleaner filterand replace if re-
quired.*XXX X
Replace theair cleaner filter.X
Inspect the front and rear brake linings and
rotors.X
Flush and replace the engine coolant. X
Replace theengine timing belt(Federal Emis-
sions).X
Replace theengine timing belt(California
Emissions).X
Replace thespark plugs.X
Adjust the drive belt tension.X
Change the differential fluid. X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
SCHEDULE “B” 249
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE “A”
Miles 6,000 12,000 18,000 24,000 30,000 36,000
(Kilometers) (10 000) (19 000) (29 000) (38 000) (48 000) (58 000)
[Months] [6] [12] [18] [24] [30] [36]
Change engine oil and engine oil filter. XXXXXX
Inspect theair cleaner filterand replace if re-
quired.*X XXX X
Replace theair cleaner filter.*X
Adjust the drive belt tension. X
Inspect the front and rear brake linings and
rotors.XX
Inspect and replace PCV valve if required. X
250 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 42,000 48,000 54,000 60,000 66,000 72,000
(Kilometers) (67 000) (77 000) (86 000) (96 000) (106 000) (115 000)
[Months] [42] [48] [54] [60] [66] [72]
Change engine oil and engine oil filter. X XXXXX
Inspect theair cleaner filterand replace if
required.*XXX XX
Replace theair cleaner filter.*X
Replace the drive belts. X
Inspect the front and rear brake linings and
rotors.XX
Flush and replace engine coolant at 60 months
or 100,000 miles.X
Check and replace, if necessary, thePCV
valve.*X
SCHEDULE “A” 251
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 78,000 84,000 90,000 96,000 102,000
(Kilometers) (125 000) (134 000) (144 000) (154 000) (163 000)
[Months] [78] [84] [90] [96] [102]
Change engine oil and engine oil filter. X X X X X
Inspect theair cleaner filterand replace if re-
quired.*XX XX
Replace theair cleaner filter.*X
Adjust the drive belt tension. X
Inspect the front and rear brake linings and rotors. X
Replace thespark plugs.X
Check and replace, if necessary, thePCV valve.*‡ X
Replace theengine timing belt(Federal Emissions
equipped vehicles only).X
Replace theengine timing belt(California Emis-
sions equipped vehicles only).X
Flush and replace the engine coolant at 60 months
or 100,000 miles.X
* This maintenance is recommended by the manufacture
to the owner but is not required to maintain the emis-
sions warranty.
‡ This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
252 SCHEDULE “A”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

WARNING!
You can be badly injured working on or around a
motor vehicle. Do only that service work for which
you have the knowledge and the right equipment. If
you have any doubt about your ability to perform a
service job, take your vehicle to a competent me-
chanic.
SCHEDULE “A” 253
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

IF YOU NEED CONSUMER ASSISTANCE
CONTENTS
Suggestions For Obtaining Service For Your
Vehicle
..............................256
▫Prepare For The Appointment............256
▫Prepare A List........................256
▫Be Reasonable With Requests.............256
If You Need Assistance..................256
Warranty Information...................258
MoparParts.........................259
Reporting Safety Defects.................259
▫In Canada..........................259
Publication Order Forms.................261
Department Of Transportation Uniform Tire
Quality Grades
........................263
▫Treadwear..........................263
▫Traction Grades......................263
▫Temperature Grades...................264
9

SUGGESTIONS FOR OBTAINING SERVICE FOR
YOUR VEHICLE
Prepare For The Appointment
If you’re having warranty work done, be sure to have the
right papers with you. Take your warranty folder. All
work to be performed may not be covered by the
warranty, discuss additional charges with the service
manager. Keep a maintenance log of your vehicle’s
service history. This can often provide a clue to the
current problem.
Prepare A List
Make a written list of your vehicle’s problems or the
specific work you want done. If you’ve had an accident,
or work done that is not on your maintenance log, let the
service advisor know.
Be Reasonable With Requests
If you list a number of items, and you must have your
vehicle by the end of the day, discuss the situation with
the service advisor and list the items in order of priority.
At many dealers you may obtain a rental vehicle at a
minimal daily charge. If you need a rental, it is advisableto make these arrangements when you call for an ap-
pointment.
IF YOU NEED ASSISTANCE
The manufacturer and its dealers are vitally interested in
your satisfaction. We want you to be happy with our
products and services.
Your selling dealer is best equipped and most anxious to
provide prompt resolution for any warranty issue or
related matter that you may experience. The manufactur-
er’s dealers have the facilities, factory-trained techni-
cians, special tools, and the latest information to assure
your vehicle is fixed correctly and in a timely manner.
The manufacturer has empowered its dealers to make
warranty and repair decisions that ensure you are not
inconvenienced. There is no need for you to wait for a
decision from the manufacturer. If a special circumstance
occurs that requires information from the manufacturer,
we have asked the dealer’s service management to make
the contact on your behalf.
256 IF YOU NEED CONSUMER ASSISTANCE
