2003 TOYOTA TACOMA Owners Manual (in English)

’03 Tacoma U (L/O 0209)
2912003 MY TACOMA (OM35800U)
With offroad packagekg (lb.)
Fourwheel drive models
3RZFE engineXtracabManual transmission703 (1550)
5VZFE engineXtracabManual transmission682 (1505)
Automatic transmission671 (1480)
Double cabAutomatic transmission596 (1315)
Pre Runner
3RZFE engineXtracabAutomatic transmission793 (1750)
Double cabAutomatic transmission721 (1590)
5VZFE engineXtracabAutomatic transmission773 (1705)
Double cabAutomatic transmission700 (1545)
∗: Occupants + luggage

’03 Tacoma U (L/O 0209)
2922003 MY TACOMA (OM35800U)
Model:2RZFE, 3RZFE and 5VZFE
Type:
2RZFE and 3RZFE engines4 cylinder in line, 4 cycle, gasoline
5VZFE engine 6 cylinder V type, 4 cycle, gasoline
Bore and stroke, mm (in.): 2RZFE engine95.0 86.0 (3.74 3.39)
3RZFE engine 95.0 95.0 (3.74 3.74)
5VZFE engine 93.5 82.0 (3.68 3.23)
Displacement, cm
3 (cu. in.):
2RZFE engine 2438 (148.8)
3RZFE engine 2694 (164.3)
5VZFE engine 3378 (206.1) Fuel type:
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): Twowheel drive models except Pre
Runner60 (16.0, 13.3)
Fourwheel drive models and Pre
Runner 70 (18.5, 15.4) ENGINE
Valve clearance (engine cold), mm (in.):
2RZFE and 3RZFE enginesIntake 0.15—0.25 (0.006—0.010)
Exhaust 0.25—0.35 (0.010—0.014)
5VZFE engine Intake 0.13—0.23 (0.006—0.009)
Exhaust 0.27—0.37 (0.011—0.014)
Spark plug type: 2RZFE and 3RZFE enginesDENSO K16RU11
NGK BKR5EYA11
5VZFE engine DENSO K16TR11
NGK BKR5EKB11
Spark plug gap, mm (in.): 1.1 (0.043)
Engine FuelService specifications

’03 Tacoma U (L/O 0209)
2932003 MY TACOMA (OM35800U)
Drive belt tension measured with Bor-
roughs drive belt tension gauge No.
BT3373F (used belt), lbf:2RZFE and 3RZFE enginesGenerator belt 115  20
Air conditioning compressor belt
100 20
Power steering pump belt
100
+20
15
5VZFE engineGenerator belt 100  20
Air conditioning compressor belt 100 20
Power steering pump belt
100
+20
15
ENGINE LUBRICATION
Oil capacity (drain and refill),
L (qt., Imp. qt.):
Twowheel drive models except Pre
Runner2RZFE engineWith filter 5.5 (5.8, 4.8)
Without filter 4.8 (5.0, 4.2)
5VZFE engine With filter 5.4 (5.7, 4.8)
Without filter 5.1 (5.4, 4.5)
Fourwheel drive models and Pre
Runner
3RZFE engineWith filter 5.4 (5.7, 4.8)
Without filter 4.7 (5.0, 4.1)
5VZFE engine With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
“Toyota Genuine Motor Oil” is f illed in
your Toyota vehicle. Use Toyota approved
“Toyota Genuine Motor Oil” or equivalent
to satisfy the following grade and
viscosity.
Oil grade: API grade SL “EnergyConserving” or
ILSAC multigrade engine oil Recommended oil viscosity:
SAE 5W30
Outside temperature
Please contact your Toyota dealer for fur-
ther details.
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Twowheel drive models except Pre
RunnerWith manual transmission2RZFE engine 8.0 (8.5, 7.0)
5VZFE engine 9.7 (10.3, 8.5)
With automatic transmission 2RZFE engine 7.8 (8.2, 6.9)

