Page 73 of 357
GETTING TO KNOW YOUR CAR71
The following refers to the display
(fig. 93) (appearing for about 3 seconds)
with an oil level above the foreseen maxi-
mum. Under this condition the bars are all
full.fig. 93
A0B2136g
Contact Alfa Romeo Au-
thorized Services to have
the engine oil restored to
its correct level.
Restore correct engine oil
level (see paragraph
“Checking fluid levels” in
chapter “Car maintenance”).Do not add oil with dif-
ferent characteristics from
those of the oil already
used in the engine (see “Fluids and
lubricants” in chapter “Car main-
tenance”).
Page 74 of 357
GETTING TO KNOW YOUR CAR72
ACCESS TO THE MENU SCREENAfter the INITIAL CHECK, it is possible to access the menu screen by pressing button
ç
.
To navigate use the
â
and
ã
buttons.
WARNING If you access the Menu and no setting/adjustment is made within about 60 seconds, the system automatically leaves the Menu
and displays the screen previously set. In this case, the latest setting selected but not confirmed (by means of button
ç
) is not stored; there-
fore, the operation must be performed again.
– When the car is running, only the short menu can be accessed (SPEED LIMIT setting).
– When the car is stopped, the extended menu can be accessed.
The following table gives the description of the cases provided.
Example of standard
screen
Is the car
moving?
Short menu screen
SPEED
TRIP B
DATE
LANGUAGE
UNITS
BUZZER
WINTER TYRES
SERVICE
INTENSITY
DEFAULT VALUES
MENU OFF
ç
See
INITIAL CHECK
NO
YES
Extended menu
screen
Page 75 of 357

GETTING TO KNOW YOUR CAR73
SPEED LIMIT (SPEED)With this function it is possible to set the car speed limit which, if exceeded, automatically sounds a buzzer and displays a specific message
to alert the driver. To set the limit speed, proceed as follows:
Using
â
and/or
ã
buttons to set the speed required. During the setting
operation, the value flashes on the screen. The possible setting is between 30
and 250 km/h or between 20 and 150 mph, depending on the unit
set previously (see paragraph UNITS described later). Every press (pulse)
of the button increases or decreases by one unit. Keeping the button pressed
obtains fast increase or decrease. When you are near the required setting, release
the button and complete adjustment with single presses.
Menu screen
Return
to menu screen
Return to previously
set screen, e.g. See INITIAL CHECK and
ACCESS TO THE MENU SCREEN
çéSelect, by means of buttons
â
or ã
activation or deactivation
(ON/OFF). The set option will be highlighted.
ç
ç
é
â
ã
â
ãâ
ã
é
Page 76 of 357
GETTING TO KNOW YOUR CAR74
Speed limit exceeded indication
As soon as the vehicle exceeds the set speed limit, the following display is shown automatically, together with the sounding of a buzzer.Example of display when the set value is 120 km/h
Page 77 of 357
GETTING TO KNOW YOUR CAR75
TRIP B ON/OFF (TRIP B)With this option it is possible to turn ON or OFF the TRIP B function (partial trip) which displays the figures relating to:
TRAVEL DISTANCE B
, AVER
-
AGE CONSUMPTION B
, AVERAGE SPEED B
, TRAVEL TIME B
during a “partial mission”.
For further details, see “General Trip - Trip B”
Menu screen
Return to menu screen See INITIAL CHECK and ACCESS
TO THE MENU SCREENReturn to previously
set screen, e.g.
â
ã
â
ã
Using the
â
or ã
buttons choose activation
or deactivation ON/OFF.
The set option will be highlighted.
çé
çé
Page 78 of 357
GETTING TO KNOW YOUR CAR76
DATE SETTING/TIME SETTING (DATE)To set the date (day - month - year) and the time (hours-minutes), proceed as follows:
Menu screen
Return to previously
set screen, e.g.:
â
ã
â
ã
â
ã
â
ãEach press (pulse) on the
â
or ã
buttons increases or
decreases by one unit.
Keeping the corresponding
button pressed obtains fast
increase or decrease.
When you are near
the required value, release the
control and complete adjustment
by single presses.
See INITIAL CHECK and ACCESS
TO THE MENU SCREEN
continues on next page
çé
çé
çé
çé
Page 79 of 357
GETTING TO KNOW YOUR CAR77
Return to menu screen
â
ã
â
ã
Each press (pulse) on the
â
or ã
buttons increases or
decreases buttons increases
or decreases by one unit.
Keeping the corresponding button
pressed obtains fast increase or
decrease. When you are near
the required value, release the
control and complete adjustment
by single presses.
continued from previous page
Return to previously
set screen, e.g.:
çé
çé
Page 80 of 357
GETTING TO KNOW YOUR CAR78
LANGUAGE SELECTION (LANGUAGE)The messages shown on the display can be provided in several languages (Italian, Deutsch, English, Spanish, French, Dutch, Portuguese).
To select the required language, proceed as follows:
Menu screen
Return to menu screenReturn to previously
set screen, e.g.
â
ã
â
ãSee INITIAL CHECK and ACCESS
TO THE MENU SCREEN
çé
çé
