2004.5 Peugeot 206 Dag Owner's Manual

100 -
31-01-2005
101
-
31-01-2005
The lighting is activated on open-
ing the tailgate or the rear screen.
Notes: the tailgate and the rear
screen lock automatically while driving
(above 6 mph (10 km/h)) and unlock
when one of the doors is opened.
When the rear windscreen wiper is
in a wiping position, the rear screen
can only be opened at the end of the
cycle.
Close the rear screen using the wind-
screen wiper arm or by pressing the
centre of the glass.
While driving , if the tailgate
or the rear screen is not
properly closed, the courtesy
light lashes if the button is in
this position.
TAILGATE RELEASE (saloon)
This enables the tailgate to be un-
locked in the event of a central locking
fault:
- Fold back the rear seats to gain access to the boot from inside the
vehicle,
- Pull the tailgate trim to release it,
- Pull the opening catch 1 upwards.
SUNROOF (saloon)
To open
Press part B of the switch. The roof
will open in the intermediate (comfort)
position.
To open the roof completely, press
part B again.
Panoramic sunroof screen
To move it to your chosen position,
press part A or B of the switch.
"Tailgate/rear screen open"
warning
With the engine running
, if the tail-
gate or the rear screen is not properly
closed, you are warned by an audible
signal and a message or a diagram
on the multifunction display.
To close
Press part A of the switch, the roof
will close in the intermediate (comfort)
position.
To close the roof completely, press
part A again.
Accesses

100 -
31-01-2005
101
-
31-01-2005
OPENING THE BONNET
Inside the vehicle: pull the handle on
the left-hand side, under the fascia.
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected when
operating the roof, you must re-
verse the movement of the roof.
To do this, press the control con-
cerned.
When the driver operates the roof
control, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that pas-
sengers use the sunroof correctly.
Be aware of children when operat-
ing the roof.
FILLING THE FUEL TANK
The tank must be illed with fuel with
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A label indicates which type of fuel
to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is ap-
proximately 50 litres. To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.
Accesses

100 -
31-01-2005
101
-
31-01-2005
OPENING THE BONNET
Inside the vehicle: pull the handle on
the left-hand side, under the fascia.
Outside the vehicle: lift the catch
and raise the bonnet.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected when
operating the roof, you must re-
verse the movement of the roof.
To do this, press the control con-
cerned.
When the driver operates the roof
control, he must ensure that no
one is preventing correct closing
of the roof.
The driver must ensure that pas-
sengers use the sunroof correctly.
Be aware of children when operat-
ing the roof.
FILLING THE FUEL TANK
The tank must be illed with fuel with
the engine switched off .
Insert the key then turn it to the left.
Remove the cap.
A label indicates which type of fuel
to use.
If you ill your tank, do not continue
after the third cut-off of the pump
nozzle. This could result in vehicle
malfunctions.
The capacity of the tank is ap-
proximately 50 litres. To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.
Accesses

102 -
31-01-2005
103
-
31-01-2005
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped/Main beam change
Pull the stalk towards you.
Note:
with the ignition off and the
automatic lighting function switched
off, when the driver's door is opened,
a buzzer sounds if you have left your
lights on. Vehicles itted with front fog lamps
and a rear fog lamp (ring C)
Side lights Dipped/Main beam
headlampsAutomatic switching
on of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off
the rear fog lamp and the front fog
lamps, turn the ring backwards twice
in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights remain on
(turn the ring backwards to switch off
the front fog lamps. The side lights
then switch off).
Vehicles itted with a rear fog lamp
(ring B)
This only operates with the dipped/
main beam headlamps.
Note: when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps remain
on (turn the ring backwards to switch
off the rear fog lamp. The dipped
headlamps and side lights then
switch off). The front fog lamps operate with
the side lights and the dipped head-
lamps.
When the main beam headlamps are
switched on, the front fog lamps are
switched off. They are switched on
again when the main beam head-
lamps are switched off.
Lights off
Front fog lamps and rear fog
lamp
Rotate the ring forwards to switch on
and backwards to switch off. The sta-
tus is conirmed by the indicator light
on the instrument panel.
Visibility

102 -
31-01-2005
103
-
31-01-2005
"Follow me home" lighting
When you leave your vehicle, the
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
position,
- place the lights stalk in the 0
position,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the vehi-
cle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards. Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly,
the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
Visibility

102 -
31-01-2005
103
-
31-01-2005
"Follow me home" lighting
When you leave your vehicle, the
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP
position,
- place the lights stalk in the 0
position,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the vehi-
cle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards. Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly,
the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
Visibility

104 -
31-01-2005
105
-
31-01-2005
WINDSCREEN WIPER STALK
Front windscreen wiper with
intermittent wipe
2 Fast wipe (heavy rain).
1 Normal wipe
(moderate rain).
l Intermittent wipe.
0 Off.
â Single wipe
(press downwards).
In the Intermittent position, the wip-
ing speed is in proportion to the ve-
hicle speed. Front windscreen wiper with
automatic wipe
2
Fast wipe (heavy rain).
1 Normal wipe
(moderate rain).
AUTO Automatic wipe.
0 Off.
â Single wipe
(press downwards).
In the AUTO position, the wiping
speed is in proportion to the intensity
of the rainfall. The command must be reactivated
whenever the ignition has been
switched off for more than one
minute:
- move the stalk to any position,
- then move it back to the required
position.
Windscreen and headlamp wash
Pull the windscreen wiper stalk to-
wards you. The windscreen wash
then the windscreen wipers operate
for a ixed period.
The windscreen wash and head-
lamp wash operate simultaneously
for two seconds, only if the head-
lamps are on.
Visibility

104 -
31-01-2005
105
-
31-01-2005
Automatic windscreen wipers
In the AUTO position, the wind-
screen wipers operate automatically
and adapt their speed to the inten-
sity of the rainfall . Do not cover the rain sen-
sor located on the wind-
screen behind the interior
mirror.
When using an automatic car
wash, switch off the ignition or
check that the wiper stalk is not in
the AUTO position.
In winter, it is advisable to wait
for the windscreen to completely
clear of ice before operating the
automatic wipe.Rear screen wiper
Rear screen wash
Turn ring A to the irst notch
for intermittent wiping.
If the ignition is switched
off, it is necessary to re-
activate the control each
time. To do this, move the stalk to
any position, then move it back to the
required position .
Turn ring A past the irst
notch; the screen wash then
the wiper operate for a ixed
period.
206 SW: the rear screen wiper and
rear screen wash functions are dis-
armed automatically when the rear
screen is open.
Operating check
Activation
Activation of the function is accom-
panied by a message on the multi-
function display.
In the event of malfunction
, the driv-
er is informed by an audible signal.
In the AUTO position, the wind-
screen wiper will operate in intermit-
tent mode.
Contact a PEUGEOT dealer to have
the system checked. Automatic rear screen wiper
When the windscreen wipers control
is activated and you engage reverse
gear, the rear screen wiper operates
intermittently.
Note:
if you use a bicycle carrier,
consult a PEUGEOT dealer to have
this function deactivated or install a
speciic bicycle carrier approved by
PEUGEOT.
Visibility