’03 Tacoma U (L/O 0209)
2942003 MY TACOMA (OM35800U)
Fourwheel drive models and Pre
RunnerWith manual transmission3RZFE engine 8.3 (8.8, 7.3)
5VZFE engine 10.1 (10.7, 8.9)
With automatic transmission 3RZFE engine 8.2 (8.7, 7.2)
5VZFE engine 10.0 (10.5, 8.8)
Coolant type: “Toyota Genuine Long Life Coolant” is
filled in your Toyota vehicle. In order to
avoid technical problems, we strongly
recommend using “Toyota Genuine Long
Life Coolant” or equivalent.
With ethyleneglycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
Please contact your Toyota dealer for
further details. BATTERY
Open voltage
∗ at 20
°C (68 °F):
12.6—12.8 V Fully charged
12.2—12.4 V Half charged
11.8—12.0 V Discharged
∗: Voltage that is checked 20 minutes
after the key is removed with all the
lights turned off
Charging rates: 5 A max.
CLUTCH
Pedal free play, mm (in.): 5—15 (0.2—0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.): 2RZFE engine 2.6 (2.7, 2.3)
3RZFE engine 2.5 (2.6, 2.2)
5VZFE engineTwowheel drive models 2.6 (2.7, 2.3)
Fourwheel drive models 2.2 (2.3, 1.9)
Oil type: Gear Oil API GL4 or GL5
Recommended oil viscosity: SAE 75W90 AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref
ill),
L (qt., Imp. qt.):
Twowheel drive models except Pre
RunnerUp to 2.4 (2.5, 2.1)
Fourwheel drive models and Pre Run-
ner Up to 2.0 (2.1, 1.8)
Fluid type:
2RZFE engine—Toyota Genuine ATF DII or
DEXRON III (DEXRON II)
3RZFE and 5VZFE engines—
Toyota Genuine ATF Type TIV
Change automatic transmission fluid
only as necessary.

’03 Tacoma U (L/O 0209)
2952003 MY TACOMA (OM35800U)
Generally, it is necessary to change
automatic transmission fluid only if
your vehicle is driven under one of
the Special Operating Conditions listed
in your “Scheduled Maintenance
Guide” or “Owner ’s Manual Supple-
ment”. When changing the automatic
transmission fluid, use only “Toyota
Genuine ATF Type TIV” (ATF
JWS3309 or NWS6500) to aid in
assuring optimum transaxle perfor-
mance.
Notice: Using automatic transmis-
sion fluid other than “Toyota Genu-
ine ATF Type TIV” may cause dete-
rioration in shift quality, locking up
of your transmission accompanied
by vibration, and ultimately damage
the automatic transmission of your
vehicle.
Please contact your Toyota dealer for fur-
ther details.
TRANSFER
Oil capacity, L (qt., Imp. qt.): 1.0 (1.1, 0.9)
Oil type: Gear Oil API GL4 or GL5
Recommended oil viscosity: SAE 75W90 DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.):
Twowheel drive models except Pre
Runner2RZFE engine 1.35 (1.4, 1.2)
5VZFE engine 2.55 (2.7, 2.2)
Fourwheel drive models and Pre
Runner
Front (except Pre Runner) 1.15 (1.2, 1.0)
Rear Short wheel baseWith rear differential lock system 2.65 (2.8, 2.3)
Without rear differential lock sys-
tem 2.55 (2.7, 2.2)
Extra long wheel base With rear differential lock system 2.95 (3.1, 2.6)
Without rear differential lock sys-
tem 2.45 (2.6, 2.2)
Oil type: Hypoid Gear Oil API GL5 Recommended oil viscosity:
Front SAE 75W90
Rear Above 18 C (0 F)
SAE 90
Below 18 C (0 F)
SAE 80W or 80W90
CHASSIS LUBRICATION
Wheel bearings: Lithium base wheel bearing grease,
NLGI No.2
Front drive shaft thrust bushings: Synthetic oil and lithium soap base
chassis grease, NLGI No.1
Propeller shafts: SpidersLithium base chassis grease, NLGI
No.2
Slide yoke and double cardan joint Molybdenumdisulfide lithium base
chassis grease, NLGI No.2

