2004.5 Peugeot 206 Dag Owner's Manual

111
-
31-01-2005
HEADLAMP ADJUSTMENT
Depending on the load in your vehi-
cle, it is recommended that the head-
lamp beam is adjusted.
0 - 1 or 2 people in the front seats.
- - 3 people.
1 - 5 people.
2 - 5 people + maximum
authorised load.
3 - Driver + maximum
authorised load.
Initial setting is position 0.
STEERING WHEEL HEIGHT
ADJUSTMENT
When stationary, lower the handle to
unlock the steering wheel.
Adjust to the desired height and
lift the handle to lock the steering
wheel.
HORN
Press one of the spokes of
the steering wheel.
Layout

112 -
31-01-2005
113
-
31-01-2005
GLOVE BOX
To open the glove box, lift the handle.
The light comes on when the cover
is opened.
1. Handbook pack storage.
2. Can holder.
3. Pen holder.
4. Spectacles storage.
5. Map storage.
6. Coin storage.
FRONT ASHTRAY
To empty, close the cover.
Pull the lug and release the ashtray
upwards.
LIGHTER
Press and wait a few moments until it
springs out automatically.
It is supplied with power with the igni-
tion key in the accessories position
(1st notch).
Layout

114 -
31-01-2005
115
-
31-01-2005
Luggage retaining net
Use the stowing rings on the boot
loor and on the back of the rear seat
to hook on your luggage retaining
net.
There are several options for storing
the shelf:
- either behind the front seats,
- or behind the rear seat using the
luggage retaining net,
- or lat in the boot.
Rear parcel shelf
To remove the shelf:
- unhook the two strings
1
,
- slightly raise the shelf, then remove it.
BOOT LAYOUT
(saloon) Layout

114 -
31-01-2005
115
-
31-01-2005
Retaining strap
A strap secured to the side of the
boot enables you to secure various
objects (cans, irst aid kit etc.).
Layout

116 -
31-01-2005
117
-
31-01-2005
Layout

116 -
31-01-2005
117
-
31-01-2005
BOOT LAYOUT (206 SW)
1. Grab handles and coat hooks
2. Coat hooks
There are six hooks to accommodate
coats.
3. High load retaining net
fastenings
The high load retaining net can be
installed behind the front seats or
behind the rear seat.
Open the covers of the correspond-
ing upper fastenings.
Install one end of the metal bar in
one of the two fastenings, compress
the bar, then install the other end and
release.
Secure the two net strap hooks be-
hind the front seats, with the rear
seat folded down, or in the stowing
rings on the loor.
The rings are located directly below
the corresponding upper fastenings.
Pull the two straps taut.
4. Hooks
There are two side hooks on which to
hang light bags. 5. 12 V Socket for accessories
This is a 12 volt socket (lighter type)
installed on the the rear left trim and
supplied from the accessories posi-
tion (1st notch).
6. Storage nets
There are two nets (which cannot be
removed), which can contain the lug-
gage retaining net, a irst aid kit etc.
7. Retaining straps
There are two straps for securing
various objects: cans etc.
8. Load space cover
Note:
release the rear seat back to
make installation and removal of the
load space cover easier.
To install it:
- position one end of the roller in one of the two supports,
- compress the opposite end of the roller and position it,
- release it to allow it to engage,
- unroll the cover as far as the boot pillars,
- insert the cover guides in the rails in the pillars. To remove it:
- remove the cover guides from the
pillar rails,
- return the cover into its roller, com- press it and remove it from its sup-
port.
9. Stowing rings
There are eight stowing rings for se-
curing the luggage retaining net: four
on the rear seat back and four on the
boot loor (two of which are under the
carpet, at the far end of the boot).
Warning triangle
The tailgate has a location intended
for a warning triangle.
Layout

118 -
31-01-2005
BOOT LAYOUT (206 RC)
1. Insulated storage boxcontaining a puncture
repair kit.
2. Cover containing the jack and the folding chock.
3. Grab handles with coat hook.
4. Removable rear shelf.
5. Retaining strap for miscellaneous objects:
can, irst aid kit, etc.
6. Stowing rings.
There are six stowing rings onto
which the luggage retaining net may
be hooked: four on the back of the
rear seats and two on the boot rear
inner panel (on the right and on the
left).
7. Luggage retaining net storage (example of location) .
Layout

119
-
31-01-2005
'PORSCHE TIPTRONIC
system' AUTOMATIC
GEARBOX
The four speed automatic gearbox
offers a choice between the comfort
of integral automatic operation ,
enhanced by a sport and a snow pro-
gram, or manual gear changing .
Gear selection gate
F Move the lever in the gate to
select a position.
The indicator light corresponding to the position selected appears
on the instrument panel screen.
P ark: to immobilise the vehicle and
to start the engine , with the hand-
brake on or off.
R everse: to reverse (select this
position with the vehicle stationary,
engine at idle).
N eutral: to start the engine and to
park , with the handbrake on.
If position N is inadvertently engaged
while driving, allow the engine to re-
turn to idle before engaging position
D to accelerate.
D rive: for driving in automatic
mode. M anual: for selection of gears.
S : sport program.
T: snow program.
Moving Off
With the engine running, to move off
from position P:
F it is essential to press the brake
pedal to exit position P,
F select position R, D or M, then
gradually release the pressure
on the brake pedal; the vehicle
moves off immediately.
You can also move off from position N:
F release the handbrake, with your
foot on the brake,
F select position R, D or M, then
gradually release the pressure
on the brake pedal; the vehicle
moves off immediately.
Starting the engine
F with the handbrake on, select
position P or N in the gate,
F turn the ignition key to the Start
position. WARNING
When the engine is at idle, brakes not
applied, if position
R, D or M is select-
ed, the vehicle moves even without
the accelerator being pressed.
For this reason, do not leave chil-
dren unsupervised inside the ve-
hicle, with the engine running.
When maintenance operations need
to be carried out with the engine run-
ning, apply the handbrake and select
position P.
Driving
