2004.5 Peugeot 206 Dag Owner's Manual

94 -
31-01-2005
SEAT BELTS
Seat belt height adjustment:
- to lower: pull the control towards you and slide it downwards,
- to raise: slide the control upwards. To lock the seat belts
Pull the strap, then insert the end into
the buckle.
To be effective, a seat
belt must be tightened as
close to the body as pos-
sible.
Depending on the nature and
seriousness of the impact, the
pre-tensioning system may be
triggered before and independ-
ently of the air bags.
In all cases, the air bag warn-
ing light on the instrument panel
comes on.
Following an impact, have the
system checked by a PEUGEOT
dealer.
Front seat belts with
pre-tensioner and force limiter
Safety in the event of front impacts
has been improved by the introduc-
tion of seat belts with pre-tensioner
and force limiter for the front seats.
Depending on the seriousness of the
impact, the pre-tensioning system
instantly tightens the seat belts and
pulls them against the bodies of the
occupants.
The pre-tensioning seat belts are
active when the ignition is on.
The force limiter eases the pressure
of the seat belt on the body of the oc-
cupant in the event of an accident.
Rear seat belts
The rear seats are itted with:
- three three-point inertia reel seat
belts (saloon and 206 SW),
- two three-point inertia reel seat belts (206 RC),
- two three-point inertia reel seat belts and one two-point lap belt
(one-part rear seat).
Comfort

95
-
31-01-2005
THE KEYS
The keys allow you to switch on the
ignition, operate the steering lock,
the passenger air bag disarming
switch, the fuel iller cap and the boot
(saloon), as well as independently
operate the locks on the front doors. Locking
Press button
A to lock the vehicle.
This is conirmed by ixed lighting of
the direction indicators for approxi-
mately two seconds. Locating your vehicle
To locate your vehicle, if you have
locked it, in a car park:
F
press button A, the courtesy lights
come on and the direction indica-
tors lash for a few seconds.
Changing the battery of the
remote control
Warning that the battery is lat is given
by an audible signal accompanied by
the message "Remote control battery
low" on the multifunction display.
To replace the battery, remove the screw
then unclip the casing using a coin at the
ring (CR 2016/3 volt battery).
If the remote control does not work
after the battery has been changed,
reprogram the remote control.
Key in ignition
A buzzer sounds on opening the
driver's door, if the key has been left
in the ignition.
Programming the remote
control
F Switch off the ignition.
F Switch the ignition on again.
F Press button A immediately for a
few seconds.
F Switch off the ignition and remove
the remote control key from the
ignition lock. The remote control
is now working again.
Central locking and unlocking
The keys allow you to lock or unlock
the doors and tailgate, from the front
doors.
If one of the doors, the tailgate or the
rear screen (206 SW) is open, the
central locking does not work.
The remote control
This performs the same functions as
the key, at a distance. Unlocking
Press button
B to unlock the vehicle.
This is conirmed by the rapid
lashing of the direction indicators.
Special feature on 206 SW: Press
and hold button B to unlock the vehi-
cle and open the rear screen.
If the vehicle is locked and the
unlocking control is pressed with-
out the doors being opened within
30 seconds, the vehicle will re-lock
automatically.
Avoid pressing the buttons of your
remote control out of range of your
vehicle. You risk causing it not to
work and the remote control would
then have to be reprogrammed (see
corresponding section).
Accesses

96 -
31-01-2005
97
-
31-01-2005
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
does not have the key.
The ignition key has an electronic
chip which has a special code.
When the ignition is switched on, the
code must be recognised for starting
to be possible.
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
Keep your card in a safe place,
never inside the vehicle.
When undertaking a long trip or
journey, however, it is advisable to
take it with you. The conidential
card contains the identiication code
necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code
is hidden by a ilm, which should be
removed only if necessary. Make a careful note of the
number of each key. This
number is coded on the la-
bel attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote control
is a sensitive system; do not oper-
ate it while it is in your pocket as
there is a possibility that it may un-
lock the vehicle, without you being
aware of it.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an emer-
gency.
As a safety precaution (with chil-
dren on board), remove the key
from the ignition when you leave
the vehicle, even for a short time. Do not repeatedly press the buttons
of your remote control out of range
of your vehicle.
You run the risk of stopping it from
working and the remote control
would have to be reprogrammed.
When purchasing a second-hand
vehicle:
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure
that the keys in your possession
are the only ones which can start
the vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
If the system does not function cor-
rectly, the central locking button indi-
cator light, situated in the centre of
the fascia, lashes rapidly when the
ignition is switched on (2nd notch).
In this case your vehicle will not
start.
Contact a PEUGEOT dealer as soon
as possible.
Accesses