’03 Tacoma U (L/O 0209)
2962003 MY TACOMA (OM35800U)
BRAKES
Minimum pedal clearance when depressed
with a pressure of 490 N (50 kgf, 110 lbf)
when the engine is stopped and after de-
press the brake pedal several times,
mm (in.):105 (4.1)
Pedal free play, mm (in.): 1—6 (0.04—0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf): 16—30 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel free play: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III
Tires
Tire size Tire pressure
kPa (kgf/cm2 or bar, psi) Wheel size
Front Rear
P205/75R15 97S 200 (2.0, 29) 200 (2.0, 29)
P225/75R15 102S 180 (1.8, 26) 200 (2.0, 29) 1661/2JJ
P235/55R16 96T 200 (2.0, 29) 220 (2.2, 32) 15
7J
15 7JJ
P265/70R16 111S 180 (1.8, 26) 180 (1.8, 26) 16
7J
16 7JJ
15
6J
15 6JJ
Wheel nut torque, N·m (kgf·m, ft·lbf): 11 0 ( 11 . 5 , 8 3 )
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire pressure” through “Aluminum wheel precautions” in Sec-
tion 72.
∗1: Double cab models∗2: Regular cab and Xtracab models
P265/70R16 111T 180 (1.8, 26) 180 (1.8, 26)∗
1
200 (2.0, 29)∗216 7JJ

’03 Tacoma U (L/O 0209)
2972003 MY TACOMA (OM35800U)
Engine compartment (without daytime run-
ning light system)
Fuses (type A)1. HEAD (RH) 10 A: Righthand headlight
2. HEAD (LH) 10 A: Lefthand headlight
3. DRL 7.5 A: Daytime running light
system
4. HEAD (HI RH) 10 A: Righthand head- light (high beam), high beam indicator
light
5. HEAD (HI LH) 10 A: Lefthand head-
light (high beam)
6. HEAD (LO RH) 10 A: Righthand headlight (low beam)
Engine compartment (with daytime run-
ning light system)
7. HEAD (LO LH) 10 A: Lefthand head-
light (low beam)
8. TAIL 10 A: Tail lights, licence plate
lights
9. A.C 10 A: Air conditioning system
10. ECTS 15 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
11. DOME 15 A: Car audio system, interior
light, clock, personal lights, door cour-
tesy light, day time running light sys-
tem, gauges and meters
Instrument panel
12. OBD 7.5 A: Onboard diagnosis sys-
tem
13. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
14. ALTS 7.5 A: Charging system
15. PWR OUTLET 15 A: Power outlet
16. ECUIG 15 A: Cruise control system,
antilock brake system, automatic
transmission shift lock system, SRS
airbag system
17. TURN 10 A: Turn signal lights, emer-
gency flashers
Fuses

’03 Tacoma U (L/O 0209)
2982003 MY TACOMA (OM35800U)
18. WIPER 20 A: Windshield wipers and
washer
19. 4WD 20 A: A.D.D. control system,
fourwheel drive control system, rear
differential lock system
20. ACC 15 A: Cigarette lighter, clock,
power rear view mirrors, backup
lights, automatic transmission shift lock
system, SRS airbag system, seat belt
pretensioners, car audio system
21. GAUGE 10 A: Day time running light
system, backup lights, cruise control
system, rear differential lock system,
electronically controlled automatic
transmission system, starting system,
charging system, air conditioning sys-
tem
22. IGN 7.5 A: Gauges and meters, SRS
airbag system, seat belt pretensioners,
multiport fuel injection system/sequen-
tial multiport fuel injection system
23. ECUB 7.5 A: SRS warning light, air
conditioning system
24. HORNHAZ 15 A: Emergency flashers,
horns
25. STA 7.5 A: Clutch start cancel system,
starting system 26. STOP 10 A:
Stop lights, high mounted
stoplight, cruise control system, anti
lock brake system, multiport fuel injec-
tion system/sequential multiport fuel in-
jection system
Fuses (type B)
27. POWER 30 A: Power windows, power
seat
28. J/B 50 A: All components in “POWER”,
“HORNHAZ”, “STOP” and “ECUB”
fuses
29. AM2 30 A: Ignition system, multiport
fuel injection system/sequential fuel in-
jection system
30. HEATER 50 A: All components in “A.C”
fuse
31. AM1 40 A: Starting system
32. ABS2 30 A: Antilock brake system
Fuses (type C)
33. ABS 60 A: Antilock brake system
34. ALT 120 A: All components in “AM1”,
“HEATER”, “A.C”, “TAIL”, “ALTS” and
“PWR OUTLET” fuses