96 -
31-01-2005
97
-
31-01-2005
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
does not have the key.
The ignition key has an electronic
chip which has a special code.
When the ignition is switched on, the
code must be recognised for starting
to be possible.
CONFIDENTIAL CARD
This is given to you on delivery of
your vehicle with the duplicate keys.
Keep your card in a safe place,
never inside the vehicle.
When undertaking a long trip or
journey, however, it is advisable to
take it with you. The conidential
card contains the identiication code
necessary for any work carried out
by a PEUGEOT dealer on the elec-
tronic immobiliser system. This code
is hidden by a ilm, which should be
removed only if necessary. Make a careful note of the
number of each key. This
number is coded on the la-
bel attached to the key.
If the keys are lost, your PEUGEOT
dealer can rapidly supply you with
new keys.
The high frequency remote control
is a sensitive system; do not oper-
ate it while it is in your pocket as
there is a possibility that it may un-
lock the vehicle, without you being
aware of it.
The remote control does not oper-
ate when the key is in the ignition,
even when the ignition is switched
off, except for reprogramming.
Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an emer-
gency.
As a safety precaution (with chil-
dren on board), remove the key
from the ignition when you leave
the vehicle, even for a short time. Do not repeatedly press the buttons
of your remote control out of range
of your vehicle.
You run the risk of stopping it from
working and the remote control
would have to be reprogrammed.
When purchasing a second-hand
vehicle:
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure
that the keys in your possession
are the only ones which can start
the vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.
If the system does not function cor-
rectly, the central locking button indi-
cator light, situated in the centre of
the fascia, lashes rapidly when the
ignition is switched on (2nd notch).
In this case your vehicle will not
start.
Contact a PEUGEOT dealer as soon
as possible.
Accesses

96 -
31-01-2005
97
-
31-01-2005
THE DOORS
The front doors
The rear doors (206 SW)
Opening the doors from outside Opening the doors from inside
Locking from inside
"Door open" warning
With the engine running
, you are
warned if a door is not shut properly
by an audible signal and a message
or graphic on the multifunction dis-
play, indicating the door in question.
When the vehicle is moving , if
the courtesy light button is in the
"lighting on opening a door" position,
the courtesy light lashes.
Without central locking
To lock, press button A. The button
locks the door in question.
The button on the driver's door locks
the door, the tailgate and the rear
screen (206 SW).
With central locking
To lock, press button A.
Locking one of the front doors locks
the front and rear doors, the tailgate
and the rear screen (206 SW).
On the rear doors, the button only
locks the door in question.
Unlocking from inside
To unlock, pull button A or operate
the handle.
Accesses

98 -
31-01-2005
99
-
31-01-2005
CHILD SAFETY LOCK
On each rear door this prevents
opening of the door from the inside.
Turn switch 1 a quarter turn using the
ignition key.
Locking/Unlocking from the
inside*
Pressing button
A permits locking/
unlocking of the doors. To switch on
Press and hold button
A.
Activation of the function is accompa-
nied by an audible signal and a mes-
sage on the multi-function display.
The message is displayed each time
the vehicle is started.
* According to speciication.
To switch off
Press and hold button
A.
Notes: if one of the doors is open,
locking from the inside and automatic
central locking are not possible.
If the boot is open, automatic central
locking of the doors is active.
Automatic central locking of the
doors
The doors can lock automatically
when you are driving (at a speed of
more than 6 mph (10 km/h)).
Above 6 mph (10 km/h), press button
A briely to unlock the doors tempo-
rarily.
You can activate or deactivate this
function.
Accesses

98 -
31-01-2005
99
-
31-01-2005
LOCKING/UNLOCKING OF
THE TAILGATE (saloon)
Without central locking:
To lock, turn the key from A to C.
To open, turn the key from A to B,
press the handle then lift the tailgate.
LOCKING/UNLOCKING OF
THE TAILGATE AND REAR
SCREEN (206 SW)
It is not possible to open the tail-
gate and the rear screen simulta-
neously.
With central locking
Locking or unlocking of the tailgate is
simultaneous with the doors.
With the rear screen closed, to open
the tailgate , operate the handle A
and lift the tailgate.
With the tailgate closed, to open
the rear screen , press and hold the
remote control unlocking button or
operate the handle B, then lift the
rear screen using the windscreen
wiper arm (location C).
Without central locking
The tailgate and rear screen are
locked or unlocked via the driver's
door lock.
With the rear screen closed, to open
the
tailgate , operate the handle A
and lift the tailgate.
With the tailgate closed, to open the
rear screen , operate the handle B,
then lift the rear screen using the
windcsreen wiper arm (location C).
With central locking:
Locking and unlocking of the tailgate
is simultaneous with the doors.
The lighting is activated on opening
the tailgate.
Accesses

100 -
31-01-2005
101
-
31-01-2005
The lighting is activated on open-
ing the tailgate or the rear screen.
Notes: the tailgate and the rear
screen lock automatically while driving
(above 6 mph (10 km/h)) and unlock
when one of the doors is opened.
When the rear windscreen wiper is
in a wiping position, the rear screen
can only be opened at the end of the
cycle.
Close the rear screen using the wind-
screen wiper arm or by pressing the
centre of the glass.
While driving , if the tailgate
or the rear screen is not
properly closed, the courtesy
light lashes if the button is in
this position.
TAILGATE RELEASE (saloon)
This enables the tailgate to be un-
locked in the event of a central locking
fault:
- Fold back the rear seats to gain access to the boot from inside the
vehicle,
- Pull the tailgate trim to release it,
- Pull the opening catch 1 upwards.
SUNROOF (saloon)
To open
Press part B of the switch. The roof
will open in the intermediate (comfort)
position.
To open the roof completely, press
part B again.
Panoramic sunroof screen
To move it to your chosen position,
press part A or B of the switch.
"Tailgate/rear screen open"
warning
With the engine running
, if the tail-
gate or the rear screen is not properly
closed, you are warned by an audible
signal and a message or a diagram
on the multifunction display.
To close
Press part A of the switch, the roof
will close in the intermediate (comfort)
position.
To close the roof completely, press
part A again.
Accesses
